- Page 1 ROTARY MOWER FA ● FA XL ● FAG USER MANUAL P. de Heus en Zonen Greup B.V. Stougjesdijk 153 3271 KB Mijnsheerenland The Netherlands Tel: +31 (0) 18 66 12 333 E-mail: info@boxeragri.nl...
- Page 2 ENG | ENGLISH TRANSLATION OF THE ORIGINAL MANUAL ROTARY MOWER | User manual December 2020...
-
Page 3: Table Of Contents
CONTENTS USING THE MOWER (FA1200, FA1500, FA1500XL, FA1800, FA1800XL or FA2100XL) ....4 SAFETY INSTRUCTIONS ....................... 5 PUTTING INTO OPERATION / OPERATING INSTRUCTIONS ............6 WORKING METHOD AND USE OF THE MOWER ................7 STORAGE, MOVING AND DEPLOYABILITY ................... 8 MAINTENANCE AND REPAIRS ..................... -
Page 4: Using The Mower (Fa1200, Fa1500, Fa1500Xl, Fa1800, Fa1800Xl Or Fa2100Xl)
USING THE MOWER (FA1200, FA1500, FA1500XL, FA1800, FA1800XL or FA2100XL) • The mower must be connected to the tractor or a comparable piece of equipment (hereinafter called the machine) using a three-point mounting frame. • The working width is determined by the type and identifier of the mower. •... -
Page 5: Safety Instructions
SAFETY INSTRUCTIONS The safety instructions below and the instructions given in the BOXER manual must be observed: • The capacity and the stability of the machine to which the mower is connected must be adjusted to the mower on the basis of 540 rpm (PTO). •... -
Page 6: Putting Into Operation / Operating Instructions
PUTTING INTO OPERATION / OPERATING INSTRUCTIONS Before connecting the mower to the machine mechanically, the following must be checked: • Whether the machine has sufficient capacity in all situations that may arise. • Whether the connection points to be secured on the mower match the connection points on the machine. •... -
Page 7: Working Method And Use Of The Mower
WORKING METHOD AND USE OF THE MOWER Prior to use, the safety instructions given in Chapter 2 must be observed! • Only work with coupling rods that move freely upward such that the mower runs horizontally and on its own four swivel casters. -
Page 8: Storage, Moving And Deployability
STORAGE, MOVING AND DEPLOYABILITY When storing the mower, make sure that the blades are free of any obstacle. Moving the mower on the swivel casters is only permitted on a paved surface. Do not stand on the machine when moving it. The power take-off must be fastened securely to the frame to prevent the possibility of a hand getting caught. -
Page 9: Maintenance And Repairs
MAINTENANCE AND REPAIRS • Maintenance and repairs must be done by a competent person. • When replacing the blades, make sure that the same blade lengths are installed across from one another to prevent imbalance! • After every working day, the mower must be cleaned carefully so that no grass and/or sand residue remains stuck anywhere on the system and hardens. -
Page 10: Regular Maintenance: Every 50 Hours Of Operation
Regular maintenance: every 50 hours of operation Check the oil level of the gearbox and, if required, top it up. Check the V-belt drive units and, if required, replace them. V-belt drive units Disconnect the mower from the tractor. Loosen the housing. Loosen the gearbox. -
Page 11: Disposal And The Environment
DISPOSAL AND THE ENVIRONMENT If the mower is no longer suitable for further use, the hydraulic hoses must be removed and the hydraulic oil must be drained. Each of the sorted materials must be offered separately to the relevant authorities/companies. Page 11/14 ROTARY MOWER | User manual December 2020... -
Page 12: Figures
FIGURES FA model FA XL model FAG model Page 12/14 ROTARY MOWER | User manual December 2020... -
Page 13: Technical File
TECHNICAL FILE The technical file, detailed drawings, structural calculations and original CE declaration of conformity are available for inspection at the office of the supplier/manufacturer. Page 13/14 ROTARY MOWER | User manual December 2020... -
Page 14: 10. Ce Declaration Of Conformity
10. CE DECLARATION OF CONFORMITY Boxer Agriculture Equipment B.V A member of de Heus group Stougjesdijk 153 3271KB Mijnsheerenland Holland Tel: +31 186 612 333 e-mail : info@boxeragri.nl EG Conformiteitsverklaring Volgens machinerichtlijn 2006/42/CE Konformitätserklärung Entsprechend der Richtlinie 2006/42/CE EEC Declaration of Conformity Conforming to the Directive 2006/42/CE Déclaration CE de Conformité...
