Air Vantage Tools AU-001003 Instruction Manual

Electric belt sander 1/2 in. x 18 in. (12.7 mm x 457.2 mm), 20,000 rpm(/min), 4637 sfpm (1413 smpm)
Hide thumbs
1
2
3
4
5
6
7
8
9
Table of Contents

Advertisement

Quick Links

Download this manual
INSTRUCTION MANUAL
ElECTRIC BELT SANDER
1/2 in. x 18 in. (12.7 mm x 457.2 mm)
20,000 RPM(/min), 4637 SFPM (1413 SMPM)
WARNING:
For your personal safety, READ and UNDERSTAND before using.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
Original Instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AU-001003 and is the answer not in the manual?

Questions and answers

Summary of Contents for Air Vantage Tools AU-001003

  • Page 1 Original Instructions INSTRUCTION MANUAL ElECTRIC BELT SANDER 1/2 in. x 18 in. (12.7 mm x 457.2 mm) 20,000 RPM(/min), 4637 SFPM (1413 SMPM) WARNING: For your personal safety, READ and UNDERSTAND before using. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.

  • Page 2: Specifications

    SPECIFICATIONS Voltage 220-240V 110-120V Model AE-001003 AU-001003 Belt Size 1/2 x 18 1/2 x 18 in. (mm) (12.7 x 457.2) (12.7 x 457.2) Motor Speed 20,000 RPM (/min) 20,000 RPM (/min) Belt Speed 4637 (1413) 4637 (1413) SFPM (SMPM) Product Net WT.

  • Page 3: General Safety Rules

    GENERAL SAFETY RULES WARNING : Read all instructions. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. The term “power tool” in all of the warnings listed below refers to your mains-operated (corded) power tool or batteryoperated (cordless) power tool. Please make sure that the side cover has been closed properly before operating.

  • Page 4: Specific Safety Rules

    Contact with a “live” wire will make exposed metal parts of the tool “live” and Designation of Machine: shock the operator. Model No./ Type: AU-001003, AE-001003 2. Ventilate your work area adequately when you perform We : X'POLE PRECISION TOOLS INC sanding operations.
  • Page 5 B-E1BS01-AV-8 Revision : 2018-08...

  • Page 6: Parts List

    PARTS LIST ITEM DESCRIPTION EOSB0049 FILE BELT ARM, (STANDARD STYLE) XPA2031 SPRING,TRACKING BIAS EOSB0009 TRACKING ARM MOUNT EOSB0010 TRACKING / CONTROL KNOB XPA2039 SCREW,SHCS (M3x5) XPA2036 SPRING-BELT TENSION XPA2038 TRACKING ARM POST XPA0767 HEX SOCKET COUNTERSUNK HEAD MACHINE SCREW(M4x10) XPA2046 DUST COVER XPA2024 PIN, 3x32mm...

  • Page 7: Adjusting Belt Tracking

    Mounting and Removing 7. Remove the Contact Arm and replace with the desired arm. Make sure the tab on the end of the arm is in the Abrasive Belt channel of the Tracking Arm Mount. (See Fig. 3.) 8. Replace the Tracking Knob and tighten it into the threaded hole on the Contact Arm so the Contact Arm is To Install/Remove Belt : as straight as possible.
  • Page 8 Brushless Electric Belt-Sander Overload and Overheat Protections (1) 2-Step Overload Protection a) The LED indicator will turn from a flashing green light into a flashing red light whenever the PCB detects a power overload. b) The tool will stop automatically within approximately 5 seconds to prevent long-term overloading damage. The LED indicator will flash red until the tool stops.
  • Page 9 AirVANTAGE™ Tools 1966 West Holt Ave. Pomona, CA 91768. Telephone: 909-620-0788. No.530-1, Sec. 2, Guoling Rd., Zhongli Dist., Taoyuan City 320, Taiwan (R.O.C.)

This manual is also suitable for:

Ae-001003
