- Page 1 User Guide MICA IO-Link Gateway...
- Page 2 No part of this manual may be reproduced in any form (print, photocopy, microfilm or any other process), processed, duplicated or distributed by means of electronic systems without the written permission of HARTING IT Software Development GmbH & Co. KG, Espelkamp. Version 1.0. Subject to alterations without notice.
-
Page 3: Table Of Contents
MICA IO-Link Gateway - User Manual Inhalt Introduction .......................... 4 About the MICA IO-Link Gateway Container ..............4 MICA IO-Link Gateway Limitations ..................4 General Overview ......................... 5 Operation Requirements and Conditions ................5 Installation, Initial Setup and Configuration..............6 Connecting the MICA IO-Link ..................... -
Page 4: Introduction
1.1 About the MICA IO-Link Gateway Container MICA IO-Link Gateway is a MICA container that lets you configure, and communicate with, IO- Link devices connected to a HARTING MICA IO-Link or MICA Wireless IO-Link.. 1.2 MICA IO-Link Gateway Limitations The MICA IO-Link Gateway currently does not support external or third-party IO-Link masters. -
Page 5: General Overview
MICA IO-Link Gateway - User Manual 2 General Overview 2.1 Operation Requirements and Conditions MICA IO-Link Gateway requires a MICA IO-Link or MICA Wireless IO-Link. MICA IO-Link M5 MICA IO-Link M8 MICA Wireless IO-Link M5 MICA Wireless IO-Link M8... -
Page 6: Installation, Initial Setup And Configuration
For connecting and logging into a MICA IO-Link or MICA Wireless IO-Link, see the MICA Getting Started available at harting-mica.com. All MICA IO-Link variants have a supplemental M8/24V input next to the IO-Link ports. This input is used to provide 24V power from the MICA to IO-Link devices. - Page 7 MICA IO-Link Gateway - User Manual Wait until the installation is finished and click Close. The installed containers IOLink and IODDstore are initially turned off. Right Click first on the IODDstore container and then the IOLink and container and press Start App button to start the container.
-
Page 8: Basic Container Operations
• Reset: Resets the configuration of the MICA IO-Link Gateway to the last reset point (factory default if no merge was executed before). • Delete: Deletes the Container including all its configuration and user data. HARTING IT Software Development... -
Page 9: Using The Io-Link Gateway
MICA IO-Link Gateway - User Manual 5 Using the IO-Link Gateway After starting the container, you can open the user interface by clicking the MICA IO-Link Gateway Container tile. The user interface consists of six sections. To make changes to a section, click on the section title or the button with the chevron left of the section title. -
Page 10: Devices
To delete an IODD entry, click the (x) in the right column. Only one IODD file per device can be uploaded to the IODD Store. Note: For the IODD Store functionality to work, the IODDstore container must be installed and running. HARTING IT Software Development... -
Page 11: Executor
MICA IO-Link Gateway - User Manual 5.4 Executor The Executor lets you perform operations on specific fields of IO-Link devices that are connected to a MICA IO-Link. To read data from a device, choose the device and field you want to read, select READ from the Operation drop down and click Execute. -
Page 12: Subscribers
3. Choose the type of the subscriber. (CUSTOM, MQTT, MQTTS AZURE, HTTP, HTTPS, JDBC, TCP, UDP options are available) 4. The URI of the Subscriber must be set and valid. 5. Left click on Apply button. HARTING IT Software Development... -
Page 13: Deleting A Subscriber
MICA IO-Link Gateway - User Manual 5.6.2 Deleting a Subscriber You can delete a subscriber by moving your mouse over on a subscriber and clicking the Delete button. The specific subscriber and all subscriptions associated with the subscriber will be deleted. Please be sure that at least one subscriber is in the subscribers list. -
Page 14: Working With Logs
To reload the log, click the Reload icon . To download the log as a text file to your computer, click the Export icon To follow the log live, click the Observe button. HARTING IT Software Development... -
Page 15: Rest Api
MICA IO-Link Gateway - User Manual 7 REST API GET /devices provides all known devices GET /devices/status provides the status of all known devices GET /devices/{deviceId} provides the requested device GET /devices/{deviceId}/fields/values provides all fields values of requested device GET /devices/{deviceId}/fields/values/{fieldId} provides field value of requested device and field PUT /devices/{deviceId}/fields/values updates a list of fields values of a device... -
Page 16: Troubleshooting
UI to reload the web page and try again. Also check that the IODDstore container is running. The IO-Link container cannot connect to the Stop both apps. Then start the IODDstore IODDstore. followed by the IO-Link container. HARTING IT Software Development...
