Instruction Manual
The IRB-MON thru beam infrared photoeye is an external entrapment protection device type B1,
non-contact sensor for use with automatic gates and doors. The photoeye provides a signal to the gate
or door operator that the beam is or is not obstructed. The IRB-MON operates up to 115 feet over a
wide range of input voltages (6-35 VDC and 12-24 VAC).
provides status information at a glance, making set-up and alignment easy. The IRB-MON provides
compatibility with most operators that accommodate monitored external entrapment devices per UL325.
Cautions and Warnings
This product is an accessory or part of a system.
instructions from the gate or door operator manufacturer. Comply with all applicable codes
and safety regulations.
Specifications
Operating Range
Power
Current (NC and 10K Monitoring Methods)
Current (Pulse Monitoring Methods)
Surge Protection
Relay Output Operation
Relay Output Configuration
Transmitter Power Cycle
Operating Temperature
Dimensions (L x W x H)
Environmental Rating
Ordering Information
IRB-MON KIT
•
IRB-HD-SET
•
IRB-SH-SET
•
EMX Industries, Inc.
IRB-MON_Rev3.3_072720
IRB-MON
™
Universal UL325 Thru Beam Photoeye
Thru beam photoeye kit, includes transmitter, receiver, protective hoods,
and sunshield
Gold anodized aluminum protective hoods
Gray powder-coated steel protective hoods
Tech support: 216-518-9889
technical@emxinc.com
A green alignment indicator on the receiver
Install the IRB-MON according to
Up to 115 ft (35 m)
6-35 VDC, 12-24 VAC
60 mA (relay activated)
ononly)
15 mA
Thermal fuse
Monitored normally closed, or normally open
Form C contacts (NO, COM, NC)
10K
<300 mS (for use in NC or 10K monitoring)
-40° to 170°F (-40° to 77°C)
2.3" (57 mm) x 2.6" (65 mm) x 3.7" (94 mm)
NEMA 4X
TM
1/6
Advertisement
Table of Contents
Summary of Contents for EMX IRB-MON
- Page 1 The photoeye provides a signal to the gate or door operator that the beam is or is not obstructed. The IRB-MON operates up to 115 feet over a wide range of input voltages (6-35 VDC and 12-24 VAC).
- Page 2 0Hz obstructed over the receiver input power supply lines Two-Wire Pulse, 3 Frequency (Wiring Diagram D): Provides 300Hz “heartbeat” unobstructed, • 2Hz obstructed, and 0Hz when failure is detected, over the receiver input power supply lines Board Diagram EMX Industries, Inc. Tech support: 216-518-9889 IRB-MON_Rev3.3_072720 technical@emxinc.com...
- Page 3 Then increase sensitivity setting one quarter turn. Confirm receiver LED is still on. 9. Place an obstruction (ex. hand) between the IRB-MON transmitter and receiver. The green LED on the receiver will flash. Check the operator control board and verify that the safety input is recognized by the operator.
- Page 4 Note: If using the IRB-MON in an application that does not require UL325 monitoring across the normally open contact, it is possible to disable the 10K resistor by using Wiring Diagram A DIP switch setting, but connect to N.O.
- Page 5 Wiring Diagram A: Wiring Diagram B: Normally Closed 10K Resistive Termination *If using the IRB-MON in an application that does not require UL325 monitoring across the normally open contact, it is possible to disable the 10K resistor by using Wiring Diagram A DIP switch setting, but connect to N.O.
- Page 6 Warranty EMX Industries, Inc. products have a warranty against defects in materials and workmanship for a period of two years from date of sale to our customer. EMX Industries, Inc. Tech support: 216-518-9889 IRB-MON_Rev3.3_072720...
