High power Tungsten-
Halogen Light Source
- ASBN-W-050 / ASBN-W075 -
- ASBN-W100 / ASBN-W150 -
Operation Manual
Advertisement
Table of Contents
Summary of Contents for Spectral Products ASBN-W-050
- Page 1 Spectrometers · Spectrophotometers · Color Instruments · Spectrographs · Monochromators 111 Highland Drive · Putnam, CT · 06260 · USA PHONE (860) 928-5834· FAX (860) 928-2676 http://www.spectralproducts.com High power Tungsten- Halogen Light Source - ASBN-W-050 / ASBN-W075 - - ASBN-W100 / ASBN-W150 - Operation Manual...
-
Page 2: Important Safety Notices
For warranty service or repair, this product must be returned to a service facility designated by Spectral Products (SP). For products returned under warranty, the Buyer shall prepay shipping charges (including shipping charges, duties, and taxes for products returned to SP from another country), and SP will pay for shipping charges to return the product to the Buyer. -
Page 3: Specification
Spectral Products Spectrometers · Spectrophotometers · Color Instruments · Spectrographs · Monochromators 111 Highland Drive · Putnam, CT · 06260 · USA PHONE (860) 928-5834· FAX (860) 928-2676 http://www.spectralproducts.com Specification The following tables provide information on our high-power tungsten-halogen light sources. - Page 4 Spectral Products Spectrometers · Spectrophotometers · Color Instruments · Spectrographs · Monochromators 111 Highland Drive · Putnam, CT · 06260 · USA PHONE (860) 928-5834· FAX (860) 928-2676 http://www.spectralproducts.com Component 1” UV grade fused silica (quartz) bi-convex lens, Fiber Optics...
- Page 5 Spectral Products Spectrometers · Spectrophotometers · Color Instruments · Spectrographs · Monochromators 111 Highland Drive · Putnam, CT · 06260 · USA PHONE (860) 928-5834· FAX (860) 928-2676 http://www.spectralproducts.com Spectrum The Tungsten-halogen light source is a well known near black body radiation source.
-
Page 6: Operation
Spectral Products Spectrometers · Spectrophotometers · Color Instruments · Spectrographs · Monochromators 111 Highland Drive · Putnam, CT · 06260 · USA PHONE (860) 928-5834· FAX (860) 928-2676 http://www.spectralproducts.com Operation [Front] Driving voltage (%) Indicator Thumb Screws (4) *Remove thumb screws to replace... - Page 7 Spectral Products Spectrometers · Spectrophotometers · Color Instruments · Spectrographs · Monochromators 111 Highland Drive · Putnam, CT · 06260 · USA PHONE (860) 928-5834· FAX (860) 928-2676 http://www.spectralproducts.com Relationship Curves for ASNM-W-PV The following curves show the relationship between the driving voltage setting and the color temperature/current/luminous power/lifetime on/off the lamp.
-
Page 8: Bulb Replacement
Spectral Products Spectrometers · Spectrophotometers · Color Instruments · Spectrographs · Monochromators 111 Highland Drive · Putnam, CT · 06260 · USA PHONE (860) 928-5834· FAX (860) 928-2676 http://www.spectralproducts.com Bulb Replacement Replacing the Tungsten-Halogen bulb 1. Turn off all power. - Page 9 Spectral Products Spectrometers · Spectrophotometers · Color Instruments · Spectrographs · Monochromators 111 Highland Drive · Putnam, CT · 06260 · USA PHONE (860) 928-5834· FAX (860) 928-2676 http://www.spectralproducts.com Collimating output option NOTE: All the optical components were properly aligned by SP. Do not touch any...
-
Page 10: Technical Support
Spectral Products Spectrometers · Spectrophotometers · Color Instruments · Spectrographs · Monochromators 111 Highland Drive · Putnam, CT · 06260 · USA PHONE (860) 928-5834· FAX (860) 928-2676 http://www.spectralproducts.com Technical Support Toll Free: (877) 928-5834 Tel: (860) 928-5834 Fax: (860) 928-2676 Website: http://www.spectralproducts.com...
