Electric Dual Motor Sit-Stand Desk Frame Corner
Desktop Dimensions: 124-187cm, 140-208cm
●
4 Height Position Memory
●
Vertical Range: 60 -125 cm
●
AVLT-MT30-1
AP4-0085A
Power Input
Max.Speed
110V
25 mm/s
SCREWS/FASTENERS (BAG)
M5×16 screws
A
(2pcs extra)
M6×12 screws
B
(2pcs extra)
C
Foot pads
D
M6×35 screws
S=4mm
E
RATED
Motion Noise
Load Capability
＜55dB
264 lbs / 120 kg
27pcs
48pcs
6pcs
6pcs
1pc
PARTS INCLUDED
10
9
8
5
D
6
3
1
A
7
B
12
4
2
C
INSTALLATION
1
Attach the adjusting foot(C) to the feet (2) ,
connect the table leg (4) to the feet (2), and
fasten the screw (B) with the wrench (E).
C Foot pads 6PCS
2 Feet 3PCS
E
S=4mm
B
M6x12 SCREW 12PCS
2 FOOT 3PCS
4 Table legs
3PCS
Desk Parts
1.
Side plates
2.
Feet
3.
Connecting rods
4.
Table legs
5.
Connection line (long)
6.
Connection lines (short)
11
13
7.
Frames 1
8.
Controller box
9.
Power cord
10.
Table board connection board
11.
Frames 2
Controllers panel
12.
Desktop
13.
(Optional)
(not included)
2
Mount the frame 1 (7) and use the wrench (E)
to lock the screw (B)
E
S=4mm
7 Frame（1）
2PCS
B
M6x12 SCREW
8PCS
2 PCS
1 Side plates 2PCS
E
S=4mm
M6x12 SCREW
8PCS
3pcs
3pcs
4pcs
3pcs
1pc
2pc
3
p
s c
1pc
1pc
2pcs
1pc
1pc
2pcs
B
2 PCS
Advertisement
Related Manuals for AvLab AVLT-MT30-1
Summary of Contents for AvLab AVLT-MT30-1
- Page 1 (not included) ● INSTALLATION Attach the adjusting foot(C) to the feet (2) , Mount the frame 1 (7) and use the wrench (E) AVLT-MT30-1 connect the table leg (4) to the feet (2), and to lock the screw (B) RATED AP4-0085A fasten the screw (B) with the wrench (E).
- Page 2 OPERATION INSTALLATION Mount the desktop (13) with screws (A) on the two side plates Fix the frame 1 (7) with screws (B) Fix the frame 2 (11) with screws (D) Secure the side plate (1) with screws (D) M6x35 SCREW 6PCS Press and display real height M6x12 SCREW...
