HUBER+SUHNER IANOS Standard Module Installation Manual

INSTALLATION
MANUAL
IANOS Standard Modules

Table of contents

• MODULE TYPES ............................................................................................................... 1
• INSPECTION AND CLEANING ......................................................................................... 2
• INSTALL AND WIRING MODULES (FROM THE FRONT) DRAWER DESIGN .............. 2
• INSTALLING AND WIRING MODULES (FROM THE REAR) ........................................... 3
• REMOVING MODULES (FROM THE FRONT) DRAWER DESIGN ................................. 4
• REMOVING MODULES (FROM THE REAR) ................................................................... 4
• MODULE: SPLICE MODULE ............................................................................................. 5
• MODULE: PRE-TERMINATED MODULE ......................................................................... 6
• APPLICATION: PART LOADED CHASSIS (USE OF OPTIONAL MODULE BLANKS)... 7

MODULE TYPES

Patching modules
Transition modules
HUBER+SUHNER disclaims any liability resulting from incorrect installation and use, including any damages resulting from the use of tools and
accessories other than the ones recommended herein. Any installation performed by unqualified personnel voids the product warranty provided by
HUBER+SUHNER. All due care and attention must be exercised when performing the installation of these products. For advice concerning the gen-
eral handling of these products please contact HUBER+SUHNER.
Splicing modules
Conversion modules
HUBER+SUHNER AG
Fiber Optics
Fiber Management Systems
DOC-0000765314 Rev B
Date: 08/03/2018
Page 1 of 7
Pre-terminated modules
Blind modules
