Sharp Energy Alpha Fury 20 Field Operation Procedure

FIELD OPERATION PROCEDURE :
Alpha Fury 20 Hydraulic Setting Tool

OPERATIONAL PROCEDURE :

1. Run the Alpha Fury 20 Hydraulic Setting Tool and BP/CR several feet below the setting depth. Note:
The Fury circulation ports are located below the ball seat. These ports will allow the tubing to fill going in
the hole or for circulating a maximum rate of ¼ BPM while going in the hole. Well fluid must clean and
free of debris (sand) for the HST to work properly. Warning: The setting sequence will begin at 1,355 psi
differential pressure in the tubing "at the tool" (see step 4).
2. Pick up slowly to setting depth to remove slack from tubing string.
3. Drop a 5/8" diameter brass ball and slowly pump down until it has seated (pressure increase).
4. Slowly pressure workstring to establish a 1,355 psi (1,855 psi max) differential pressure inside the
tubing "at the tool" to begin the setting sequence.
To Shear a 30,000 Pound Shear Stud (5-1/2" – 6" Casing)
5. Continue pressuring workstring to establish a 1,400 psi differential pressure inside the tubing "at the tool"
to anchor the BP/CR against the casing wall. Pick up tubing to the neutral position. Hold pressure for 5
minutes.
6. Continue pressuring workstring to establish a 1,695 psi (2,195 psi max) differential pressure inside the
tubing "at the tool" to complete the set. Pick up on tubing to determine if disconnected from BP/CR. If the
HST has not disconnected from BP/CR then Pick up 1,000 pounds over tubing weight and pressuring
workstring again to establish 1,695 psi (2,195 psi max) inside the tubing "at the tool" to complete set. Over
pressuring HST will cause damage to tool.
To Shear a 55,000 Pound Shear Stud (7" & Larger Casing)
7. Continue pressuring workstring to establish a 1,800 psi differential pressure inside the tubing "at the tool"
to anchor the BP/CR against the casing wall. Pick up tubing to the neutral position. Hold pressure for 5
minutes.
8. Continue pressuring workstring to establish a 3,107 psi (3,607 psi max) differential pressure inside the
tubing "at the tool" to complete the set. Pick up on tubing to determine if disconnected from BP/CR. If the
HST has not disconnected from BP/CR then Pick up 1,000 pounds over tubing weight and pressuring
workstring again to establish 3,107 psi (3,607 psi max) inside the tubing "at the tool" to complete set. Over
pressuring HST will cause damage to tool.
8. Apply 1,000 pounds of set down weight to determine if BP/CR is securely set.
9. The Fury 20 HST will automatically dump pressure when fully stroked out. Clean and re-dress Hydraulic
Setting Tool and Setting Adapter Kit. Over pressuring HST will cause damage to tool.
Alpha Oil Tools
a Sharp Energy Group Company
Release Date: January 27, 2005
Revision Level: 1 (May 6, 2019)
Page: 1 of 2
