- Page 1 AGROW FLEXIROLLER OPERATOR’S MANUAL AF8000 through to AF12000 3pt Link FLEXIROLLER 2015 AGROWPLOW | 55 Wellington St, Molong NSW...
-
Page 2: Contact Details
Contact Details Agrowplow Pty Ltd Postal/Office: 55 Wellington St Molong NSW 2866 Phone: 1300 722 491 Fax: 1300 721 746 Email: agrowplow@agrowplow.com Web: www.agrowplow.com Local Agrowplow Dealer: ‘Prosperity Through Soil Care’ A g r o w p l o w O p e r a t o r s M a n u a l... -
Page 3: Disclaimer
Every effort has been made to ensure that the information in this manual was accurate and up to date at the time of printing. Agrowplow Pty Ltd reserves the right to make subsequent changes to the machine or this manual, where necessary, without notification. -
Page 4: The Owner's Manual
The manual is considered as part of your machine and must remain with the machine when it is sold. Delivery Inspection On delivery of your new Agrowplow machinery please check that the machine is not damaged. In cases of shipping damage, please ask your dealer to arrange for the appropriate claim to be lodged immediately. -
Page 5: Table Of Contents
The Owner’s Manual ................................4 Delivery Inspection ................................. 4 Table of Contents ................................5 Agrowplow – Company Profile ............................6 Warranty Policy .................................. 7 Conditions of Warranty ..............................7 Completing Safe Use Instruction (SUI) & Pre Delivery Inspection (PDI) Reports ............9 Safety ................................... -
Page 6: Agrowplow - Company Profile
The founders of Agrowplow had the foresight to see that farmers needed to improve their practices - to improve soil structure, increase humus and allow more water to infiltrate and store in the soil - if farming was to be sustainable. -
Page 7: Warranty Policy
The Safe Use Inspection (SUI) and Pre Delivery Inspection (PDI) Forms must be filled in and returned to Agrowplow by the Dealer or Agrowplow representative within seven days of delivery and installation of the unit. By signing the SUI &... - Page 8 With proper training of service personnel, diagnostic time should be at a minimum. Agrowplow expects that Dealers will assign a well trained and proficient technician to handle warranty repairs.
-
Page 9: Completing Safe Use Instruction (Sui) & Pre Delivery Inspection (Pdi) Reports
The original SUI and PDI forms must be completed, signed and returned to Agrowplow for Warranty to be valid A g r o w p l o w O p e r a t o r s M a n u a l... -
Page 10: Safety
The dealer will explain the capabilities, safe application, service requirements and restrictions of the Flexi Roller and demonstrate the safe operation of the Flexi Roller according to Agrowplow’s instructions. The dealer can also identify unsafe modifications or use of unapproved attachments. -
Page 11: Safety Instructions
1.3 Safety Instructions READ THESE SAFETY INSTRUCTIONS CAREFULLY BEFORE ALLOWING ANY PERSON TO OPERATE THE AGROWDRILL 1. Review this manual before each season of use. 2. Never allow anyone unfamiliar or untrained to operate the implement. 3. Operators must know and abide by any road transport regulations pertinent to the transit of your Flexi Roller. -
Page 12: Risk Assessment
1.4 Risk assessment The table on the next page is a guide to assess the severity of hazards associated with the machines use. The columns listed include: Hazard Type – lists hazards for assessment and notes whether they are relevant to the machine ... - Page 13 HAZARD TYPE CAUSE OF HAZARD RISK CONTROL RISK Determine and apply appropriate risk Is there a potential for injury What is the cause or source ASSESS controls after considering Hierarchy or illness due to … of the hazard … RATING of Risk Control CRUSHING Attachment of machinery to...
-
Page 14: Flexiroller Specifications
2.0 FlexiRoller Specifications Model Transport Width Working Width Weight Number of Rings AF8000 9.0m 8.0m 2400kg AF9140 9.8m 9.14m 2800kg AF12000 12.6m 12.0m 3700kg Flexi Roller Specifications Ring Specifications Outside Diameter: 400mm Inside Diameter: 300mm Width: 60mm Weight: 10kg Optional Equipment Cat III Three Point Linkage Cat IV Three Point Linkage Cat III Three Point Hitch... -
Page 15: Operating Instructions
3.0 Operating Instructions 3.1 Hitching The Flexi Roller should be matched to the tractor size to maximise performance and efficiency. A mismatched tractor and implement will be inefficient and cost money, as well as being unsafe. The three-point linkage lift capacity of the tractor will generally determine the required tractor size. Check the tractor’s operator’s manual for details. -
Page 16: Operating Direction
3.2 Operating Direction The Flexi Roller is a multi purpose unit and can be utilised in either direction. In aggressive mode the Flexi Roller will shatter clods and mulch topsoil. It can also be used to break the crust on newly sown soil after rain. In passive mode the Flexi Roller provides a firming, pressing action. -
Page 17: Operating Height
3.4 Operating Height The Flexi Roller rings are allowed to work up and down in a vertical plane enabling individual contour following. Best results will occur if the entire weight of the machine is rested on the roller rings. Therefore if hydraulic or manual transport kits are fitted the wheels should be raised clear and as high as possible. -
Page 18: Lubrication And Maintenance
4.0 Lubrication and Maintenance The Flexi Roller is an extremely robust and durable machine and will give many years of service with simple routine maintenance. 4.1 Pre-Operation Check Check the following points before operation: Check all nuts and bolts are tight. ... -
Page 19: End Of Season Storage
4.4 End of Season Storage To ensure a long and trouble free working life please take the following steps when storing the Flexi Roller for long periods. To ensure a long and trouble free working life please take the following steps when storing the Flexi Roller for long periods.
