- Page 1 User's manual & technical documentation Always read the instructions carefully REFERENCE MODEL: DSI before use. Document SD-PUM revision 1, April 29, 2020...
-
Page 2: Table Of Contents
Content Product characteristics ......................... 3 Product description ..............................3 Battery characteristics ..............................4 Charging equipment ..............................4 Radio module ................................4 Recommended minimum Computer requirements ....................5 Safety instructions ..........................6 Operating Instructions ......................... 7 Environmental operating conditions ........................... 7 Configuration - Create your account / Login ....................... -
Page 3: Product Characteristics
Product characteristics Product description Contents of the box: - 1 case with storage compartments for accessories - 6 pairs of connected PodoSmart insoles in different sizes: 36/37 - 38/39 - 40/41 42/43 - 44/45 - 46/47 - 6 white USB cables - 1 black USB cable - 1 shoulder strap - 1 PodoStation: connection box... -
Page 4: Battery Characteristics
Battery characteristics - Rechargeable lithium-ion battery - Rated voltage: 3.6 V - Load voltage: 70 mA - Life cycle ~ 500 loads - Full charge time: 2h30 - Active mode: 33 h - Total standby time (without use): 2000 hrs. Charging equipment The charging equipment must meet the requirements of IEC60601-1 or IEC 60950-1. -
Page 5: Recommended Minimum Computer Requirements
This equipment complies with the EMC Directive 2014/30 / EU and the MDD Directive 93/42 / EEC on the electromagnetic compatibility of medical equipment and/or medical electrical systems. These limits are designed to provide reasonable protection against interference in a residential installation. -
Page 6: Safety Instructions
Safety instructions Under normal use, there is no identification of hazards or dangerous situations and damage when using the PodoSmart device. The base plate is tightly sealed, the battery and conductive components are sealed in a box made of insulated material. No modifications of the device are permitted. -
Page 7: Operating Instructions
Operating Instructions Intended use: PodoSmart is a device for transferring, converting and displaying running parameters. You collect data from the insole, and the dedicated web interface displays an overview of the gait data on your computer. The patient positions the insole in his or her shoe and walks for at least 30 seconds. No additional training is required to install and operate this device. -
Page 8: Configuration - Create Your Account / Login
Configuration - Create your account / Login 1. Create your account If you have not yet created a PodoSmart account, please register via the following link: https://app.podosmart.tech/auth/sign-up 2. Login If you have already created your account, simply log in via the following link: https://app.podosmart.tech/auth/sign-in 3. -
Page 9: Charging The Insoles
Step 1: Connect your Podostation to the USB port of your computer. Step 2: Click on "Start Search". Step 3: Select your usual WIFI network. Step 4: Enter your WIFI password (you can click on the eye symbol at the end of the password line to verify the information entered) and click "Connect". -
Page 10: Add A Pair Of Insoles
Charge the insole at temperatures between 15°C (59°F) and 34°C (95°F). Warning! Do not use an insole during charging. Remember to recharge the insoles before prolonged non-use to avoid damage to the battery. Add a pair of insoles If you are not already logged in to the software interface, log in to https://app.podosmart.tech Click on the Equipment tab in the menu on the left, then click on + to add a pair of soles. -
Page 11: Check The Battery Level Of The Soles
Check the battery level of the insoles Note that you will NOT be able to see the charge level of your insoles when charging and as long as they are plugged in. Go to the Devices tab, click Check Status if necessary. The battery level of the left and right soles will appear. -
Page 12: Add A Patient
Add a patient Click on the Patients tab, and then click on New Patient. Fill in the form. Required fields are marked with *. Once completed, click on Save. Once the patient has been created, you can add a pathology, a reason for consultation and a history. -
Page 13: Making And Stopping An Acquisition
Making and stopping an acquisition Select the appropriate patient from the patient list (assuming the patient has already been created). Click on "New Acquisition". Make sure that the patient is within 1 to 2 metres of the PodoStation. You can choose between 3 types of acquisitions: walking, running on treadmills and running outdoors. In the next step, you can add the patient's pain, type of shoes and potential walking aids. - Page 14 Then select the pair of soles with which you are going to make the purchase. Finally set the acquisition time and the acquisition start time and press the blue arrow when you are ready. Once the acquisition has started, your patient can run. If you wish, it is possible to stop the acquisition before the time limit has expired by clicking on Stop Acquisition.
- Page 15 Troubleshooting Podosmart uses a self-testing system. The error message is designed to assist you in identifying the action to be taken in case a problem is encountered. Error Action to be taken Equipment No Podostation is currently available online. Connect to the Internet / power supply. No pair of insoles is currently available.
- Page 16 Important notice Insole cleaning instructions Hygiene of the insoles: You may use disposable socks - Do not use the insole without clean socks. We recommend you to perform the following operations on a regular basis: Clean with a damp cloth, a slightly damp microfiber cloth, sanitizer, or an antifungal spray. ...
- Page 17 Recycling The device contains electronic components and lithium-ion batteries. The PodoSmart insoles may not be disposed of in household waste. The device must be taken back by your health care provider, distributor, manufacturer. Label Symbol Explanation EU Directive 2014/53 / of the European Parliament and of the Council of 16 April 2014 on the harmonization of the laws of the Member States relating to the availability on the market of radio equipment (RED).
- Page 18 United States: Statement by the Federal Communications Commission (FCC). This device complies with Part 15 FCC rules. Operation is subject to the following two conditions: "Changes or modifications not expressly approved by Digitsole could void the user's authority to operate the equipment".
- Page 19 Help and support Help – PodoStation Detailed information is available at: https://podosmart.tech/help Contact A question, a suggestion? Do not hesitate! Contact us: +33 (0)3 83 36 72 72 contact@podosmart.tech DIGITSOLE 13 Rue Héré Place Stanislas 54000 Nancy France...
