Summary of Contents for Trelawny MHS11
- Page 1 MHS11 MULTI-HEADED SCABBLER OPERATION & MAINTENANCE...
- Page 2 Do not drag this tool by the air hose. Preferably, the compressor should be able to Trelawny SPT Ltd disclaims all responsibility Do not use petrol (gasoline), thinners or any supply a minimum of 33L/s (70cfm) free air. In for damage to persons or objects arising as a other high flash point solvent to clean the tool.
- Page 3 (39). Lower the exhaust screws and lift the head clear of the cylinder recommended that a Trelawny recommended chamber (46) into position with the cavity block. Take care when removing the cylinder vacuum system be connected to the vacuum nearest the block (45), Fit new brush seals head as it weighs 16.4kg (36.0lbs), take...
- Page 4 SERVICING continued Long period storage: over 3months After 6 months have elapsed, check the Machine storage Clean outside of machine, inspect the cutter condition of the hose then insert a liberal Short period storage: up to 3months. heads for wear; replace any worn parts as quantity of air tool oil into the air inlet as Clean the outside of the machine and inspect required.
- Page 5 SERVICING continued Exploded View 2 PART NUMBER LIST Item No Part No Description Item No Part No Description 490.0200 Hand Grip (set of 2) 809.0500 Cylinder 'O'Ring - Prior Nov 2013 x 11 422.0120 Prior 2010 - Handle Assembly 809.0269 Cylinder 'O'Ring - After Nov 2013 x11 422.0125 2010 onwards - Handle Assembly...
- Page 6 5.0m/s (K= +40% -0%) Trelawny SPT Ltd operates a policy of continuous product development and refinement and therefore reserves the right to change technical specifications and product designs without giving prior notice. *These values are guidelines only. Test concrete surface was one year old and the finish produced suitable for keying additional layers. The aggregate was exposed but not severely damaged or disturbed.
