Summary of Contents for EFE Elektronik lite 1.0
Page 1
How to contact us: If you have any questions about using your Efergy monitor, or if you'd like further advice about energy saving at home or at work, please feel free to contact us: Call Efergy on +44 (0) 8450177 769 Efergy will answer any installation or set-up questions and offer quick energy saving tips.
CONTENTS INTRODUCTION INTRODUCTION Energy metering and monitoring are at the heart of energy management: you need the information to tell when and where you’re saving money. SAFETY The Efergy monitor is an Electricity Display Device or EDD that shows the amount of energy IN THE BOX that a household is consuming at the time the display is read.
SAFETY IN THE BOX IT IS IMPORTANT THAT YOU OBSERVE SOME SIMPLE PRECAUTIONS BEFORE USING Your Efergy Pack includes: Sensor Transmitter THIS PRODUCT. 1x Sensor 1x Transmitter When installing the Efergy monitor you should find that everything is relatively straight- 1x Display Unit forward.
FIND THE FEED CABLE IN YOUR ELECTRICITY METER (UK) Dual Tariff meters (Diagram 3) will often Diagram 3 The Efergy monitor is installed by clipping the sensor around the feed cable of your have an Auxiliary cable running between electricity meter. Cable 3 and Cable 4.
LINKING THE TRANSMITTER AND THE DISPLAY INSTALLATION 1. Ensure three AA batteries are inserted in the transmitter QUICK HINT: FIT THE SENSOR and the display unit. The sensor needs to be fitted to the live feed cable. Sensors are suitable If the LINK is COMPLETED for cables up to 12mm in diameter.
SETTING THE TIME AND DATE SET-UP INSTRUCTIONS The Efergy monitor needs to know the time and date in order to provide you with the correct The Efergy monitor needs to know unit cost per kWh charged by your electricity supplier, information.
DUAL TARIFF MODE Esc. BWD FWD Mode If you have a dual tariff rate meter you may want to set-up the dual tariff function. STEP 3. SINGLE TARIFF SET UP On release you will see the symbol flash. If you are charged one single tariff push Mode Button to confirm.
DISPLAY INFORMATION Example: If you are on an economy-7 tariff which starts at 1am and finishes at 8am, set The Efergy monitor shows instant, historical and average information. at 01:00 set at 08:00. Push the Mode Button to confirm. Select the currency and set the cost per kWh you pay for each tariff, approx 5p/kWh and Some of the information will always be displayed on the screen regardless of whether you 12p/kWh for night and day time rates respectively.
INSTANT MODE HISTORY MODE Days, weeks, months Push the history button to move from daily to weekly to monthly information Transmission signal Use the BWD and FWD buttons to scroll between dates and compare consumption data History Instant Information Push the History Push the Mode Button to access Button to change...
FREQUENTLY ASKED QUESTIONS SPECIFICATIONS Model Name/Number: efergy lite 1.0 If I remove the batteries will I lose the information on the display? If you need to change or remove the batteries, the display has an internal memory, so Frequency: 433.52MHz information stored on the display will not be lost.
