RC-Easy Pipe Manual

PIPE Manual
Pipe
Dear Customer,
You have bought the Pipe, a competitive indoor aerobatic plane. Before you start building the plane,
read carefully the instructions and make sure you understand the sequence of operations. In case of
difficulties, contact your vendor or the manufacturer.
Part description
3mm depron wing
EPP fuselage
Building instructions
Carbon wing joiners (1x 130 mm
carbon)
Reinforcement of EPP fuselage sides
(carbon 1x690mm)
Elevator and rudder pushrods
(carbon 1x380mm)
Wing reinforcements (1x330)
Fuselage reinforcement (carbon
1x166)
Depron wing braces
Landing gear formers
Rudder pushrod ending (carbon
1x160)
You will also need:
Donocik Handels und Leasing GmbH, Jägerweg 8, 85658 Egmating
email: info@rc-easy.com
Tel: +49 - (0)8095 - 2752
List of parts:
pieces Part description
2
1
2
4
2
2
4
2
2
2
1
Web: www.rc-easy.com
Fax: +49 - (0)8095- 8951
Donocik handels & leas. GmbH
rudder
elevator
Control horn
EPP fuselage reinforcement
EPP pushrod ducts 5x5x10 mm
Carbon firewall
)
Elevator pushrods (1x60 mm)
Landing gear legs (carbon 1,5x200)
20 mm landing gear wheels
Upper wing EPP „saddle" 5x5x150
mm
Elevator pushrod ending (carbon
1x90)
pieces
2
2
4
2
6
1
4
2
2
1
1
1
