Summary of Contents for Schiller STEINER 75-70006A
- Page 1 75-70006A 430 MAX 25HP KUBOTA GAS 75-70008A 430 MAX 21HP KUBOTA DIESEL 75-70010A 430 MAX 33HP GENERAC GAS 75-70011A 430 MAX 30HP KOHLER GAS PARTS MANUAL 4163331...
- Page 2 CALIFORNIA WARNING Proposition 65 Warning The engine exhaust from this product Diesel engine exhaust and some of contains chemicals known to the State its constituents are known to the State of California to cause cancer, birth of California to cause cancer, birth defects or other reproductive harm.
-
Page 3: Table Of Contents
Your safe use of this Schiller Grounds Care, Inc. product is one of our prime design objectives. Many safety features are built in, but we also rely on your good sense and care to achieve accident-free operation. For best protection, study the manuals thoroughly. -
Page 4: Safety
Schiller of hazard seriousness. These words appear in this Grounds Care, Inc. Engineering Department. Any manual and on the safety labels attached to Schiller Schiller Grounds Care, Inc. product that is altered, Grounds Care, Inc. machines. For your safety and... - Page 5 SAFETY PREPARING FOR SAFE OPERATION Site preparation and circumstances Operator preparation and training – Evaluate the terrain to determine what accessories and attachments are needed to Read the Operation & Safety Manual properly and safely perform the job. Only use –...
- Page 6 SAFETY OPERATING SAFELY In general Interrupting operation – Use extra care when loading or unloading the – Before leaving the operator's position: machine into a trailer or truck. - Park on level ground. – Close fuel valve before transporting. - Lower attachments. - Disengage the PTO.
- Page 7 All slopes require extra caution. Rollover Protection Structure (ROPS) – The operator must be experienced with the Schiller Grounds Care, Inc. tractor and it's unique operational responses. – A Rollover Protection Structure (ROPS) for this tractor is available as an optional accessory.
- Page 8 SAFETY Do not fill containers in a vehicle or on a truck or MAINTENANCE SAFETY – trailer bed with a plastic liner. Fill containers on In general the ground away from the vehicle. – Maintain machine according to manufacturer's – When practical, remove gas powered equipment schedule and instructions for maximum safety from the truck or trailer and refuel it on the...
- Page 9 SAFETY Battery JUMP STARTING WARNING Battery acid is caustic and fumes 1. Be sure the jumper cables are in good condition. are explosive and can cause Turn off the ignition and all electrical accessories serious injury or death. on both machines. To reduce the risk of personal 2.
-
Page 10: Labels
LABELS 00-093 00-220 Location: Location: Top of rear hydraulic motor shield. Right side of frame and front right side of fuel tank. 00-200 00-025 Location: Location: Steering column. Front grille. -
Page 11: Assembly / Specifications
ASSEMBLY / SPECIFICATIONS The Schiller Grounds Care, Inc. 430 MAX is designed for the commercial user or homeowner. From the rugged in- dustrial frame to the operator controls...the tractor is ready for demanding turf and grounds care assignments. Power steering and articulated frame, combined with a low center of gravity and high flotation tires, provide exceptional maneuverability. -
Page 12: Controls
CONTROLS 1. PTO LEVER The PTO lever controls the front drive belt (Power Take Off or PTO) that supplies power to attachments. Rotate the lever upward to disengage the PTO and stop an attachment. Rotate the lever downward to engage the PTO and start the attachment. –... - Page 13 CONTROLS 11. FORWARD-REVERSE LEVER Controls infinitely variable forward and reverse speeds. – To move forward, move the control lever sideways out of the neutral slot and forward. The farther the lever is moved forward, the faster the machine will travel up to its maximum speed. –...
- Page 14 CONTROLS 16. REAR TRANSAXLE RANGE SELECTOR LEVER Selects rear transaxle speed range. Both transaxles must be in the same range. See page 15 for HI-LO Range selection information. 17. FRONT TRANSAXLE RANGE SELECTOR LEVER Selects front transaxle speed range. Both transaxles must be in the same range.
-
Page 15: Operation
2. Open throttle approximately one-fourth of its Fill transaxle to the safe range with approved travel. hydraulic oil. Use only Schiller Grounds Care, Inc. Trans-Hydraulic Oil or Texas Refinery Corp. 6440 3. GASOLINE ENGINES: Pull choke. Universal Torque Fluid. Do not use automatic... - Page 16 OPERATION OPERATING NOTES MAXIMUM ENGINE INCLINATION RECOMMENDATIONS – OBSERVE SAFETY DECALS. When using an engine in an inclined position – Practice at slow engine and travel speeds with the continuously, the following points must be PTO off until fully familiar with the controls. remembered: –...
- Page 17 OPERATION DRIVING INSTRUCTIONS FOR TRANSAXLE RANGE SELECTION 1. Select desired engine speed with the throttle. For Do not attempt to select ranges on slopes or power driven attachments, the engine is normally when the unit is traveling. Select ranges only run at maximum RPM.
- Page 18 OPERATION FRONT LIFT AUXILIARY HYDRAULICS The front lift control valve is equipped with a detent The auxiliary valve and quick couplers are standard float position. Always use “FLOAT” position when equipment. Keep dust covers in place when couplers mowing, sweeping, etc. are not in use.
-
Page 19: Service Charts
SERVICE CHARTS EVERY EVERY EVERY EVERY SERVICE CHART DAILY HOURS HOURS HOURS HOURS Read safety decals. Check fuel level. Check engine oil level. Check coolant level. (Liquid cooled engines only) Visual inspection of: Bolts and fittings for signs of loosening. Accumulation of dirt or foreign matter around engine, restricting engine cooling. - Page 20 CAPACITY CHART CAPACITIES CHART* CAPACITY OF: QUANTITY Engine Oil (Generac) 2.3 U.S. Quarts (2.4 liters) Engine Oil (Kubota Gas) 3 U.S. Quarts (2.9 liters) Engine Oil (Kubota Diesel) 3 U.S. Quarts (2.9 liters) Engine Oil (Kohler) 1.9 U.S. Quarts (1.8 liters) Engine Coolant (Kubota Gas) 3 U.S.
-
Page 21: Maintenance
2. Turn the PTO on. This check should kill the engine after 1/2 second. Repair machine before using if the Operator Presence Interlock System does not operate correctly in start or run. Contact your authorized Schiller Grounds Care, Inc. dealer. Hardware Tighten any nuts and bolts found loose. - Page 22 MAINTENANCE ENGINE AIR FILTERS – Install filters properly, do not over tighten and Do not perform engine maintenance without the deform element. engine off, spark plug wires (gasoline engines) disconnected and PTO disengaged. Kohler & Generac – Keep an extra foam wrap oiled and ready - Can ENGINE OIL AND FILTER CHANGE PROCEDURE keep the extra foam wrap in tool box.
- Page 23 TRANSAXLE OIL CHANGE PROCEDURE NOTE: Change oil and filter at any time contamination is THE USE OF ANY OIL OTHER THAN Schiller suspected. Approximately 3 gallons of approved Grounds Care, Inc. TRANS-HYDRAULIC OIL hydraulic oil are needed to change oil.
- Page 24 - Schiller Grounds Care, Inc. belts are high pressure hydrostatic system. recommended. (See Belt Chart on page 18 for sizes). Schiller Grounds Care, Inc. specification TRANSAXLE OIL LEVELS belts are Aramid fiber reinforced...
- Page 25 MAINTENANCE FRAME WHEELS AND TIRES 1. Check for loose or missing fasteners after first 10 - Use only factory recommended wheels and hours. - Every 100 hours thereafter. tires. - Torque transaxle mount bolts 60 - 65 ft. lbs. - Never use different sizes in any combination. Torque wheel hub bushing bolts to 192 in lbs.
-
Page 26: Adjustments
ADJUSTMENTS PTO BELT ADJUSTMENT STOP ENGINE! DO NOT ATTEMPT TO INSTALL BELTS OR MAKE BELT ADJUSTMENTS WITH THE ENGINE RUNNING. It is necessary to check the PTO belt adjustment - Every time attachments are changed. - If the PTO drive belt slips or does not release properly. - Page 27 ADJUSTMENTS FORWARD-REVERSE LEVER TENSION ADJUSTMENT Tension is adjusted by tightening the spring-loaded friction washers on the Forward - Reverse lever. Tighten the friction washers to hold the lever in the desired position under normal loads. When the hydrostatic system is subjected to heavy loads, the Forward-Reverse lever has a tendency to return to the neutral position. Ad- ditional holding pressure from your hand may be needed to keep the lever in the desired position.
-
Page 28: Troubleshooting
TROUBLESHOOTING SYMPTOM POSSIBLE CAUSE REMEDY Forward-Reverse control lever not in neutral. Adjust neutral linkage (See page 24). PTO engaged. Disengage PTO. Battery dead. Check battery, charge or replace. Engine will not turn Defective wiring, broken or loose Visually check, or check with test light for continuity over. -
Page 29: Belt Chart
BELT CHART... - Page 30 SCHILLER GROUNDS CARE, INC. ONE BOB-CAT LANE P.O. BOX 469 JOHNSON CREEK, WI 53038 920-699-2000 www.schillergc.com BOB-CAT BUNTON RYAN STEINER...
