Delta Core GP8 Radio CPL Manual

Energy manager, radio driver
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Delta Dore hereby declares that the equipment complies with
the essential requirements and other relevant provisions of the
R&TTE Directive 1999/5/EC
The EC declaration of conformity for this equipment is available,
on request, from:
"Technical information" department
DELTA DORE - Bonnemain - 35270 Combourg (France)
E-mail : info.techniques@deltadore.com
Because of changes in standards and equipment, the characteristics
given in the text and the illustrations in this document are not binding
unless confirmed.
GP8 Radio CPL
Radio DRIVER
Energy manager
OK
OK
RF RF
Amp.
CE
90
5
75
7,5
63
10
60
15
50
20
45
25
GP8 RADIO CPL
40
35 30

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GP8 Radio CPL and is the answer not in the manual?

Questions and answers

Summary of Contents for Delta Core GP8 Radio CPL

  • Page 1 GP8 Radio CPL Radio DRIVER Energy manager Delta Dore hereby declares that the equipment complies with the essential requirements and other relevant provisions of the R&TTE Directive 1999/5/EC The EC declaration of conformity for this equipment is available, on request, from: RF RF "Technical information"...

  • Page 2: Table Of Contents

    Contents Warning Description ......5 • Carefully read these instructions prior to installa- Positioning the GP8 RADIO PLC ... . 5 tion.

  • Page 3: Description

    Allocation of receivers on a three-phase system . 34 Re-associating PLC receivers ....37 GP8 RADIO CPL 35 30 Associating a PLC receiver for DHW control ..37...

  • Page 4: Connecting The Gp8 Radio Plc

    Installation with an electronic meter Connecting the GP8 RADIO PLC Electronic Note: Please use at least a 10 A circuit breaker to meter protect the power supply of the GP8 RADIO PLC. 230 V supplied between terminals 3 and 4. The Heating powerline carrier signals are received and transmitted power supply...
  • Page 5 Three-phase connection Connecting the GP8 RADIO PLC The phase connected to the meter's Off-Peak Installation with an electromechanical meter contact must be the same as the L1 L2 L3 GP8 RADIO PLC power supply phase. T.I. Meter Meter remote info remote info off-peak contact off-peak...

  • Page 6: Commissioning The Gp8 Radio Plc

    Configuring the load shedding Commissioning the GP8 RADIO PLC Load shedding is configured using switches located on Calibre selection the upper connection terminal of the GP8 RADIO PLC. If your installation is equipped with a Switch 1: Single-phase or three- conventional meter, select one of Circuit phase.

  • Page 7: Mounting/Positioning The Radio Driver

    Attachment with screws Mounting/Positioning the RADIO DRIVER For ease of use, the RADIO•DRIVER can be installed: Attach the base unit using - on the wall, at a height of about 1.5 m, with screws and plugs suitable for screws/plugs, the mounting surface or to a - on a base, placed on a piece of furniture or on a flush-mounting box, then close shelf.

  • Page 8: Quick Association Of The Gp8 Plc To The Radio Driver And Plc Receivers

    Press Press Living room 1 RF RF Corridor 1Corridor 2 Bedroom RF RF Amp. The RF 35 30 GP8 RADIO CPL LED flashes Bedroom Press Press Press and hold Bath- until the following for 3 seconds room 1 screen appears...

  • Page 9: Setting The Time On The Radio Driver

    Put the receiver Setting the time on the RADIO DRIVER in association mode (see documentation) Minutes Validate on Press the receiver Days to configure (1: Monday zone 2 to 7: Sunday) Hours to configure Turn the selector dial to zone 3 Load shedding Load shedding The days flash.

  • Page 10: Configuration

    Configuration Basic configurations (menu 1) To enter the configuration menus, Press the button. turn the dial to then press and hold button for 5 seconds. 5 seconds To modify the various settings, press the + or - buttons, The unit will offer a choice of 4 configurations: then press the OK button to confirm and go to the next Unit reference (example: RADIO DRIVER 630) setting.

  • Page 11: Pilot Wire Type Selection

    Advanced configurations (menu 2) 6-order Pilot Wire (default) Pilot Wire Press the button. 4-order Pilot Wire type selection DHW off (default) DHW status in DHW in automatic absence mode After defining the settings for menu 1, the unit goes back To modify the various settings, press the + or - buttons, to the list of menus.

  • Page 12: Pilot Wire Order Selection

    If there is a difference between the actual temperature Advanced configurations (menu 2) (taken with a thermometer) and the temperature meas- ured and displayed by the unit, function 2-02 can be With the tempo rate used to compensate for the difference by changing the Specific to and compatible only with the French elec- way the sensor takes measurements.

  • Page 13: Wireless/Plc Association (Menu R)

    In the 2-06 configuration, the tariff reduction mode Wireless/PLC association (menu R) can never be lower than parameter 2.03 (see table): This menu lets you associate all the installation’s Temporal wireless products (transmitters and receivers) with the Economy Comfort - 2°C Comfort - 1°C (Configuration (Configuration...

  • Page 14: Home Automation Functions In The Installation

    Home automation functions in the Wireless/PLC association (menu R) installation “Consumption meter” function Up to 7 home automation products (alarm control unit, remote controls, etc.) can be associated for each of the If the GP8 RADIO PLC is connected to the electronic heating zones + 7 products to act on all the heating meter, you have access to consumption indication.

  • Page 15: Access To Plc Configuration

    Access to PLC configuration Wireless/PLC association (menu R) Associating a radio transmitter Step 1: Associate the GP8 RADIO PLC with the RADIO DRIVER. Press the button on the GP8 RADIO PLC for 3 seconds until the RF LED flashes slowly. No PLC configuration Press and release the Access to PLC...
  • Page 16 Step 2: Associating the home automation products. Wireless/PLC association (menu R) All zones Transmitter Association Door/window opening detector To be associated zone by zone or for all zones (rAd) Window open: heating in Frost Protection Press the button. mode Telephone transmitter To be associated with all zones (rAd)

  • Page 17: Associating Plc Transmitters

    Transmitter Association Wireless/PLC association (menu R) Press the domain button until the Home automation Associating PLC transmitters remote control remote control emits a beep and symbol flashes. In PLC association, the OK LED of the GP8 RADIO PLC flashes. Associate buttons zone by zone.

  • Page 18: Associating Plc Receivers

    Associating PLC receivers (e.g. TC 51089) Wireless/PLC association (menu R) Programming zone If more than one receiver is associated with the same programming zone, it is recommended that they each Load shedding be given a separate load shedding channel to prevent channel selection simultaneous load shedding (see section on load shed- ding).

  • Page 19: Re-Associating Plc Receivers

    Associating receiver A. Wireless/PLC association (menu R) Programming zone selected: PLC 1. Re-associating a PLC receiver Press + or - to select the load shed- For example, to modify its load shedding channel. ding channel: d=1. • Set the transmitter to PLC association mode On the receiver, the OK LED (zone + load shedding channel).

  • Page 20: Configuration Of The Consumption

    Configuration of the consumption meter function Configuration of the consumption meter function (Menu 3) (Menu 3) Only if the GP8 RADIO PLC is connected to an elec- 3-13 to 3-18 kWh cost (incl. tax) tronic meter. The price displayed is the price per kWh (exclusive of Menus 3-12 to 3-18 are only available if you have subscription) expressed in euros including tax (price declared the consumption meter function in menu R...

  • Page 21: Deleting Wireless Associations

    Specific to and compatible only with the French elec- Deleting wireless associations tronic meter To cancel all wireless associations, turn the selector Configurations 3-13 to 3-18 allow you to modify the dial to , then hold down the button for 5 seconds. costs according to your subscription.

  • Page 22: Restore Factory Settings

    Restore factory settings Wireless test The factory settings may be restored for each of the Turn the selector dial to , then hold down the 2 menus. button from the top for 5 seconds until tESt is displayed. Turn the dial to , then press and hold the button for The RF LED of the GP8 RADIO PLC must flash each...

  • Page 23: Summary Table Of Configurations

    Summary table of configurations Summary table of configurations Type of program Wireless and PLC association (Menu R) 1-01 0 = weekly 1 = daily Home automation functions r-01 No programming 0 = No 1 = Yes 1-02 0 = 1 hour 1 = 30 minutes 2 = 15 minutes Consumption indicators...

  • Page 24: Load Shedding

    Load shedding Technical characteristics Load shedding is used to reduce the contractual • Wireless range: 100 to 300 metres outside, variable demand of the mains supply and to avoid tripping in depending on the associated equipment (the range the event of strong current draws. Load shedding starts can vary depending on the installation conditions and as soon as the total current draw attempts to exceed the electromagnetic environment)

  • Page 25: Help

    GP8 RADIO PLC modular unit Help • 230 V +/-10%, 50 Hz power supply Nothing is displayed on the room unit screen. • Consumption: 4 VA There is no power supply. • Class II insulation Check the batteries. • DHW output: 2A/230V symbol flashes.
  • Page 26 You wish to associate a home automation feature and the screen displays ——. You have reached the maximum number of functions to associate. The four LEDs (OK, RF, are flashing. The GP8 RADIO PLC has not been configured. The unit displays the time and the temperature. The RADIO DRIVER is in standby mode.
