Maximum limit values
Function
V DC / V AC
A DC
Batteries
1
Replacing the battery / fuse
To replace the battery or fuse, first disconnect the test prods from all
voltage sources. Undo all the screws at the rear of the device and
replace the battery or replace the defective fuse by a fuse of the
same type and rating. Do not touch the green pc-board. Also make
sure it is kept clean. Close the housing and carefully screw the meter
back together. Do not switch on the device with the cover open.
1 1 x 1.5 V type AAA
2 F 630 mA / 300 V (Ø 5 mm x 20 mm)
Turn the rotary switch to position
!
prods so that they touch and with rotary knob (3) adjust the
pointer exactly to
possible, the battery needs to be replaced.
14
GB
Maximum limit values
300 V DC, 300 V AC
600 mA
9 V
1
2
Be sure to pay attention to polarity.
0" on the OHM-scale (A). If this is not
"
Ω". Hold the two test
"
