Wilson Electronics WTFS91 Quick Start Manual

Parts List
(3) Top Shelves - no handle (18" x 24")
(3) Middle Shelves (18" x 24")
(3) Bottom Shelves with caster sockets (18" x 24")
(6) Sets of fluted legs (4 each set)
(8) 4" Swivel Casters
(1) Electrical Assembly (if ordered)
Hardware pack
SHELF ATTACHMENT
CASTER
H. Wilson Company
2245 Delany Road
Waukegan, IL 60087
Phone: 800-245-7224
www.hwilson.com
sales@hwilson.com
WTFS91 Flat Panel TV Stand
The shelves need to be bolted together as shown
in photo.
1. Match up shelves. Bottom shelves have caster
sleeves. Line up holes and bolt together with
enclosed hardware.
Middle shelves have leg bosses on both upper and
lower parts of shelves. Center middle shelf has
predrilled holes for the TV stand base. Line up
holes and bolt together with enclosed hardware.
Top 18" x 12" shelf has 2 bosses on the underside
only. Center top shelf has predrilled holes for the
TV stand base.
2. Turn bottom shelf set to expose caster sleeves.
you have 8 casters. where the shelves are joined,
place one non locking caster on one side and one
on the other side of the join.
Tap remaining casters into place until fully seated.
Required Tools
(not included)
Optional: metal hammer with
Rubber Mallet
block of wood to cushion impact.
