PARTS AND HARDWARE
Avoid using sharp objects such as a knife to cut open packing as you may accidentally
damage the upholstery.
A. Backrest
B. Seat
2x
2x
D. Bolt M6 x 30
E. Bolt M6 x 35
16x
4x
G. Cushion
H. Table Frame
2x
1x
L. Table
K. Table Bolt
Washer 12x
12x
2-4
C. Arm
4x
F. Chair Washer
20x
I. Table Legs
J. Table Side
2x
2x
M. Allen Key
N. Glass
1x
1x
ASSEMBLY INSTRUCTIONS
Do not fully tighten bolts until assembly is complete.
Attach Arm sides ( C) to back rest (A) and Seat (B) using bolts (D) and washers (F)
B
F
D
D
Attach Arms (C ) to back rest (A) using bolts (E) and Washers (F)
F
E
M
M
B
C
F
M
C
3-4
Advertisement
Table of Contents
Related Manuals for DH Casual DAYTONA
Summary of Contents for DH Casual DAYTONA
- Page 1 ASSEMBLY INSTRUCTIONS PARTS AND HARDWARE Avoid using sharp objects such as a knife to cut open packing as you may accidentally Do not fully tighten bolts until assembly is complete. damage the upholstery. Attach Arm sides ( C) to back rest (A) and Seat (B) using bolts (D) and washers (F) A.
- Page 2 Attache Table legs (I) to table Frame (H) and Table Sides (J) using Bolts (K) and washers (L), Place table glass onto of table frame once assembled Date of Purchase: DAYTONA 3 PC SET Place Cushions onto assembled chair frames and enjoy your new outdoor seating.
