INFOSEC UPS SYSTEM X1 EX Series User Manual page 6

B A C K P A N E L
X 1 E X – 5 0 0 / 7 0 0 / 1 0 0 0 R E A R P A N E L
Optional USB
Breaker
AC Input Cable
X 1 E X – 1 2 5 0 R E A R P A N E L
Optional USB port
X 1 E X – 1 6 0 0 / 2 0 0 0 R E A R P A N E L
AC Input Outlet
INFOSEC UPS SYSTEM - 4, rue de la Rigotière - 44700 Orvault - FRANCE - www.infosec-ups.com
6
Hot Line – Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)2 40 94 29 51 - hotline@infosec.fr – 03 15 AA 59 204 31
Fuse
2 protected UPS outlets
AC Input Cable
Breaker
4 protected UPS outlets
Optional USB port
4 protected UPS outlets
