Page 1: Table Of Contents
Introduction ..............................1 The Design Minds Behind the Monster PowerSource ..................3 Content Checklist .............................4 Hookup Guide ..............................5 Grounding Your Cable TV, Satellite Dish, and Antenna Connections..............15 HTPS 7000 Features ............................16 Troubleshooting ..............................21 Frequently Asked Questions ..........................25 Appendices Glossary of Terms ............................27 Warranty Information ..........................29...
Page 2: Important Safety Precautions
IMPORTANT SAFETY PRECAUTIONS Please read and observe the following safety points at all times. WARNING - Power Sources Do not plug your Monster PowerSource into a power outlet that differs from the source indicated for safe use on the Monster PowerSource. if you don't know the type of electrical power that is supplied to your home, please consult your local power company.
Page 3 WARNING - Liquid: Avoiding Electrical Shocks Do not operate your Monster PowerSource if liquid of any kind is spilled onto or inside the unit. Do not operate your Monster PowerSource near rain or water that's spilled or openly exposed (e.g., bathtub, kitchen or bathroom sink).
Page 4 WARNING - Storm Precautions In the event of a lightning storm, immediately disconnect your Monster PowerSource from its power source. After you've done this, it's not necessary to disconnect any components from your Monster PowerSource. WARNING - No User Serviceable Parts Inside If, for any reason, your Monster PowerCenter is not operating properly, do not remove any part of the unit (cover, etc.) For repair.
Page 5: Proper Grounding And Installation Tips
(no ground or reverse polarity), the green "SYSTEM GROUNDED" LED light on the front panel of the Home Theatre Reference PowerSource HTPS 7000 will not light up. In this event, call a qualified electrician to fix the problem in your home's wiring.
Page 6: Introduction
INTRODUCTION Thank You Thank you for purchasing Monster Power's Home Theatre Reference PowerSource HTPS 7000. The PowerSource reflects Monster's commitment to creating performance-enhancing solutions for home theater systems, so you will enjoy superior picture and sound quality. Ordinary AC power accessories compromise the quality of the components they power. The PowerSource's advanced technologies and innovative design solve this problem and offer several unique convenience and performance features.
Page 7 AC powerline. Also, the higher the Clean Power stage, the more isolation between connected equipment for maximum component-generated noise rejection. HTPS 7000 features Clean Power Stage 5 with balance transformers for the best possible performance. Clean Power Stage 5:...
Page 8: The Design Minds Behind The Monster Powersource
-There are few experts able to solve the complex problems of AC power Richard Marsh is one of the illustrious few. He has designed best selling power conditioning components costing more than $3,000 and now brings his expertise to Monster Power. Richard developed Monster's exclusive Clean Power circuitry.
Page 9: Content Checklist
Monster PowerSource. You'll need the following items to get started: This owner's manual. Your favorite pen or a computer with an Internet browser (for registering your warranty information). One Monster Power Home Theatre Reference PowerSource HTPS 7000. One sheet of Monster Power audio/video ID labels (included).
Page 10: Hookup Guide
FOR PAY-PER-VIEW DEVICES (SUCH AS DSS) Connect one end of a phone cable into a telephone wall jack. Plug the other end into the HTPS 7000 "IN" jack (figure 1a). Connect a second phone cable from the HTPS 7000 "OUT" jack to the Pay-Per-View input on your DSS receiver or DVD player (figure 1b).
Page 11 STEP 2 Outlet Programming All PowerSource's outlets located on the rear panel are "programmable". This means in order to program each outlet pair, you must use the front panel buttons "MENU" and "SET" (figure 2). These buttons enable you to program between "switched on", "switched on after delay"...
Page 12 C) Set Outlet Pair to "Switched On After Delay": Press "MENU" until the display shows the status of AUDIO outlet pair. Press "SET" button until the DELAY TIME changes to the desired DELAY TIME in second(s) before this outlet pair will turn on after the "ON/OFF"...
Page 13 STEP 3 Remote AC Control Hookups This feature allows you to turn your PowerSource on/off via your A/V receiver or preamplifier. Plug the Remote AC Control Cord's (included) female end into your PowerSource's REMOTE IN AC 120V jack (see diagram below). Plug the Remote AC Control Cord's 2-prong male end into a switched AC power outlet on a receiver or preamplifier.
Page 14 STEP 4 Remote DC Control Hookups This feature allows you to turn your PowerSource on/off via your Home Automated Control System. A component you don't want powered constantly (such as your projector or surround amplifier) can be plugged into one of the PowerSource's outlets programmed as "switched on"...
Page 15 STEP 5 Coaxial Outlet Hookup NOTE: You will need additional coaxial cables to connect the PowerSource to your components. Protect Cable TV, Satellite, and Antenna Connections as Follows: CABLE TV From grounding block To TV, VCR, or cable box (connected to in coming cable TV line) SATELLITE From grounding block to satellite receiver To satellite receiver “DISH IN”...
Page 16 This way, power amplifiers are turned on last and turned off first, preventing speaker "thump". See "STEP 2: Outlet Programming" (page 6) for details. Attach a Monster Power ID label to each component's power cord before you plug it into the appropriate color-coded PowerSource outlet.
Page 17 "unswitched". You can plug any type of analog video component (e.g., VCR, camcorder, TV, receiver into these two Video AC outlets. Attach a Monster Power ID label to each component's power cord before you plug it into the appropriate color-coded PowerSource outlet.
Page 18 You can plug any type of digital component (e.g., CD player, DVD player, cable TV box, MiniDisc player, digital camcorder) into the corresponding CD, DVD, CABLE/SAT, SPARE outlet. Attach a Monster Power ID label to each component's power cord before you plug it into the appropriate color-coded PowerSource outlet.
Page 19 You can plug any type of low current analog audio component (e.g., preamplifier, tape deck) into the corresponding PREAMP or SPARE outlet. Attach a Monster Power ID label to each component's power cord before you plug it into the appropriate color-coded PowerSource outlet.
Page 20: Grounding Your Cable Tv, Satellite Dish, And Antenna Connections
GROUNDING YOUR CABLE TV, SATELLITE DISH, AND ANTENNA CONNECTIONS IMPORTANT NOTE: Proper grounding can be accomplished by using a special grounding block attached to a cold water pipe or copper ground rod driven into the ground. Consult with a qualified electrician to verify your outdoor connections are grounded properly.
Page 21: Htps 7000 Features
HTPS 7000 FEATURES PLEASE TURN TO PAGE 17-20 FOR DESCRIPTION OF PRODUCT FEATURES Digital Filter High Power Audio FIlter Video FIlter CABLE TV PHONE DC IN 3-30V GROUND SATELLITE AC IN 120V BREAKER 15A ANTENNA DC OUT AC 120V REPLACE WITH...
Page 22 Sets the amount of light to the alphanumeric display. Grounded OK LED: Indicates PowerSource is plugged into a properly grounded 120V AC power outlet. Protection ON LED: Indicates Monster Power Surge Protection Circuitry is functioning properly. Clean Power LED: Indicates the unit is powered on. Abnormal Voltage LED: Indicates abnormal line voltage.
Page 23 NUMBERS REFER TO DRAWINGS ON PAGE 16 Digital Filter 2 LED: Indicates the "Digital Filter 2" outlet pair has power. Video Filter LED: Indicates the "Video Filter" outlet pair has power. High Power 1: Indicates the "High Power 1" outlet pair has power. High Power 2: Indicates the "High Power 2"...
Page 24 NUMBERS REFER TO DRAWINGS ON PAGE 16 21. Digital Fuse: This 2A slow blow fuse protects "Digital Filter 1" and "Digital Filter 2" from power overload. Replace only with the same type/rating fuse. 22. Video Filter: Special filter circuit designed to reduce interference (such as wide band noise that would disturb video performance) to your video components.
Page 25 Protects the PowerSource from power overload. 35. Extra-long 8 ft. Ultra-High Current Powerline- Power Cord: For maximum power delivery and easy reach to outlets. 36. Monster Power Color-Coded Audio/Video ID labels: For easy identification of your components and where they're connected.
Page 26: Troubleshooting
TROUBLESHOOTING PROBLEM - The PowerSource is not receiving power. Possible Cause #1 The PowerSource is not turned on. Possible Solutions •Press the ON/OFF button on the PowerSource. •Make sure the PowerSource's AC power plug is plugged into a properly grounded 120V wall outlet. •In some households, a wall switch may need to be thrown to make the wall outlet come alive.
Page 27 TROUBLESHOOTING (continued) Possible Cause #3 The PowerSource's power cord is plugged into an outlet on the back of one of your components and the component is not turned On. Possible Solution •Turn on the component. NOTE: For the best possible performance, plug the PowerSource into a wall outlet, not an outlet on another component. Possible Cause #4 The PowerSource is defective.
Page 28 TROUBLESHOOTING (continued) Possible Cause #2 PowerSource is plugged into a switched outlet on a component which is not turned on. The PowerSource will not receive power and therefore will not provide power to the components plugged into the PowerSource's outlets. Possible Solution •Turn on the component.
Page 29 TROUBLESHOOTING (continued) PROBLEM - The "GROUND OK" LED is off. Possible Cause The PowerSource is not plugged into a properly grounded AC outlet. Possible Solution •Plug the PowerSource into a properly grounded 120V outlet.
Page 30: Frequently Asked Questions
FREQUENTLY ASKED QUESTIONS Q. What is the importance of component-to-component filtering? With the Monster PowerSource, AC power must first go through a segment of noise filters, which isolates your equipment from noise on the AC power line. Most manufacturers' battles against line noise stops there. The next crucial step of noise filtering must occur between components.
Page 31 FREQUENTLY ASKED QUESTIONS Q. Will it harm a component to plug it into an outlet that it's not designated to power, like a high power amplifier into an outlet marked for TV? No. However, you may not realize the full performance potential of the component. Q.
Page 32: Appendices A. Glossary Of Terms
Clean Power : Noise filtering designed exclusively for Monster Power products by renowned engineer/inventor Richard Marsh. Filters out unwanted interference caused by RFI, EMI, and component-generated noise, so components plugged into a PowerSource can deliver maximum performance without noise entering their signal path.
Page 33 Hertz (Hz): A unit of frequency equal to one cycle per second. Joule Rating: A measurement of how much surge can be absorbed by a surge suppressor device. The higher the joule rating, the more surge it can absorb. Peak Current: The maximum current which flows during a complete cycle without permanent change in breakdown ratings or published life specifications.
Page 34: Warranty Information
APPENDIX B Warranty Information Monster Cable Products, Inc. warrants that this product shall be free of defects in materials and workmanship under normal use for its lifetime. This warranty extends only to the original purchaser and is nontransferable. During the warranty period, Monster Cable Products, Inc.
Page 35 THE ABOVE ARE IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING IMPLIED WARRANTY OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL MONSTER CABLE PRODUCTS, INC. BE LIABLE FOR SPECIAL, INCIDENTAL, CONSEQUENTIAL OR INDIRECT DAMAGES. Product Warranty Home Theatre Reference PowerSource HTPS 7000 offers a Lifetime Product Warranty.
Page 36 CONNECTED EQUIPMENT CLAIM How To Make A Claim In the event damage has occurred to equipment which is properly connected to a Monster Power product as a result of an abnormally high voltage spike, you must follow these instructions. Call 877/800-8989.
Page 37 If it is determined that the damage was caused by the Monster Power product, Monster Cable Products, Inc., at its discretion, will direct you to: Obtain a repair estimate at a service center authorized by the manufacturer of the connected equipment;...
Page 38: How To Contact Us
APPENDIX C How to Contact Us Write to us at: Monster Power C/O Monster Cable Products, Inc. 455 Valley Drive Brisbane, CA 94005 Visit us on the web at: monstercable.com Call us toll-free at: 877/800-8989...
Page 39: Warranty Registration
Daytime Phone Number (with area and/or country code) Evening Phone Number (with area and/or country code) Name and Location of Dealer Monster Power Model Purchased Serial Number Other Monster Power and/or Monster Cable Products Used 1. How did you hear about Monster Power? Salesperson Friend Newspaper/Magazine Advertisement...
Page 40 16. Do you buy ... DVDs Video Tapes laser Discs 17. If you could suggest a new Monster Power product or an improvement to one or more of our existing products, what would it be? Monster Power Please return warranty registration to:...
