San Diego, CA 92110 USA
www.ecr4kids.com
2-Station See-Thru Art Easel
with Storage & Drying Racks
Model# ELR-0730
WARNING:
Adult Assembly Required.
Two adults recommended.
- Contains small parts, sharp points and
edges.
- Do not stand, sit, kneel, climb, lean or
pull on unit for support.
- Never leave children unattended.
- Do not place unit near high heat or
moisture.
- Adult supervision recommended.
CAUTION:
- Do not allow children to climb on art easel.
- Do not use as a ladder or step.
A
B
TOOLS NEEDED
Screwdriver
10mm Wrench
C
14mm Wrench
Parts List
BEFORE ASSEMBLING, MAKE SURE YOU HAVE ALL THE PARTS
Easel Frame (1)
Batch ID Sticker
located on underside
Acrylic Sheet (2)
Easel Tray (2)
D
E
F
G
K
Apron Screw (2)
40mm
H
L
Screw (10)
35mm
I
Nut (12)
J
M
Metal Washer (18)
Wire Basket (1)
Wire Shelf (1)
Easel Clip (4)
Plastic Washer (20)
Wheel Caster (4)
Apron Hook (2)
Advertisement
Summary of Contents for ECR 4 Kids ELR-0730
- Page 1 San Diego, CA 92110 USA Easel Frame (1) Wire Basket (1) www.ecr4kids.com 2-Station See-Thru Art Easel with Storage & Drying Racks Model# ELR-0730 Wire Shelf (1) Easel Clip (4) Batch ID Sticker located on underside Acrylic Sheet (2) Apron Screw (2)
- Page 2 Install Wire Basket & Wire Shelf Install Casters Place the Wire Basket (D) & Wire Shelf (E) onto the bottom rungs of the frame. Unfold the frame until the side hinges are in the The Wire Basket & Wire Shelf should rest on the crossbars. straight, locked position.
- Page 3 Attach Apron Hooks Attach the Apron Hooks (M) Attach the Acrylic Sheets to the Easel Frame (A) with a Screw (G), 2 Plastic Washers (K), Carefully remove protective paper from 2 Metal Washers (J) & a Nut (I). Acrylic Sheet (B). Attach the Acrylic Sheets (B) to the Easel Frame (A) using the 10mm Wrench &...
- Page 4 Do not use abrasive, ammonia, or other harsh chemicals to clean. Save this sheet in an accessible place. If unsure, always test a small area before Model Number: ELR-0730 applying to the entire acrylic surface. Do not place near heat, moisture or Factory Code: F vaporizer which may cause easel to warp.
