ISTRUZIONI PER L'INSTALLAZIONE E MONTAGGIO DEL CARICA BATTERIE PER I PROGRAMMATORI PRG851-PRG852
BATTERy ChARGER INSTALLATION AND ASSEMBLy INSTRUCTIONS fOR PRG851-PRG852 ELECTRONIC PROGRAMMERS
INSTRUCTIONS POUR L'INSTALLATION DU ChARGEUR DE BATTERIE POUR LES PROGRAMMATEURS PRG851-PRG852
INSTALLATIONSANLEITUNG DES BATTERIELADEGERÄTES fÜR DIE PROGRAMMIERER PRG851 UND PRG852
INSTRUCCIONES PARA LA INSTALACIÓN DEL CARGADOR DE BATERÍAS PARA LOS PROGRAMADORES PRG851-PRG852
ITALIANO
COLLEGAMENTO PRG851
COLLEGAMENTO PRG852
ENGLISH
FRANÇAIS
DEUTSCH
ESPAÑOL
DESCRIPCIÓN GENERAL
APERTURA DEL CONTENEDOR
EXTRACCIÓN DEL CIRCUITO
INSERCIÓN DE LAS BATERÍAS
PREPARACIÓN DE LOS HILOS
CONEXIÓN PARA PRG851
CONEXIÓN PARA PRG852
ENSAMBLAJE FINAL
MODALIDADES DE FUNCIONAMIENTO
