Aversix AVB-2000 Series User Manual

Rugged box pc
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User Manual
Rugged Box PC
AVB-2000 Series

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AVB-2000 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Aversix AVB-2000 Series

  • Page 1 User Manual Rugged Box PC AVB-2000 Series...

  • Page 2: Table Of Contents

    Contents AVB-2000 Series Rugged Box PC User Manual Prefaces……………………………………………………………………………………….…04 Revision…………………………………………………………………………..……………….…………………04 Copyright and Trademarks Notice………………………………………..……………………………..04 Disclaimer……………………………………………………………………………………………………………04 Declaration of Conformity…………………………………………………..………………………………04 Technical Support and Assistance………………….………………………………………………….…04 Safety Instructions……………….……………………….…………………………………………….………04 Packing List….……………………………………………….………………………………………………….…05 Ordering Information….……………………………………….………………………………..……………05 Optional Accessories….………………………….…………….…………………………………………..…05 Chapter 1 Product Introductions…………………………….………………………06 1.1 Overview…………………………………..………….………………………………………………………07 1.2 Hardware Specifications….………………………………..………………………………………….08 1.2.1 AVB-2000 Specificarion…...………………………………………………………….08 1.2.2 AVB-2001(S) Series Specification……....…………………………………….09...
  • Page 3 AVB-2000 Series Rugged Box PC User Manual Chapter 4 BIOS Setup…………………………………………………………………….62 4.1 BIOS Introduction…….……….………………………..….…….…..….……………………………..63 4.2 Main Setup……..……….……………………………………..…….….………………....64 4.2.1 System Date…….…………………………………..……..………………….....64 4.2.2 System Time………..………………………………..……….……………….....64 4.3 Advanced Setup………………………………………………..………………………………………….65 4.3.1 Trusted Computing (Optional)………………………………………..………………….65 4.3.2 ACPI Settings….………………………………………………..…………………………………66 4.3.3 Super IO Configuration………………………..…………………..……......67 4.3.4 Hardware Monitor…………………………….………..……………..…......71 4.3.5 Serial Port Console Redirection………………..…..……..……......72...

  • Page 4: Prefaces

    This user’s manual is for informational purposes only and is subject to change without prior notice. It does not represent commitment from Aversix Inc. This product might include unintentional typographical or technical errors. Aversix will periodically correct such erroneous files and incorporate these corrections into the new version of the file.

  • Page 5: Packing List

    AVB-2000 Series Rugged Box PC User Manual Package List Item Description Q’ty AVB-2000 Series Fanless Box PC Utility DVD Driver Wall Mount Kit Accessory Kit DVI to VGA Adapter Ordering Information Model No. Product Description Intel® J1900 Compact Fanless System with 2x LAN,2x COM and 1x AVB-2000 Removable 2.5”...

  • Page 6: Chapter 1 Product Introductions

    AVB-2000 Series Rugged Box PC User Manual Chapter 1 Product Introductions...

  • Page 7: Overview

    2x SATA, 2x PoE+ port and 6x COM ports models for users to choose. The AVB-2000 series system has a wide range of DC power input from 9V to 48V, wide operating temperature range of -40°C to +70°C and industrial- grade protection (RVP, OVP, OCP, ESD, surge, etc.).

  • Page 8: Hardware Specifications

    AVB-2000 Series Rugged Box PC User Manual 1.2 Hardware Specifications 1.2.1 AVB-2000 Specification Processor Expansion • Onboard Intel® Celeron® J1900 Quad Core • 1x Full-size Mini-PCIe Socket (mux with mSATA) • 1x Full-size Mini-PCIe Socket Processor, up to 2.42 GHz •...

  • Page 9: Avb-2001(S) Series Specification

    AVB-2000 Series Rugged Box PC User Manual 1.2.2 AVB-2001(S) Series Specification Processor Expansion • Onboard Intel® Celeron® J1900 Quad Core • 1x Full-size Mini PCIe Socket (mux with mSATA) • 1x Full-size Mini PCIe Socket Processor, up to 2.42 GHz •...

  • Page 10: Avb-2010(-2P)(-M12) Series Specification

    AVB-2000 Series Rugged Box PC User Manual 1.2.3 AVB-2010(-2P)(-M12) Series Specifications Processor Expansion • Onboard Intel® Celeron® J1900 Quad Core • 1x Full-size Mini PCIe Socket (mux with mSATA) • 1x Full-size Mini PCIe Socket Processor, up to 2.42 GHz •...

  • Page 11: Avb-2011(S)(-2P)(-M12) Series Specification

    AVB-2000 Series Rugged Box PC User Manual 1.2.4 AVB-2011(S)(-2P)(-M12) Series Specifications Processor Expansion • • Onboard Intel® Celeron® J1900 Quad Core 1x Full-size Mini PCIe Socket (mux with mSATA) • Processor, up to 2.42 GHz 1x Full-size Mini PCIe Socket •...

  • Page 12: Panel I/O

    AVB-2000 Series Rugged Box PC User Manual 1.3 Panel I/O 1.3.1 Front Panel Removable HDD port Power on/off button Removable 2.5" SATA HDD Area Press to power-on or power-off the system Power LED AT/ATX mode select switch Indicates the power status of the system...
  • Page 13 AVB-2000 Series Rugged Box PC User Manual AVB-2001 Series AVB-2010 Series...
  • Page 14 AVB-2000 Series Rugged Box PC User Manual AVB-2011 Series...

  • Page 15: Rear Panel

    AVB-2000 Series Rugged Box PC User Manual 1.3.2 Rear Panel Line-out Earthing Screw Hole Used to connect a speaker Used to connect the ground wire Mic-in Antenna Hole Used to connect a microphone Used to connect an antenna for optional Mini-...
  • Page 16 AVB-2000 Series Rugged Box PC User Manual AVB-2001 AVB-2001S...
  • Page 17 AVB-2000 Series Rugged Box PC User Manual AVB-2010 / AVB-2010-2P AVB-2010-M12 / AVB-2010-2P-M12...
  • Page 18 AVB-2000 Series Rugged Box PC User Manual AVB-2011 AVB-2011S...
  • Page 19 AVB-2000 Series Rugged Box PC User Manual AVB-2011-M12 / AVB-2011-2P-M12 AVB-2011S-M12 / AVB-2011S-2P-M12...

  • Page 20: Right Panel

    AVB-2000 Series Rugged Box PC User Manual 1.3.3 Right Panel Clear CMOS COM port Used to clear CMOS COM1 ~ COM2 support RS232/422/485 serial device CFast Socket Used to insert CFast card Digital I/O Terminal Block The Digital I/O terminal block supports 8...
  • Page 21 AVB-2000 Series Rugged Box PC User Manual AVB-2001 Series AVB-2010 Series...
  • Page 22 AVB-2000 Series Rugged Box PC User Manual AVB-2011 Series...

  • Page 23: Mechanical Dimensions

    AVB-2000 Series Rugged Box PC User Manual 1.4 Mechanical Dimensions 1.4.1 AVB-2000 1.4.2 AVB-2001 Series...

  • Page 24: Avb-2010 Series

    AVB-2000 Series Rugged Box PC User Manual 1.4.3 AVB-2010 Series 1.4.4 AVB-2011 Series...

  • Page 25: Chapter 2 Switches And Connectors

    AVB-2000 Series Rugged Box PC User Manual Chapter 2 Switches and Connectors...

  • Page 26: Switches And Connectors

    AVB-2000 Series Rugged Box PC User Manual 2.1 Switches and Connectors 2.1.1 Front View 2.1.2 Rear View...

  • Page 27: Right View

    AVB-2000 Series Rugged Box PC User Manual 2.1.3 Right View...

  • Page 28: Switches, Leds And Connectors Definition

    AVB-2000 Series Rugged Box PC User Manual 2.2 Switches, LEDs and Connectors Definition List of Switches and LEDs Location Definition PWR_SW1 Power Button AT_ATX1 AT / ATX Power Mode Switch RESET1 Reset Button CLR_CMOS1 Clear BIOS Switch PC_CAR1 PC / Car Mode Switch...

  • Page 29: Switches Definition

    AVB-2000 Series Rugged Box PC User Manual 2.3 Switch Definitions PWR_SW1：Power Button Switch Definition Push Power On/Off System AT_ATX1：AT / ATX Power Mode Switch Definition 1-2 (Right) ATX Power Mode (Default) 2-3 (Left) AT Power Mode RESET1：Reset Button Switch Definition...
  • Page 30 AVB-2000 Series Rugged Box PC User Manual Set the Power Ignition Step Step 1 To select power ignition by PC/CAR switch. Step 1 Pin 1-2 (Left)：PC Power Mode 2-3 (Right)：Vehicle Power Ignition Mode Step 2 To configure the power off delay time, please check the delay time setting options in advance.
  • Page 31 AVB-2000 Series Rugged Box PC User Manual PWR_LED1：Power Status LED Power Status LED Color Power ON Blue HDD_LED1：HDD Status LED HDD Status LED Color HDD Read/Write Yellow IGN_LED1：Ignition Status LED IGN Status LED Color IGN ON Green GPIO_LED1：GPIO Status LED...

  • Page 32: Connectors Definition

    AVB-2000 Series Rugged Box PC User Manual 2.4 Connector Definitions PWR_SW2：Remote Power Switch Connector Type：Terminal Block 1X2 2-pin, 3.5mm pitch Definition Power Button COM1_1, COM2_1, COM3_1, COM4_1, COM5_1, COM6_1：RS232 / RS422 / RS485 Connector Connector Type：9-pin D-Sub RS232 RS422 / 485 Full...
  • Page 33 AVB-2000 Series Rugged Box PC User Manual DIO1_1：Digital Input / Output Connector Connector Type：Terminal Block 2X5 18-pin, 3.5mm pitch Definition Definition External DC Voltage Input External GND POWER1：Power Connector Connector Type：1X4-pin Wafer, 2.0mm pitch Definition +12V...
  • Page 34 AVB-2000 Series Rugged Box PC User Manual MINIPCIE1：Mini PCI-Express Socket (Support SIM Card to Link feature) Definition Definition WAKE# +3.3Vaux +1.5V CLKREQ2# UIM1_PWR USIM1_DATA PCIE_CLK- USIM1_CLK PCIE_CLK+ USIM1_RST USIM1_VPP RESERVED RESERVED W_DISABLE# RESET# PCIE_RXN2 +3.3Vaux PCIE_RXP2 +1.5V SMB_CLK PCIE_TXN2 SMB_DATA...
  • Page 35 AVB-2000 Series Rugged Box PC User Manual CN1：Dual Mode Mini PCI-Express (Support mSATA and SIM Card to Link feature) Definition Definition WAKE# +3.3Vaux +1.5V CLKREQ3# UIM2_PWR USIM2_DATA PCIE_CLK- USIM2_CLK PCIE_CLK+ USIM2_RST USIM2_VPP RESERVED RESERVED W_DISABLE# RESET# PCIE_RXN3 +3.3Vaux (SATA_RXP1) PCIE_RXP3 (SATA_RXN1) +1.5V...

  • Page 36: Chapter 3 System Setup

    AVB-2000 Series Rugged Box PC User Manual Chapter 3 System Setup...

  • Page 37: Installing Sodimm

    AVB-2000 Series Rugged Box PC User Manual WARNING In order to prevent electric shock or system damage, before removing the bottom chassis cover, must turn off the power and disconnect the device from power source. 3.1 Installing SODIMM AVB-2000 / AVB-2010 Series 1.
  • Page 38 AVB-2000 Series Rugged Box PC User Manual 3. Locate SODIMM socket. 4. Insert SODIMM module from 45 degree direction.
  • Page 39 AVB-2000 Series Rugged Box PC User Manual 5. Press the module down until it’s fixed firmly by the two locking latches. AVB-2001 / AVB-2011 Series 1. Turn over the system to have the bottom side face up and loosen the 6 screws at the...
  • Page 40 AVB-2000 Series Rugged Box PC User Manual 2. Remove the bottom cover. 3. Remove the hard drive bay on the side.
  • Page 41 AVB-2000 Series Rugged Box PC User Manual 4. Locate SODIMM socket. 5. Insert SODIMM module from 45 degree direction.

  • Page 42: Replace Cmos Battery

    AVB-2000 Series Rugged Box PC User Manual 6. Press the module down until it’s fixed firmly by the two locking latches. 3.2 Replace CMOS Battery AVB-2000 / AVB-2010 Series 1. Turn over the system to have the bottom side face up and loosen the 2 screws at the...
  • Page 43 AVB-2000 Series Rugged Box PC User Manual 2. Remove the bottom cover. 3. Locate the CMOS Battery.
  • Page 44 AVB-2000 Series Rugged Box PC User Manual 4. Remove the old CMOS battery. 5. Install a new CMOS battery in the battery holder.
  • Page 45 AVB-2000 Series Rugged Box PC User Manual AVB-2001 / AVB-2011 Series 1. Turn over the system to have the bottom side face up and loosen the 6 screws at the bottom. 2. Remove the bottom cover.
  • Page 46 AVB-2000 Series Rugged Box PC User Manual 3. Remove the hard drive bay on the side. 4. Locate the CMOS Battery.
  • Page 47 AVB-2000 Series Rugged Box PC User Manual 5. Remove the old CMOS battery. 6. Install a new CMOS battery in the battery holder.

  • Page 48: Installing Mini-Pcie Card / Msata Module

    AVB-2000 Series Rugged Box PC User Manual 3.3 Installing Mini-PCIe / mSATA Module 1. Turn the SATA HDD thumb screw on the front panel and remove the SATA HDD bay. 2. Turn over the system to have the top side face up and loosen the six screws on the left and right sides.
  • Page 49 AVB-2000 Series Rugged Box PC User Manual 3. Remove the top cover 4. loosen the 3 screws and remove the HDD tray.
  • Page 50 AVB-2000 Series Rugged Box PC User Manual 5. Locate the Mini-PCIe sockets. Please note that the left connector (CN1) is shared Mini- PCIe/mSATA interface, and right connector (MINIPCIE1) is Mini-PCIe interface. Both of these support SIM card to Link feature.
  • Page 51 AVB-2000 Series Rugged Box PC User Manual 7. Press the Mini-PCIe/mSATA module down and lock it with two screws . 8. If you have a Half-size Mini-PCIe card, make sure use extender to make it full-size as shown below.

  • Page 52: Installing Antenna

    AVB-2000 Series Rugged Box PC User Manual 3.4 Installing antenna 1. Remove the antenna hole covers at front or rear panel. Front Rear 2. Have antenna jack penetrate through the hole.
  • Page 53 AVB-2000 Series Rugged Box PC User Manual 3. Put on washer and fasten the nut with antenna jack. 4. Assemble the antenna and antenna jack together.
  • Page 54 AVB-2000 Series Rugged Box PC User Manual 5. Attach the RF connector at the cable-end onto the Mini-PCIe wifi module.

  • Page 55: Installing Sim Card Or Cfast Card

    AVB-2000 Series Rugged Box PC User Manual 3.5 Installing SIM Card or CFast Card 1. Loosen 2 screws on the right panel to remove the CFast / SIM cover plate. 2. Insert CFast / SIM card into the socket. Note 1 Please note that the installation of SIM1 and SIM2 has to match the installation of Mini- PCIe sockets.

  • Page 56: Installing The Front Removable Sata Hdd Bay

    AVB-2000 Series Rugged Box PC User Manual 3.6 Installing the front removable SATA HDD bay 1. Unscrew the two thumb screws circled below to take out the removable 2.5” SATA HDD bay. 2. Lock the 2.5” SATA HDD with HDD bracket using four screws...

  • Page 57: Installing The Right Removable Sata Hdd Bay

    AVB-2000 Series Rugged Box PC User Manual 3. Slide the HDD bracket back and then fasten the thumb screws. 3.7 Installing the right removable SATA HDD bay (AVB-2001/ AVB-2011 Series Only) 1. Unscrew the two thumb screws circled below to take out the removable 2.5” SATA HDD...
  • Page 58 AVB-2000 Series Rugged Box PC User Manual 2. Lock the 2.5” SATA HDD with HDD bracket using four screws. 3. Slide the HDD bracket back and then fasten the thumb screws.

  • Page 59: Installing Wall Mount Brackets

    AVB-2000 Series Rugged Box PC User Manual 3.8 Installing Wall Mount Brackets 1. Wall mount kit is included in the standard package. 2. The mounting holes are at the bottom of system.

  • Page 60: Installing Din-Rail Holder

    AVB-2000 Series Rugged Box PC User Manual 3. Use provided 4 screws to fasten the bracket with each side of system together. 3.9 Installing DIN-Rail Holder 1. The DIN-Rail bracket is an optional accessory.
  • Page 61 AVB-2000 Series Rugged Box PC User Manual 2. Place the system upside down so you can see the bottom cover with two screw holes for din-rail holder. 3. Place the din-rail holder on top of the bottom cover and lock it with two screws.

  • Page 62: Chapter 4 Bios Setup

    AVB-2000 Series Rugged Box PC User Manual Chapter 4 Bios Setup...

  • Page 63: Bios Introduction

    AVB-2000 Series Rugged Box PC User Manual 4.1 BIOS Introduction The system BIOS software is stored on EEPROM. The BIOS provides an interface to modify the configuration. When the battery is removed, all the parameters will be reset. BIOS Setup Power on the embedded system and by pressing <Del>...

  • Page 64: Main Setup

    AVB-2000 Series Rugged Box PC User Manual 4.2 Main Setup Press <Del> to enter BIOS CMOS Setup Utility. The Main setup screen is showed as following when the setup utility is entered. System Date/Time is set up in the Main Menu.

  • Page 65: Advanced Setup

    AVB-2000 Series Rugged Box PC User Manual 4.3 Advanced Setup 4.3.1 Trusted Computing (Optional) ■ Security Device Support Enable or disable TPM function...

  • Page 66: Acpi Settings

    AVB-2000 Series Rugged Box PC User Manual 4.3.2 ACPI Settings ■ Enable ACPI Auto Configuration This item allows you to enable or disable BIOS ACPI Auto Configuration. ■ Enable Hibernation This item allows you to enable or disable system ability to hibernate.

  • Page 67: Super Io Configuration

    AVB-2000 Series Rugged Box PC User Manual 4.3.3 Super IO Configuration This setting allows you to select options for the Super IO Configuration, and change the value of the selected option.
  • Page 68 AVB-2000 Series Rugged Box PC User Manual ■ Serial Port 1 Configuration ■ Serial Port 2 Configuration...
  • Page 69 AVB-2000 Series Rugged Box PC User Manual ■ Serial Port 3 Configuration ■ Serial Port 4 Configuration...
  • Page 70 AVB-2000 Series Rugged Box PC User Manual ■ Serial Port 5 Configuration ■ Serial Port 6 Configuration...

  • Page 71: Hardware Monitor

    AVB-2000 Series Rugged Box PC User Manual ■ Watch Dog Function This setting allows you to setup the system watch-dog timer, a hardware timer that generates a reset when the software that it monitors does not respond as expected each time the watch dog polls it.

  • Page 72: Serial Port Console Redirection

    AVB-2000 Series Rugged Box PC User Manual 4.3.5 Serial Port Console Redirection ■ Console Redirection These items allows you to enable or disable COM1~COM6 console redirection. • Legacy Console Redirection Settings Select a COM port to display redirection of Legacy OS and Legacy OPROM Messages.

  • Page 73: Cpu Configuration

    AVB-2000 Series Rugged Box PC User Manual 4.3.6 CPU Configuration ■ Intel Virtualization Technology Virtualization enhanced by Intel Virtualization Technology will allow a platform to run multiple operating systems and applications in independent partitions. With virtualization, one computer system can function as multiple Virtual systems.

  • Page 74: Sata Configuration

    AVB-2000 Series Rugged Box PC User Manual 4.3.8 SATA Configuration ■ SATA Speed Support Change the SATA Speed. Select <Gen1> or <Gen2> speed. ■ SATA Mode This item allows you to select IDE or AHCI Mode. ■ SATA Port 0 This item allows you to enable or disable SATA Port 0.

  • Page 75: Network Stack Configuration

    AVB-2000 Series Rugged Box PC User Manual 4.3.10 Network Stack Configuration ■ Network Stack Use this item to enable or disable UEFI Network Stack.

  • Page 76: Csm Configuration

    AVB-2000 Series Rugged Box PC User Manual 4.3.11 CSM Configuration ■ CSM Support Enables or disables UEFI CSM (Compatibility Support Module) to support a legacy PC boot process. ■ Boot option filter This item allows you to select which type of operating system to boot.

  • Page 77: Usb Configuration

    AVB-2000 Series Rugged Box PC User Manual 4.3.12 USB Configuration ■ Legacy USB Support Allows USB keyboard/ mouse to be used in MS-DOS. ■ XHCI Hand-off Determines whether to enable XHCI (USB3.0) Hand-off feature for an operating system without XHCI (USB3.0) Hand-off support.

  • Page 78: Chipset

    AVB-2000 Series Rugged Box PC User Manual 4.4 Chipset 4.4.1 North Bridge This section provides information on the installed memory size and memory/onboard graphics-related configuration options.
  • Page 79 AVB-2000 Series Rugged Box PC User Manual ■ IGD Configuration This section provides onboard graphics-related configuration options. • IGD Turbo Enable This item allows you to enable or disable IGD Turbo. • PAVC This item enables/disables Protected Audio Video Control. Select <Disabled>, <LITE Mode>...

  • Page 80: South Bridge

    AVB-2000 Series Rugged Box PC User Manual 4.4.2 South Bridge ■ Azalia HD Audio Control detection of the Azalia device. • Audio Controller Enabled: Azalia will be unconditionally enabled. Disabled: Azalia will be unconditionally disabled.
  • Page 81 AVB-2000 Series Rugged Box PC User Manual ■ USB Configuration • XHCI Mode This item allows you to enable or disable the USB XHCI controller. • USB 2.0 (EHCI) Support This item allows you to enable or disable the USB EHCI support.
  • Page 82 AVB-2000 Series Rugged Box PC User Manual ■ PCI Express Configuration Control detection of the Azalia device. • PCI Express Port 1 (PCIE1/MINIPCIE1) This item allows you to enable or disable PCI Express Port 1 (PCIE1/MINIPCIE1) in the chipset. • Speed Change the PCIe Port Speed.

  • Page 83: Security

    AVB-2000 Series Rugged Box PC User Manual 4.5 Security Security menu allow you to change administrator password and user password settings. 4.5.1 Administrator Password This item allows you to set Administrator Password. 4.5.2 User Password This item allows you to set User Password.

  • Page 84: Boot

    AVB-2000 Series Rugged Box PC User Manual 4.6 Boot This menu allows you to setup the system boot options. 4.6.1 Setup Prompt Timeout This item sets number of seconds to wait for setup activation key. 4.6.2 Bootup NumLock State This item selects the keyboard NumLock state. Select <On> or <Off>.

  • Page 85: Save & Exit

    AVB-2000 Series Rugged Box PC User Manual 4.7 Save & Exit This setting allows you to configure the boot settings. 4.7.1 Save Changes and Reset This item allows you reset the system after saving the changes. 4.7.2 Discard Changes and Reset Select this option to quit Setup without making any permanent changes to the system configuration.

This manual is also suitable for:

Avb-2001Avb-2001sAvb-2010Avb-2010-2pAvb-2011Avb-2011-2p ... Show all
