  • Page 1 ™ Owner’s Manual Fuel Management System for Transfer Flow Auxiliary Fuel Tanks...

  • Page 2: Table Of Contents

    Maintenance and Troubleshooting ................ 10 ™ TRAX 4 Troubleshooting Table ................11 Important Safety Information ................. 12 Transfer Flow Replacement Parts ................13 Warranty ........................13 1444 Fortress Street, Chico, CA 95973 (800) 442-0056 • (530) 893-5209 Fax (530) 893-0204...

  • Page 3: Trax 4 ™ Fuel Management System

    The TRAX 4™ system ® also monitors the vehicle’s fuel system status and the fuel levels of each tank. TRAX 4™ transfers fuel as needed with an electric fuel pump at a rate of one gallon every three minutes. Fuel System Overview The TRAX 4™...

  • Page 4: Trax 4 ™ Mobile App Setup

    Step 4 Select “Connect” from the drop down menu (fig. 2). fig. 2 Step 5 Select the device for your vehicle (TRAX 4™), and click connect. Step 6 If this is the first time setting up, see Bluetooth setup instructions on page 3.
  • Page 5 You can access the dropdown menu bar by pressing the three white vertical dots located on the blue bar. Below is a brief description of each item. Home - This is the main screen that displays current Trax 4™ Status, Distance to Empty, and Fuel Tank Levels Setup –...

  • Page 6: Trax 4 ™ Status Guide

    Fuel transfer from the auxiliary tank to the main tank is occurring. There is an error with the vehicle’s fuel systems. See TRAX 4™ manual. Bluetooth connection has been lost. Vehicle engine is off. Start engine ENGINE to access data.

  • Page 7: Fuel Tank Levels

    Fuel Tank Levels The TRAX 4™ system will transfer fuel at predetermined fuel levels while the vehicle is in use, based on the individual vehicle fuel system calibration and size of the Transfer Flow auxiliary fuel tank (fig. 8). To change gallons to percentage of fuel in each tank, tap on the gallons/ percentage values or by changing the fuel display settings in the setup screen.

  • Page 8: Trax 4 ™ Mobile App Diagnostics

    “Diagnostics Data” menu. Important Vehicle Diagnostic Note When performing any diagnostics on the vehicle through the OBDII port (smog check diagnostics, ECU flashes, and any remote automated ser- vices) the TRAX 4™ system must be disconnected.

  • Page 9: Manual Fuel Transfer Button

    Optional In-Cab LCD Fuel Level Monitor LCD If you prefer not to use our TRAX 4™ app with your auxiliary tank but still want to know how much fuel is in the auxiliary tank, consider our in-cab fuel level monitor LCD. The LCD shows the fuel level of the auxiliary tank with an easy-to-read bar graph that decreases when fuel is transfered to the pickup’s main fuel tank.

  • Page 10: Computer Module Overview

    Computer Module Overview fig. 15...

  • Page 11: Frequently Asked Questions

    I previously bought a Transfer Flow auxiliary tank. Can I transfer it to my new truck? It depends on the truck you are buying. TRAX 4™ is only available for 2008 to current model years. You may need to purchase a re- installation kit. Call our fuel system experts for more information at (800) 442-0056.

  • Page 12: Maintenance And Troubleshooting

    Transfer Flow includes an extra filter with your initial purchase. Routine filter replacement: Transfer Flow recommends the filter be replaced every 12 months on vehicles that see normal use. If the vehicle is operated in dusty conditions or driven more than 20,000 miles per year, the filter should be changed every 6 months.

  • Page 13: Trax 4 ™ Troubleshooting Table

    Tech Support Check wiring for a Pump short/check pump Pump not Current Out The fuel pump is shorted for internal short/ transferring of Range replace pump fig. 16 Transfer Flow Technical Support: (800) 442-0056 x2 or (530) 893-5209 x2...

  • Page 14: Important Safety Information

    • Never overfill or “top-off” any fuel tank. Overfilling the fuel tank may cause damage to the emissions system, cause dangerous spills and possibly result in a fire. The Transfer Flow TRAX 4™ system may also shut down in the event of a “top off” condition.

  • Page 15: Transfer Flow Replacement Parts

    “off the shelf” parts and cannot be replaced with parts that appear to be similar. For example, the in-line fuel pump used with our TRAX 4™ system appears to be a normal fuel pump, but it is actually a high-quality solenoid pump with a critical forward and reverse check feature.
  • Page 16 IMPORTANT SETUP INFORMATION Please use the 10-digit part below when calibrating the TRAX 4™ mobile app to your specific vehicle. TFI USE ONLY APPLY 080 LABEL HERE 1444 Fortress Street, Chico, CA 95973 (800) 442-0056 • (530) 893-5209 www.TransferFlow.com PRINTED IN USA...
