- Page 1 POR-0102 2-Port Power over Ethernet Repeater 100 m 100 m 100 m Ethernet Switch 15.4W Power POR-0102 POR-0102 PD1+PD2≦6.5 POR-0102 PD3+PD4≦6.5...
- Page 2 Maximum Range Connect with Standard 15.4W PSE End to end distance 100m 200m 300m 400m 500m Daisy-Channing ( PoE Repeater ) ≦10.9 W ≦6.5 W ≦3.84 W Data only Total Output Power (Out 1+Out 2) No power Connect with Hi-Power 30W PSE End to end 100m 200m 300m 400m 500m 600m 700m 800m...
- Page 3 H. The LED indicators “OUT2” will flash to indicate Ethernet data activity. 100 m 100 m Ethernet Switch Power POR-0102 ** Note: If the Ethernet cable is not standard CAT5 cable, the POR-0102 may be working for shorter length than 100 meter. V1.0...
