Safety, Operation, and Procedure Instructions for the CDS Series of
Capacitor Discharge/ Hipot Cable Fault Locators
Equipment to be used by trained personnel only
This Operator Manual contains instructions for the operation of a High Voltage power source. The operator of this equipment
must use good judgement and follow all safety precautions noted in this guide to ensure the protection of himself and others in
close proximity to the test area.
death. Proper grounding of the test set must be done prior to connecting this
unit to a power source.
Danger- Lethal Voltages:
Failure to follow the instructions could result in injury or
CDS
SERIES

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CDS Series and is the answer not in the manual?

Questions and answers

Summary of Contents for High Voltage CDS Series

  • Page 1 Equipment to be used by trained personnel only This Operator Manual contains instructions for the operation of a High Voltage power source. The operator of this equipment must use good judgement and follow all safety precautions noted in this guide to ensure the protection of himself and others in Failure to follow the instructions could result in injury or close proximity to the test area.
  • Page 2 Operator Manual © HIGH VOLTAGE, INC. 31 County Route 7A Copake, N.Y. 12516 Phone 518/329-3275 • Fax 518/329-3271 http://www.hvinc.com...

  • Page 3: Table Of Contents

    T able of Contents About the Operator Manual S E C T I O N 1 General Information Theory of Operation Features and Specifications Controls and Indicators S E C T I O N 2 Setting up the Equipment Operating the Equipment 9-17 Hipot / Burn Mode 9-11...

  • Page 4: About The Operator Manual

    This Operator Manual is organized to provide information on the CDS Series in steps that familiarize the new operator with the entire scope of operation of this test set.

  • Page 5: General Information

    HVI CDS series fault locators all have built in Arc reflection filters for use with most TDR’s (RADAR) on the market at thump voltages up to 25 kV.

  • Page 6: Features And Specifications

    M A N U A L Features and Specifications The CDS Series of cable fault locating test sets provide continuously adjustable output voltages for the test and location of faults in primary cables. The constant energy design provides the maximum energy at the lowest voltage to quicken fault location while not overstressing the cables and terminations.
  • Page 7 O P E R A T O R M A N U A L OPTIONS AVAILABLE • Storage Reel system available for Output and Ground Cables • CDS-36 available with 3.2kJ discharge capacitor - 4 -...
  • Page 8 O P E R A T O R M A N U A L CDS MODEL SPECIFICATIONS See last page of parts list for Specifications - 5 -...
  • Page 9 O P E R A T O R M A N U A L DISCHARGE OPERATING MODE MODE SINGLE HIPOT/ PULSE BURN OUTPUT ADJUST CONTINUOUS DISCHARGE DISCHARGE TIMING INTLK COUPLER MODE OUTPUT TAP 18kV DIRECT RADAR 3 SEC 9 SEC 36kV MAIN POWER...
  • Page 10 The OUTPUT ADJUST control variable transformer sets the output voltage. The 0-100% markings on the knob indicate the low to high setting. The control must be at ZERO (0) to energize the high voltage circuits. The output control must always be returned to zero at the completion of testing, prior to de- energizing the output.
  • Page 11 The use of this switch provides a constant energy for capacitor discharge even at lower output voltages. When in any one of the OFF positions, the high voltage cannot be energized. If the switch is operated during testing, the output will de-energize. When changing tap positions allow 20 seconds for the motorized switch to achieve final position.

  • Page 12: Setting Up The Equipment

    SETTING UP THE EQUIPMENT The setup of this equipment has been minimized by careful consideration for the operator during design. The CDS Series’ one-piece FIELD PORTABLE construction makes this the preferred unit for fault locating. Select a location for the unit that will allow easy viewing of the meters at a safe distance from the test cable.

  • Page 13: Operating The Equipment

    6. Connect the HV lead clamp to the center conductor of the cable being tested. Note: If an output cable reel is being used, connect the high voltage MC connector to the center plug on the reel. The MC connector requires the operator to push IN before pulling...
  • Page 14 11. Choose the appropriate OUTPUT TAP (9/18/36 kVdc, 5/10/20 kVdc) for the cable being tested. When changing tap positions the switch must be in position to energize high voltage, allow 20 seconds for the motorized switch to achieve final position.
  • Page 15 O P E R A T O R M A N U A L 17. At completion of test or operation, the depress the STOP pushbutton, the output cable load will be discharged through an internal discharge resistor. Turn off the MAIN POWER circuit breaker.

  • Page 16: Capacitor Discharge Fault Locating (Thumping)

    6. Connect the HV lead clamp to the center conductor of the cable being tested. Note: If an output cable reel is being used, connect the high voltage MC connector to the center plug on the reel. The MC connector requires the operator to push IN before pulling OUT to disconnect.
  • Page 17 11. Choose the appropriate OUTPUT TAP voltage (9/18/36 kVdc, 5/10/20 kVdc) for the cable fault being tested. When changing tap positions the switch must be in position to energize high voltage, allow 20 seconds for the motorized switch to achieve final position.
  • Page 18 O P E R A T O R M A N U A L over ('Thump') at the fault location and acoustical devices can be used to pinpoint the resulting sound. 17. Upon locating the failure point, depress the STOP pushbutton to interrupt the test cycling. 18.

  • Page 19: Capacitor Discharge Fault Locating (Tdr)

    O P E R A T O R M A N U A L Capacitor Discharge Fault Locating High Voltage Cables Using a TDR Device When testing cables, either single or three phase, there are certain steps that must be observed to ensure safe operation.
  • Page 20 O P E R A T O R M A N U A L Note: If an output cable reel is being used, connect the high voltage MC connector to the center plug on the reel. The MC connector requires the operator to push IN before pulling OUT to disconnect.
  • Page 21 O P E R A T O R M A N U A L Always use a GROUND HOOK to ground the cable(s) prior to disconnecting the output cable. - 18 -...
  • Page 22 O P E R A T O R M A N U A L THIS PAGE LEFT BLANK FOR APPLICATION NOTES - 19 -...

  • Page 23: Performing Special Operations

    The CDS SERIES of fault locators use precision metal film resistors for measurement and calibration of the voltmeter and the current meter. The use of these resistors in both the high voltage tank and the metering circuits has minimized circuit drift due to aging and temperature.

  • Page 24: Return Material

    M A N U A L RETURNED MATERIAL If for any reason it becomes necessary to return any equipment or materials to High Voltage, Inc., the Service Department of High Voltage, Inc. must be notified, and authorization received, prior to the shipment of the equipment.

  • Page 25: Warranty

    High Voltage. This warranty is valid only for normal use of the product. Any use outside High Voltage’s written operation instructions will void this warranty. In addition, any one of the following...
  • Page 26 If inspection discloses that the defect is not one for which High Voltage is liable, that is, is outside the stated terms of this warranty provided by High Voltage, then the purchaser agrees to reimburse High Voltage for all expenses incurred.
  • Page 27 PRINTED CIRCUIT BOARD, HVI # PCB-027 82-538 PRINTED CIRCUIT BOARD, HVI # PCB-033 Not used 84-325 TANK, HIGH VOLTAGE, 5/10/20 kVdc , UNI-POLAR HIGH VOLTAGE CAPACITOR ASSEMBLY 82-533 COUPLER ASSEMBLY, HVI # PCB-019 83-535 VM PRINTED CIRCUIT BOARD, HVI # PCB-001...
  • Page 28 10-496 SWITCH, ROTARY, 1 POLE, 5 POS., 125V, 15A, OHMITE #111-5 10-304 SWITCH, TOGGLE, DPDT, ON-OFF-(ON), 5A, 125V 83-547 SWITCH, ROTARY, HIGH VOLTAGE TAP SWITCH, HVI #HVS-0180A 24-143 MOTOR, GEAR, 24Vdc, 1.2 RPM, McMASTER-CARR# 6409K21 RY1,2 11-112 RELAY, DPDT, 24 Vdc COIL, MIDTEX # 25862C200...
  • Page 29 RESISTOR, METAL FILM, 11.7W, 100 M, 1%, EBG # SSX78-100M SOL1-3 12-201 SOLENOID, PULL TYPE, 24Vdc, GUARDIAN #11HD-C-24VDC T147 TRANSFORMER, HIGH VOLTAGE STEP-UP, HVI # 147 HIGH VOLTAGE CAPACITOR ASSEMBLY 03-205 CAPACITOR, HV, 4 X 20µF, 5kVdc, CONDENSER PRODUCTS # NOC4X5M20K R1-8 01-378 RESISTOR, METAL FILM, 12.5W, 2.5M, 10%, EBG # SSP52-2.5M...
  • Page 30 06-205 SPARK GAP, 90V, CP CLARE# CG90L MISC. 23-119 KNOB, SKIRTED, POINTER, ALCO # PKD-70B-1/4 88-323 50FT SHIELDED EPR X-RAY CABLE ASSEMBLY, HV# CDS-0157A 88-328 50FT GROUND CABLE ASSEMBLY, HV# CDS-0180A SCHEMATIC, WIRING, HV # CDS-0072S REV I 12ft. 22-508 INPUT POWER CABLE, 12/3 07-488 CONN, PLUG, 125V, 20A...
  • Page 31 0-400 mAdc, +/-2% Full Scale Terminations Input line: 10 Ft. Return/High Voltage Cable: 50 ft or 12 ft. for use with cable reel. 2 AWG Braided Ground Lead: 50 ft or 12 ft. for use with cable reel. Size 27w x 27d x 48 high (69CM x 69CM x 122CM) Weight 260 lbs.
  • Page 32 PRINTED CIRCUIT BOARD, HVI # PCB-027 82-538 PRINTED CIRCUIT BOARD, HVI # PCB-033 NOT USED 84-325 TANK, HIGH VOLTAGE, 5/10/20 kVdc , UNI-POLAR HIGH VOLTAGE CAPACITOR ASSEMBLY 82-533 COUPLER ASSEMBLY, HVI # PCB-019 83-535 VM PRINTED CIRCUIT BOARD, HVI # PCB-001...
  • Page 33 10-496 SWITCH, ROTARY, 1 POLE, 5 POS., 125V, 15A, OHMITE #111-5 10-304 SWITCH, TOGGLE, DPDT, ON-OFF-(ON), 5A, 125V 83-547 SWITCH, ROTARY, HIGH VOLTAGE TAP SWITCH, HVI #HVS-0180A 24-143 MOTOR, GEAR, 24Vdc, 1.2 RPM, McMASTER-CARR# 6409K21 RY1,2 11-112 RELAY, DPDT, 24 Vdc COIL, MIDTEX # 25862C200...
  • Page 34 RESISTOR, METAL FILM, 11.7W, 100 M, 1%, EBG # SSX78-100M SOL1-7 12-201 SOLENOID, PULL TYPE, 24Vdc, GUARDIAN #11HD-C-24VDC T147 TRANSFORMER, HIGH VOLTAGE STEP-UP, HVI # 147 HIGH VOLTAGE CAPACITOR ASSEMBLY 03-205 CAPACITOR, HV, 4 X 20µF, 5kVdc, CONDENSER PRODUCTS # NOC4X5M20K R1-8 01-378 RESISTOR, METAL FILM, 12.5W, 2.5M, 10%, EBG # SSP52-2.5M...
  • Page 35 15-114 NEON, #NE2 07-120 CONNECTOR, CABLE, 8 PIN, .1” SPACING, MOLEX # 22-01-2087 07-104 CONNECTOR PINS, .1” SPACING, MOLEX # 08-50-0114 14-001 PRINTED CIRCUIT BOARD, HVI # PCB-001 R1,2 01-164 RESISTOR, METAL FILM, 0.25W, 499K, 1% 11-110 RELAY, PCB MOUNT, SPDT, 24 Vdc COIL, P&B # T70L5D131-24 82-536 CURRENT METER PCB 04-025...
  • Page 36 0-400 mAdc, +/-2% Full Scale Terminations Input line: 10 Ft. Return/High Voltage Cable: 50 ft or 6 ft. for use with cable reel. 4 AWG Braided Ground Lead: 25 ft. Size 27w x 27d x 48 high (69CM x 69CM x 122CM) Weight 260 lbs.
