Summary of Contents for Certon integrita
- Page 1 Manual English Version 1.0 integrita certon systems GmbH Hans-Bunte-Straße 8-10 D-69123 Heidelberg Tel. +49 (0)6221 7590-260 Fax +49 (0)6221 7590-261 E-Mail: info@certon.de www.certon.de Page 1 http://www.certon.de...
-
Page 2: Preface
The Integrita music server • The Integrita music server is a device to store and archive high quality music files, movies and pictures. Network-capable audio and video components can access the data in a simple and easy manner. -
Page 3: Table Of Contents
Back Panel Connectors, Control and Display Elements ..............9 Quickstart .................................. 10 Integrita Control Center: First Steps ........................ 10 Working with the Integrita Control Center ....................10 Registration ................................11 Changing the Password for User ‚admin‘ ....................11 Call up Status Information ..........................12 Manage your Users............................ - Page 4 5.20 Integrita Update ..............................24 Working with the Integrita music server ......................26 Find Integrita music server in your Windows Network ............... 26 Find Integrita music server in your Apple Network ................27 Replacing Hard Disk Drives ..........................27 Installing a New Hard Drive ..........................27 Switching off the Integrita music server ....................
-
Page 5: Important Safety Instructions
• The Integrita music server is not splash-proof, so don’t use it in damp or moist rooms. • If you want to give your Integrita music server to a 3rd party, please also hand over the manual. Always connect the Integrita music server to an easily accessible outlet so that it can be unplugged quickly in case of a malfunction. -
Page 6: Repairing
Allow the device to acclimatize for 2 to 4 hours in the operation room and only then switch it on. • The Integrita music server is not waterproof. Never immerse the device in water and protect it from any moisture (rain, splashing water, sea water). -
Page 7: Repair And Modification
• Hardware and insulation conditions are designed to ensure an optimal balance. The improper use of components not certified by the manufacturer may cause serious malfunctions, in which case certon system GmbH accepts no liability. If you have any questions in this regard, please contact the manufacturer. -
Page 8: Technical Data
RAID Mode: RAID 6 Disk Type: Professional AV discs, designed for 24/7 use Power Consumption: Full load: ~58W Power: 100-240V ; 50/60Hz Acoustic: Super silent Technology System requirements: Computer with 10/100/1000Mbit/s Ethernet or DLNA clients Warranty: 2-year warranty www.certon.de Page 8... -
Page 9: Before You Start
3.2.2 Back Panel Connectors, Control and Display Elements On the back of your Integrita music server you find the power supply plug, the main switch, a 1000 Mbit network connection, a USB 3.0 and an e-SATA connection. The following media can be attached: •... -
Page 10: Quickstart
Quickstart • In case you would like to do a quick start with your Integrita music server, please read the following chapter. If problems emerge, please read the corresponding chapters in this manual. • Connect the power plug • Connect the LAN cable to your network. -
Page 11: Registration
Be sure to keep the new password in mind! In case you have forgotten the admin password, you can reset the password via the incremental button: Choose the menu „Password Reset“ in the menue “service“. The new password will again be ‚admin‘. www.certon.de Page 11... -
Page 12: Call Up Status Information
Call up Status Information On the left hand side in your Integrita Control Center you find all the necessary information to check the status of the Integrita music server. At the bottom left, you can see whether a hard disk drive has failed or if your data is still secure. If the system reliability shows 2, your data is perfectly safe. -
Page 13: Manage Your Users
Please keep in mind that user names may not contain uppercase letters. A user name containing uppercase letters will not be created!. Please avoid using capital letters and special characters by using only the 26 lower case letters and the numbers www.certon.de Page 13... -
Page 14: 5.5.2 Change Password By User
No other features are available to him. Manage Folders To serve the disk space of your Integrita music server in the network environment, the network folders have to be shared to the network (These network folders must be generated first). At the same time you can define which user should be able to access the folders and define his read/write permissions. - Page 15 • You should avoid folder names that only differ in capital letters and lower case letters. A folder that contains music can be named e. g. MyMusic. www.certon.de Page 15...
- Page 16 • The folder is available in the network now and users can access from their computer via network. To visualize the availability in the network all connections in the network have to be interrupted temporarily. Ensure that nobody accesses the Integrita music server and select the checkbox. Then click “OK”. www.certon.de...
-
Page 17: Settings
• The menu “Settings” allows you to further adapt the Integrita music server to your individual needs. Language • In the Integrita Control Center you can the language of the Control Center to German, English, Russian or French by clicking on “Language”. Confirm your selection with “OK”. Date and Time Settings •... -
Page 18: Notifications
• If there is no DHCP server available, you manually have to enter the one address in your Integrita music server Control Center that corresponds with the one you found on your PC that matches the first three digit groups. Only the fourth digit group must differ, because every device in your network has to have a unique address. -
Page 19: Media Interface
For example you can play a video that is stored on a DLNA-compatible device on a DLNA-compatible TV. To activate DLNA enter the IP address of your Integrita music server in a browser via the Control Center. -
Page 20: Twonky Mediaserver
On delivery, DLNA is activated on your integrita music server. The DLNA server is „Twonky“. Twonky automatically indexes all multimedia files in your folder „Music“ or “Media”. 5.14 Twonky MediaServer • Twonky MediaServer is a multimedia software to provide your Integrita music server to a multimedia server with uPNP functionality. -
Page 21: Ftp Access
5.15 FTP Access • If you want to access your Integrita music server via FTP, set a checkmark at „FTP activate“. • Click “OK” to confirm the change. 5.16 Activating VPN • If you want to set up VPN (virtual private network), set a checkmark at „Activate VPN interface”. -
Page 22: Expert Mode
• How to activate the Integrita service mode : • Select “Settings”, then click “Service”. A new window will open. • Set a checkmark at „Activate service mode“ and confirm with “OK”. 5.18 Expert Mode • In the Control center select „settings“, then „expert mode“. Here you can adjust the settings for the following functions. -
Page 23: Windows Network Settings (Smb)
5.18.3 Control Center: Settings • Here you can change the time that you want to remain logged on to the Control Center when there is no activity. By default you are logged out automatically after 15 minutes. www.certon.de Page 23... -
Page 24: Integrita Messages
5.20 Integrita Update • At www.certon.de you find the latest updates for your Integrita music server. Only download the latest update if recommended by certon systems or if you’re under the impression that the system doesn’t work properly. Store the update in a folder on your computer. - Page 25 Integrita music server leads to data loss! • Start the update by clicking on „Update“. • Set the checkmark and then click “OK”. Your data and settings remain unchanged. After reboot you can access your Integrita music server as usual. www.certon.de...
-
Page 26: Working With The Integrita Music Server
Find Integrita music server in your Windows Network • If you want to access the Integrita music server via a Windows PC, you can find the Integrita music server in the network environment. Select “My Computer”, click “Start”, then “Network environment”. -
Page 27: Find Integrita Music Server In Your Apple Network
• Choose “Finder” and click “Go To”, then select” Connect to server”. • In the line “Server Address” enter the IP address of your Integrita music servers and click on “Search”. • Now a window opens that shows all available shares (also called network files or volumes). -
Page 28: Switching Off The Integrita Music Server
Switching off the Integrita music server • To switch off the Integrita music server briefly press the On/Off-Button on front. The Integrita music server automatically shuts down. In general it makes sense to switch the Integrita music server off if not in use. - Page 29 Further or other claims resulting out of or in connection with the device shall be excluded from this Guarantee. certon systems GmbH is not liable for interruption of operation, loss of data, loss of profits, loss of software or other data. The liability exclusions and limitations do not relate to claims of the Customer in the event of mandatory liability under the German Product Liability Act.
