Quickstart Guide:
Big Beamer and Jelly Beamer
™
Switch, or Wireless Switch Latch and Timer
(WSLAT)
2
Connecting and Activating
Plug the wireless receiver into a device.
Press the transmitter's switch top.
Signal lights on both components will light up and the
attached device will activate.
Note: Big and Jelly Beamer has an effective range of up to 30 feet.
Computer access requires a switch interface (not included).
1
Powering and turning on transmitters and receivers
Wireless
™
Learn Button
3
Wireless SLAT Set-Up
Mode Button
Select your Mode of Control by repeatedly pressing the
"Mode" button.
The receiver's mode lights will indicate which mode is activated.
For Timed Modes - Adjust the Timer Dial from 1-60 seconds or
minutes as desired.
Note: First half-turn of the Timer Dial ranges from 1-10 sec/min.
Second half-turn ranges from 11-60 sec/min.
On
(WSLAT only)
Mode Lights
Timer Dial
On
Insert two AA batteries into both components as shown on housing.
(Big Beamer transmitter uses 2 AAA batteries)
Slide the power switches on each component to the "On" position.
The components' lights will activate briefly when the components are turned on.
Modes of Control
Direct
Traditional switch behavior - device
remains ON as long as switch is held.
Timed Seconds
Runs device from 1 to 60 seconds with
each activation.
Timed Minutes
Runs device from 1 to 60 minutes with
each activation.
Latch
First activation turns device ON; second
activation turns it OFF.
Programming Tip: Turn the Timer Dial all the way up
to 60 and activate the device. As the desired time
approaches, turn the Dial back down towards 0,
stopping the device at the time desired.
On
