DKR 250
Installation and user manual
T
HERMOMETER WITH SWITCH
CONTACTS
Description:
Available in two options: maximal and minimal.
Thermometer has two main parts head and stem.
Under the removable cap on the back side, screw
clamps 1 and 2 are located. A protective clamp is
attached to the stem hexagon part. Temperature
sensor is attached to the end of the thermowell. In the
front screen is installed a regulation knob.
Adjustable pointer of maximal temperature is located
to the right from contact pointer.
Adjustable pointer of minimal temperature is located
to the left from contact pointer.
Applications:
DKR thermometer
temperature as a plant thermometer and to signal
when „desired temperature" is reached. Thermowell
has to be used when DKR is in liquid or in humid
environment.
The maximum DKR thermometer is designed to
indicate the maximum temperature
The minimum DKR thermometer is designed to
indicate the minimum temperature.
Thermometer DKR must not be used as a safety element.
Installation:
Position of DKR is optional.
Installation has to be done according ČSN 33 2180
and connection to the elcetric circuit according to ČSN
34 0350 ed. 2 with a flat power cable 2x 0,5 mm2.
Tighten the clamp screws 1 and 2 with torque force no
more than 0,4 Nm.
Technical Data
Scale division
1 °C
1 °C
2 °C
5 °C
DKR 250
is designed to measure
Scale range
-30 to +50 °C
0 to 120 °C
0 to 200 °C
0 to 350 °C
Connect safety clamp with safety power cable to
safety power source.
Only specially trained person with qualification of
§ 6 Vyhlášky č.50/1978 Sb. (Czech law) can
perform DKR installation to power source.
Head should be placed in an environment according
to ČSN 33 2000-1 ed.2, Attachment NM, Table 32-
NM1 with tolerated bias according to ČSN EN 60947-
1 ed.4
• temperature from -5°C to +40°C
• relative
temperatures may be higher, eg 90% at 20 °C)
• altitude up to 2000 m
• degree of pollution 3
• occurrence of solid objects AE1
• electromagnetic, electrostatic or ionizing effects of
AM1
• intensity of sunshine AN11
Stem can be placed accordingly:
• freely
• by inserting into the sliding threaded neck
screwed in the device
• by inserting into the thermowell socket screwed in
the device
Immersion of thermometer:
• for measured range from –30 °C to +50 °C and 0
°C to +350 °C minimum immersion of 80 mm
• for other range minimum immersion of 60 mm
Thermowell has to be used it these cases:
• in measured place is static or dynamic pressure
• in measured place is harsh or aggressive
environment not suitable for stem alone
Seal the thermowell once installed in device with flat
ring 20x24 (20x26). Material choose according to use.
Measuring range
-20 to +40 °C
+20 to +100 °C
+20 to +180 °C
+50 to +300 °C
1 / 2
humidity up to 50%
Stem length [mm]
ø 8 mm [stainless steel (AKVS)]
100 160 250
x x
x x
x x
x x
2018/02d
(at lower
400
x x
x x
x x
x x
