Summary of Contents for Vivaldi V Series
-
Page 2: Table Of Contents
Table of contents INTRODUCTION ............................. 3 VIVALDI PUMPS - TECHNICAL FEATURES ....................4 V ONCERTO ANGE ERIES Exploded view of all models..........................5 GENERAL DIAGRAM OF THE HEATING AND COOLING CIRCUIT............6 Heating mode ...............................6 Cooling mode ................................6 ... -
Page 3: Introduction
Introduction Congratulations for choosing the reversible Vivaldi heat pump for your pool! This equipment has been installed in accordance with current standards and is now ready for use. Carefully read through this documentation to ensure that you know all its rules of operation. -
Page 4: Vivaldi Pumps - Technical Features
When the pump is delivered, check the condition of the packaging. If there is any damage, inform the carrier within 48 hours by registered mail, with acknowledgement of receipt. Before handling, carry a full inspection of the machine. Vivaldi Pumps - technical features Concerto Range Series V Concerto... -
Page 5: Exploded View Of All Models
Vivaldi Pumps - technical features Exploded view of all models Vivaldi Copyright 2012 © V 1.0 5 ... -
Page 6: General Diagram Of The Heating And Cooling Circuit
The 4-way valve reverses the flow of the liquid refrigerant. The fluid evaporates in the heat exchanger (evaporator) by recovering the heat contained in water and then passes through the compressor which heats it. It then passes through the blade radiator (which becomes a condenser) and returns to the liquid state. Vivaldi Copyright 2012 © V 1.0 ... -
Page 7: Control And Safety System
If a fault occurs on one of these devices (system failure, power off, abnormal measurements) an error message appears on the display. See paragraph "Error messages/error fixing" IMPORTANT! Any control or safety system alteration or deactivation may cause serious injury or death. Vivaldi Copyright 2012 © V 1.0 7 ... -
Page 8: Diagrams Of The Electronic Cards
Diagrams of the electronic cards Concerto range – V 30, V 40, V 50, V 60, V 70 Vivaldi Copyright 2012 © V 1.0 8 ... -
Page 9: Heat Pump Installation Rules
The safe distance between the heat pump and the water source (pool, foot bath) must comply with electrical standard C15-100 section 702. The pump must be installed in Volume 2, i.e. at a minimum distance of 2 metres from the pool or footbath, horizontally, and a minimum of 2.5 metres, vertically. –– Vivaldi Copyright 2012 © V 1.0 9 ... -
Page 10: Other Installation Precautions
Volume “2” - Devices are allowed in volume "2", on condition either that they are supplied by SELV or that they are protected by a 30 mA RCD or that they are supplied by an isolating transformer. Vivaldi Copyright 2012 © V 1.0 ... -
Page 11: Electrical Installation
2 x 1.5 + 1.5 V 40 220/-240 2 x 1.5 + 1.5 V 50 220/-240 2 x 2.5 + 2.5 V 60 220/-240 2 x 2.5 + 2.5 V 70 220/-240 12.1 2 x 2.5 + 2.5 Vivaldi Copyright 2012 © V 1.0 11 ... -
Page 12: Filter Pump Servo Control
Electrical hazard. IMPORTANT! Before connecting the pump, check that the supply cable is properly disconnected from the mains. Never connect when it is raining or when the weather is very humid. Vivaldi Copyright 2012 © V 1.0 12 ... -
Page 13: Assembly And Installation Of The Control Box
Connect the white cable to the heat pump – connector in accordance with its direction. 6. Fix the screen to the holder by pressing it gently. 7. Return the connector to the box to protect it. Vivaldi Copyright 2012 © V 1.0 13 ... -
Page 14: Hydraulic Installation
Comply with the instructions on the pump for connection of the necessary water inlet and outlet. Vivaldi Copyright 2012 © V 1.0 14 ... -
Page 15: Bypass (Diverter Valves)
For optimum performance of your heat pump and to minimise frost on the exchanger, adjust the water flow by gradually closing valves 1 and 2, to obtain 1 to 2 degrees difference between the inlet temperature (Temp IN) and the water outlet temperature (Temp OUT) as on the screen below. Isolation of the pump for maintenance Open valve 1, close valves 2 and 3. Disconnect the hydraulic connections. Vivaldi Copyright 2012 © V 1.0 15 ... -
Page 16: Initial Commissioning
8 x 5 x 1.5 x 1 000 = 60 000 litres Starting temperature 15° C Desired temperature 28° C Temperature difference 13° C (28 – 15) Vivaldi pump capacity 12.5 kW Climatic conditions Temperate Protection Bubble cover Pool type: Standard (no overflow) Temperature increase time: 60 000 X 13 X 4.18 / 3 600 / 12.5 = 72.45 hours i.e. -
Page 17: Operating Principle
During defrosting, the pictogram of heating mode (sun) flashes. You can optimize performance based on local weather conditions by changing the settings (2-5) on the control panel. (This setting must be performed by a specialist). Vivaldi Copyright 2012 © V 1.0 17 ... -
Page 18: Description Of The Control Panel
(only for models with this option) On shut-down, the display shows the ambient air temperature and the current mode. Diagram A Select mode Press at any time to toggle between modes. COOLING MODE HEATING MODE AUTO MODE Vivaldi Copyright 2012 © V 1.0 18 ... -
Page 19: Configuration Of The Heat Pump
15° C to 40 ° C 28° C Technician setting A or 10 Shutdown temperature IMPORTANT! Settings 02 to A or 10 must only be handled by a qualified professional. Incorrect setting may permanently damage the heat pump. Vivaldi Copyright 2012 © V 1.0 19 ... -
Page 20: Error Messages/Error Fixing (1)
Have the settings adjusted by a professional. Massive formation of frost on the Have the auto defrost or refrigerant evaporator. settings checked professional. Not enough refrigerant gas. Have it topped up by a refrigeration engineer. Vivaldi Copyright 2012 © V 1.0 20 ... -
Page 21: Error Messages/Error Fixing (2)
Check the voltage in the 4-way valve wiring. If electrical power is present, replace the coil. If the problem persists, have pump checked refrigeration engineer. Insufficient gas charging. Call a refrigeration engineer to have the gas topped up. Vivaldi Copyright 2012 © V 1.0 21 ... -
Page 22: Error Messages/Error Fixing (3)
Temperature between water inlet and outlet. Cause: Too great a difference in temperature between water inlet and outlet. Corrective action: Increase the water flow with the bypass and check the filter pump and filter itself. Vivaldi Copyright 2012 © V 1.0 22 ... -
Page 23: Table Of Error Codes And Corrective Action
1 - Increase the water flow by Flashes eight flow is sufficient cleaning the filter and adjusting times and stops the bypass valves. 2 - Check that the water flow switch connections 2 - Reconnect the switch wires if Vivaldi Copyright 2012 © V 1.0 23 ... - Page 24 PP06. 3 minutes later, the pump will restart. If the pump stops 3 times in error PP06 during 30 minutes, the controller will display error PP05. In this the circuit breaker to the heat pump should be switched off and turned back on so that it can restart. Vivaldi Copyright 2012 © V 1.0 ...
-
Page 25: General Maintenance
Control of water chemistry All Vivaldi heat pumps come standard equipped with a titanium condenser resistant to chemical attack from poorly balanced pool water. However, the other pool or spa equipment can be damaged by water chemistry that does not comply with current standards. -
Page 26: Guarantee
Concerto range V 30, V 40, V 50, V 60 et V 70 Series V Concerto Range Vivaldi heat pumps have a 2 year standard guarantee covering parts, labour and travel (only in France). The compressor is guaranteed for 5 years and the titanium heat exchanger has a lifetime guarantee (excluding problems due to frost) Repairs are carried out on-site. - Page 27 _________ _______________________________________________ Post Code/Town: Pool measurements: __________________________________________________________ Length __________________________________________________________ Width __________________________________________________________ Ave. depth __________________________________________________________ Distributor/installer name: __________________________________________________________ Address: _________ _______________________________________________ Post Code/Town: Pump reference: __________________________________________________________ Model __________________________________________________________ Serial number: __________________________________________________________ Date of installation: Installer stamp: Vivaldi Copyright 2012 © V 1.0 27 ...
-
Page 28: Declaration Of Ec Conformity
NF EN 60335-2-40/A11 Safety of domestic appliances and similar devices. - Safety. - Part 2-40: particular requirements for electrical heat pumps, air conditioners and dehumidifiers (classification index: C73-840/A11). Gif-sur-Yvette, 2 January 2012 Manager Bruce Martin Vivaldi Copyright 2012 © V 1.0 28 ... - Page 29 Vivaldi Copyright 2012 © V 1.0 29 ...
