Summary of Contents for Stealth Products Simple Solutions Lexan Tray
- Page 1 Mounting Hardware OWNER MANUAL Simple Solutions Tray Simple Solutions Lexan Tray Owner’s Manual...
-
Page 2: Customer Satisfaction
Customer Satisfaction Stealth Products strives for 100% customer satisfaction. Your complete satisfaction is important. Please contact us with feedback or suggested changes that will help improve the quality and usability of our products. You may reach us at: Stealth Products, LLC... - Page 3 Important Information Important Information! All persons responsible for fitting, adjustment, and daily use of the devices discussed in these instructions must be familiar with and understand all safety aspects of the devices mentioned. In order for our products to be used succesfully, you must: •...
-
Page 4: Introduction
Introduction The installation instructions will guide you through the options and possibilities with the product. Instructions are written with the expressed intent of use with standard configurations. They also contain important safety and maintenance information, as well as describe possible problems that can arise during use. For further assistance, or more advanced applications, please contact your supplier or Stealth Products at 1-512-715-9995 or toll free at 1-800-965-9229. -
Page 5: Warranty
In the event of product failure covered by our warranty, please follow the procedures outlined below: Call Stealth Products at +1 (512) 715-9995 or toll free at +1 (800) 965-9229. Request the Returns Department or obtain a Return Authorization (RA) from the Returns... -
Page 6: Table Of Contents
Table of Contents 1.0 Customer Satisfaction ................. i 2.0 Important Information ................ii 3.0 Introduction ....................iii 4.0 Warranty ..................... iv 5.0 Table of Contents ..................v 6.0 Warning Labels ..................vii 6.1 Warning Labels ......................vii 6.2 Limited Liability ......................vii 6.3 Testing ..........................vii 7.0 Safety Precautions ................... - Page 7 Table of Contents 12.0 Installation Instructions ................5 12.1 Preparations ........................5 12.2 Tools..........................5 12.3 Installation Plan ......................5 12.4 Required Tools/ Torque Chart ................6 12.5 Installing the Tray ......................7 13.0 Adjustments ....................8 13.1 Depth Adjustment .....................8 13.2 Horizontal Adjustment ....................8 13.0 First Time Use ....................
-
Page 8: Warning Labels
Stealth Products does not hold responsibility for final integration of final assembly of product to end user. Stealth Products is not liable for user death or injury. Testing Initial setup and driving should be done in an open area free of obstacles until the user is fully capable of driving safely. -
Page 9: Safety Precautions
Safety Precautions General Safety Guidelines WARNING Ensure the user does not rest forearms on the edge of the tray as it can cause soreness to the user’s forearms. WARNING The tray should be removed during transportation or driving of the chair. WARNING Care should be taken when swinging the tray to the side so as to not strike the user, or damage the tray. -
Page 10: Design And Function
Design and Function Intended Use The Simple Solutions Tray does away with the need for a user to pull under a table to participate in independent ‘activities of daily life’. Mounting screws are flush to the surface of the tray to provide a flat writing and work surface for the user. -
Page 11: Parts And Accessories
Parts and Accessories Parts and Accessories Breakdown A typical Simple Solutions Tray package comes with: 1. Tray • Composed of shatter resistant polycarbonate material with better impact resistance and light transmission than most glass. Polycarbonate is safe, durable, and lightweight. 2. - Page 12 Installation Instructions...
-
Page 13: Hardware Parts
Parts and Accessories Hardware Parts Description Qty. Mounting Screws M5 X 0.8 X 20MM FHS Tray Simple Solutions Tray Hardware Swing Away Hardware Note: The size and shape of the tray will vary... -
Page 14: Installation Instructions
Installation Instructions 10.0 Preparations 10.1 Only a qualified service technician may install the Simple Solutions Tray. WARNING An incorrect installation of the Simple Solutions Tray may cause damage to the hardware and/or injury to the user. Tools 10.2 Use the proper tools to install and adjust the Simple Solutions Tray to the desired position for the user. -
Page 15: Required Tools/ Torque Chart
Installation Instructions 10.0 Required Tools 10.4 The tools needed to complete the installation of the tray is as follows: Hardware Description 3mm T-Handle Lateral Mounting (F1) 4mm T-Handle Button Head Screws on Lateral Bracket (E1) Tools are not provided. Screws Torque Specifications M5 X 0.8 X 20MM Flat Head Screw 6.9nM... -
Page 16: Installing The Tray
Installation Instructions 10.0 Installing the Tray 10.5 Step One: Place the plastic tray over the mounting brackets. Align the holes of the plastic tray with the bracket holes. Step Two: Using a 3mm T-Handle, tighten the M5 x 0.8 x 20mm Flat Head Screws to secure the tray to the hardware. -
Page 17: Adjustments
Adjustments 11.0 Depth Adjustment 11.1 Step One: Loosen the stop collar using a 3mm T-Handle. Step Two: Slide the tray to the correct position for user. Step Three: Slide the stop collar against the cane to prevent unintentional movement of the tray. Lock the stop collar in place by using a 3mm T-Handle. -
Page 18: First Time Use
First Time Use 12.0 Dealer Assistance 12.1 During first time use by the client, it is advised that the dealer or service technician assists and explains the configuration of user positioning to the customer (the user and/or the attendant). If needed, the dealer can make final adjustments. -
Page 19: Maintenance
Maintenance 13.0 Cleaning 13.1 • Wash Lexan Sheet with a mild soap or detergent using a clean sponge or soft cloth • Rinse well with clean water • Do not scrub or use brushes with this product Do not use highly abrasive cleaners. Never scrape with squeegees or razor blades. -
Page 20: Notes
Notes 14.0... - Page 21 Notes 14.0...
- Page 22 Notes 14.0...
- Page 23 Notes 14.0...
- Page 24 Stealth Products, LLC. • info@stealthproducts.com • www.stealthproducts.com +1(800) 965-9229 | +1(512) 715-9995 | 104 John Kelly Drive, Burnet TX 78611 Revision Date 2019-12-17 P144D562D1 UK Tray...
