Personal Private 3D mobile theater

Overview

Thank you for choosing of high-tech electronic products to us. Please read the instructions carefully before using this

product. If you start using this product, we will assume that you have carefully read the manual. The company does not provide

any explicit or implicit representations or warranties regarding the contents of this document, especially former chantability and

fitness for a particular purpose applicability does not provide any guarantee. In addition, the company reserves the right of

the revised publications and change the document at any time without informing users.

Product Feature

1. 3D Private mobile theater;

2.80 inch (640*360) private high resolution , high quality mobile theater(at 3 meter away )

3. Amazing 3D UI menu

4. 350°myopia can be naked eye view

5. Special 3D engine driver,can show 3D movie/video more vividly.

6. Play 3D or 2D video,movie.

7. Pupil distance adjust in menu setting

8. 1080P full video/audio play

9. AV-IN connection for TV,FPV,game,DVD,etc.

10. TF card,USB data transmission

11. USB Host function, can connect with U-disk

12. Built-in battery, 4 hours movie play;

13. Humanized adjustable head-mounted design

14.Anytime, Anywhere (outdoor, bed room, car, train, airplane etc)

Keys functions

(Please note only

①

Play/select or OK：

②

Direction up/down：▲ and

③

Left/right：◀ and ▶,

left or right direction, volume up or down.

④

Earphone jacket

⑤

Return：

exit from sub-menu

⑥

Power on/off：

HMD-518 manual

is for power charging, and

long press this button is back to main menu

▼, up or down direction, long press is moving forward or backward

is for host connect with U-disk,etc.)

Table of Contents

Need help?

Do you have a question about the HMD-518 and is the answer not in the manual?

Questions and answers

Summary of Contents for High Tech HMD-518

Page 1 Personal Private 3D mobile theater HMD-518 manual Overview Thank you for choosing of high-tech electronic products to us. Please read the instructions carefully before using this product. If you start using this product, we will assume that you have carefully read the manual. The company does not provide any explicit or implicit representations or warranties regarding the contents of this document, especially former chantability and fitness for a particular purpose applicability does not provide any guarantee.
Page 2 ⑦ microUSB jacket： USB data transfer. ⑧ Backlight/power saving switch：3D/ 2D transfer ⑨ TF card slot ⑩ Reset USB charge jacket :DC 5V power input AV-IN jacket Operations 1.Main menu ◀ and ▶ Press power button for 6 secs, enter into main interface,press to choose function you want, and press confirm.
Page 3 In main interface, press ▲ and ▼to choose music you want, and press to confirm. In the process of playing movie, press ◀ and ▶ to adjust volume,press to play/pause, press to exit from sub-menu, long press back to main menu.
Page 4 6.Last memory: Set video play from last memory point or not. There are “on”、 “off” options. On: set continue to play video last time Off: select and play new video 7. Pupil adjust: Pupil adjust setting: Set pupil adjust or not when turn on the mobile theater there are “once”、...
Page 5 8. Power off: Automatic power off setting, there are “never”、 “last 30 mins”、“last 1 hour” “last 2 hours” options.
Page 6 Battery recharge The product can be charged directly through the USB cable. Power adapter output DC5V/1A (optional) charging, please note charge only by charge port 4~5 charging hours can be fully charged. * The first 3 times charging must be charged to 12 hours. * If not use products for 6 month long time, need to charge the battery once time.
Page 7 3.Get TF card method: Need to get off the face cover showed below first. Specifications HMD-518 Specification Description Name Head-mouned 3D mobile theater Model HMD-518 Color Black/white Storage Expand storage T-Flash card Screen Virtual 80”（2m） Size Type TFT screen Resolution...
Page 8 Function 3D video play Left/right 2D video play USB Host Timing power off 30m、1H、2H Forward/backward DC charge Earphone port 3.5mm Avin port 3.5mm Connection USB2.0 Battery Battery type Lithium ion polymer battery 3.7V Battery capacity 1600mAh Video play time 5v/1000ma Size size 170mmx120mmx70mm(take the real product as standard）...
