Visual Productions TIMECORE Manual page 61

URI
/core/tm/1/start
/core/tm/1/stop
/core/tm/1/restart
/core/tm/1/pause
/core/tm/1/set
The following table uses variable #1 as an example. The number '1' can be
replaced by any number in the range of [1,8].
URI
/core/va/1/set
/core/va/1/refresh
/core/va/refresh
The following table shows how to active miscellaneous functions.
URI Parameter
/core/blink -
D.2 TCP & UDP
The following table uses actionlist #1 as an example. The number '1' can be
replaced by any number in the range of [1,8]. The table also uses action #2 as
an example. The number '1' can be replaced by any number in the range of
[1,48].
String
core-al-1-1-execute= arg
core-al-1-enable= bool
The following table shows how to manipulate the internal timecode.
String
core-tc-start
core-tc-stop
core-tc-restart
core-tc-pause
core-tc-set= text
Parameter Description
- Start timer #1
- Stop timer #1
- Restart timer #1
- Pause timer #1
time-string Set timer #1 at the time-string
Parameter Description
integer Set the value of variable #1
- Refresh variable #1; a trigger will be generated as if the
variable changed value
- Refresh all variables; triggers will be generated
Description
Momentarily flashes the TimeCore's LED
Description
Execute action #2 inside action list #1
Set the 'enable' checkbox for action list #1
Description
Start timecode
Stop timecode
Restart timecode
Pause timecode
Set the timecode frame at the specified string. For example
"23:59:59.24"
