- Page 1 DEFENDER PRESS BRAKE GUARDING SYSTEM Operation Manual LS-CS-M-069 27 Action Road, Malaga WA 6090, Australia PO Box 2368, Malaga WA 6944, Australia +61 8 9249 4388 +61 8 9249 6011 info@lazersafe.com...
- Page 2 Defender Press Brake Guarding System Operation Manual LS-CS-M-069 Document Status Document Reference Code: LS-CS-M-069 Version: 1.04 Released: 01/04/2020 Page i Original Language Version: 1.04 Released: 01/04/2020...
- Page 3 Defender Press Brake Guarding System Operation Manual LS-CS-M-069 Document Revision History Date Manual Software Summary of Change Version Version 02/02/2015 1.00 New manual 5/11/2015 1.01 Changed back gauge mode height from 12mm to 16mm. Updated User Interface Panel system information screen.
- Page 4 Copyright in this documentation is owned by Lazer Safe Pty Ltd. No part of this document may be reproduced or copied in any form or by any means (graphic, electronic, or mechanical including photocopying, recording, taping, or information storage and retrieval systems) without the written permission of Lazer Safe Pty Ltd.
-
Page 5: Table Of Contents
Defender Press Brake Guarding System Operation Manual LS-CS-M-069 Table of Contents About This Manual ........................1 Document Objectives ......................1 Technical Competence Requirements ................... 1 Document Organisation ...................... 1 Related Documentation ....................... 1 Guide to Notes, Cautions and Warnings ................2 Obtaining Technical Assistance .................... - Page 6 Defender Press Brake Guarding System Operation Manual LS-CS-M-069 Transmitter and Receiver Adjustment .................. 14 Initial Alignment ....................... 14 Mounting Brackets ......................14 Tool Change ........................14 Adjustment After Tool Change ................... 14 Periodic Alignment Check ....................17 The Defender User Interface Panel ..................18 User Interface Overview ....................
- Page 7 Defender Press Brake Guarding System Operation Manual LS-CS-M-069 User Menu ........................40 7.2.1 Parameter 0 – Buzzer On/Off ................40 Supervisor Menu ......................40 7.3.1 Parameter 0 – Supervisor Access Code ..............40 7.3.2 Parameter 1 – Field Muted Button Functionality ........... 41 7.3.3...
-
Page 8: About This Manual
• Obtaining Technical Assistance. Document Objectives This manual provides information about the operation of the Lazer Safe Defender Press Brake Guarding System. Technical Competence Requirements All operators of the Defender Press Brake Guarding System should be trained in its use, and the press brake upon which it is installed in a manner that complies with established safety practices. -
Page 9: Guide To Notes, Cautions And Warnings
LS-CS-M-069 Guide to Notes, Cautions and Warnings Note: This symbol indicates helpful information that helps you make better use of your Lazer Safe product. Caution: This symbol alerts you to situations that could result in equipment damage. Warning: This symbol indicates danger. You are in a situation that could cause bodily injury. -
Page 10: Critical Safety Information
• The Defender system must be installed either in the press brake factory, or by specialist technicians trained by Lazer Safe (or its authorised representatives). • The operator must be fully conversant with the operation of the press brake and the risks associated with it, as well as the operation of the Defender Press Brake Guarding System. -
Page 11: Requirements For Factory-Fitted Systems-Within The European Union
Similarly, any alteration of the Defender system, or its bridging, or both, either in part or full is expressly prohibited. Access to the electrical equipment cases of the machine control unit and the components within them is restricted to personnel trained and authorised for this purpose by Lazer Safe. Page 4 Original Language Version: 1.04... -
Page 12: System Overview
Defender Press Brake Guarding System Operation Manual LS-CS-M-069 System Overview The Lazer Safe Defender Press Brake Guarding System is a guarding system designed for hydraulic press brakes that provides a highly effective solution for both operator protection and machine productivity. -
Page 13: System Components
Defender Press Brake Guarding System Operation Manual LS-CS-M-069 System Components The system contains the following components: • LZS-1 Transmitter/Receiver pair. • PGS-2 Safety Controller. • Defender User Interface Panel. • Optical Rotary Encoder. • Bracket System for the LZS-1 Transmitter and Receiver. -
Page 14: Laser Classification And Warnings
Defender Press Brake Guarding System Operation Manual LS-CS-M-069 These sensors are divided into three zones that represent the front, middle and rear of the laser plane (the FR, MI, RE signals). If an obstruction blocks the laser light to any of the sensors, the receiver will turn off the appropriate signal, and the PGS-2 controller will immediately disable downward movement of the press beam. -
Page 15: Mute Point
The laser to punch distance is displayed in mm, and you must ensure that the laser is set to this distance below the punch tip. Refer to Lazer Safe Alignment Reference Guide (LS- CS-M-017) for a step by step description of how to fully align the laser. -
Page 16: Obstruction Detection - From A Stationary Position
Defender Press Brake Guarding System Operation Manual LS-CS-M-069 Note: The Defender User Interface Panel displays the status of the machine, and any action that is required to be performed by the operator. In the following sections the operator messages are shown in the following format: Status –... -
Page 17: Tray Mode - When The Tools Are Closing
Defender Press Brake Guarding System Operation Manual LS-CS-M-069 Mute point Figure 3-6: Tray/Box Mode Operation If the middle sensor is obstructed when the pedal is pressed then the tools will not close. The operator must release and press the pedal again. The system will force the tools to close in safe speed only with the optical protection muted and display the message LASERS INACTIVE until the bend is completed. -
Page 18: Back Gauge Mode
Defender Press Brake Guarding System Operation Manual LS-CS-M-069 Back Gauge Mode Back Gauge mode is used in cases where the back gauge of the press brake is moving forward far enough to obstruct the rear sensor. When Back Gauge mode is enabled, the rear sensor is muted 16mm above the normal mute point, allowing the back gauge to enter the work space without causing an obstruction. -
Page 19: Mute Mode - Restricted (Optional)
Defender Press Brake Guarding System Operation Manual LS-CS-M-069 Press Brake Guarding System ensures that the machine does not exceed safe speed in this mode, particular caution must still be exercised. 3.10 Mute Mode - Restricted (Optional) The Defender system may be installed on machines that do not support dual speed operation. - Page 20 Defender Press Brake Guarding System Operation Manual LS-CS-M-069 The system also monitors the machine process for failures of hydraulic valves, failures of electrical components, and failures in the machine controller software in relation to the actions of the parts of the machine that pose risk to the operator.
-
Page 21: Transmitter And Receiver Adjustment
Initial Alignment When the system is first installed, a complete alignment of the laser transmitter and receiver is required. Refer to Lazer Safe Alignment Reference Guide (LS-CS-M-017) for detailed step by step instructions on how to perform a full alignment. - Page 22 Figure 4-3: Tool Locator Tabs To assist in setting the laser to punch distance correctly, Lazer Safe provides magnetic alignment cards, which are supplied with adhesive backed tool locator tabs. The tool locator tabs can be stuck onto the alignment card at the laser to punch distance. The operator can then attach the magnetic alignment card to the punch, locating the tool tip in the centre groove of the locator tab.
- Page 23 Defender Press Brake Guarding System Operation Manual LS-CS-M-069 If the new tool has changed the laser to punch distance, then the laser will not be aligned to the slots in the alignment card. The example in Figure 4-5 shows a laser that needs to be moved down to return to alignment.
-
Page 24: Periodic Alignment Check
Defender Press Brake Guarding System Operation Manual LS-CS-M-069 Periodic Alignment Check The alignment of the transmitter, receiver and punch should be checked using the supplied Lazer Safe alignment cards at the following times. • After system start-up. • After each tool change. -
Page 25: The Defender User Interface Panel
User Interface Overview The User Interface Panel is an advanced, industrial grade Human Machine Interface (HMI) specifically designed for Lazer Safe optical guarding systems. The operator controls the Defender Press Brake Guarding System through a simple, menu-style user interface. The... -
Page 26: Error Reset Indicator And Reset Button
See the Status and Action screens of the Defender User Interface for further information. If the error cannot be cleared contact your supplier or Lazer Safe Customer Support for assistance. Optional Indicators... -
Page 27: Status And Action Windows
Defender Press Brake Guarding System Operation Manual LS-CS-M-069 5.4.1 Status and Action Windows The Status window informs the operator of the current status of the Defender system, and the machine it is guarding. The information provided by the Status screen includes: •... -
Page 28: The Mode Select Screen
Defender Press Brake Guarding System Operation Manual LS-CS-M-069 MOS 11mm Mute Mode Mute Off-Set Distance Indicates the mute mode Shows the mute off-set option. distance in millimetres. Laser A These symbols show the status of the FRONT, MIDDLE and REAR sensors of the laser receiver –... -
Page 29: Menu Screen
Defender Press Brake Guarding System Operation Manual LS-CS-M-069 Menu Screen The Menu screen gives access to the menus that are used to configure the way that the Defender system operates. There are three levels of access to the menu system; User, Supervisor and System. -
Page 30: User Guides
The User Guides are simple, step by step graphical guides for common procedures that need to be performed regularly on Lazer Safe equipment (such as how to align LZS-1 laser guards). If the guide contains more than one page, the left/right arrow keys can be used to navigate the pages of the guide. -
Page 31: System Information
Connected or Not connected. • HMI version. Defender User Interface Panel software version. HMI type. The User Interface Panel or HMI is used in several Lazer Safe guarding • products. This is the particular guarding system for which the panel has been configured. -
Page 32: System Operation
Defender Press Brake Guarding System Operation Manual LS-CS-M-069 System Operation This section describes the operation of the Defender Press Brake Guarding System from power up. Power-up When the Defender is first powered it displays a start-up screen with the message SYSTEM STARTING –... -
Page 33: Setting The Mute Point
Defender Press Brake Guarding System Operation Manual LS-CS-M-069 Before performing the overrun test check the following. • Open the tools to a minimum opening of 100mm. • Check that the transmitter and receiver are correctly aligned. • Check the laser to punch distance. - Page 34 Defender Press Brake Guarding System Operation Manual LS-CS-M-069 STATUS 0000 ACTION PRESS FOOT PEDAL TOOL MODE MENU INFO SETUP SELECT Figure 6-4: Set Mute Point Prompt Screen Figure 6-5: Material Placement on the Die Note: During mute point set-up the Defender Press Brake Guarding System uses only the front and middle sensors of the receiver to detect the material.
-
Page 35: Resetting The Mute Point
Defender Press Brake Guarding System Operation Manual LS-CS-M-069 Press the foot pedal. Laser A will activate, and the tools will close until the laser is obstructed by the sample material. The Sensor window will show an obstruction, and the SET button will... -
Page 36: Selecting Tray/Box Modes
Defender Press Brake Guarding System Operation Manual LS-CS-M-069 Note: Do not press the foot pedal while the MUTE RESET label is flashing. If the foot pedal is pressed, the mute reset operation will be cancelled. When pressed and released, the MUTE RESET button will flash three times while the mute point is cleared. -
Page 37: Selecting Field Muted Mode
Defender Press Brake Guarding System Operation Manual LS-CS-M-069 Press the GUARD MODE button to enter Tray Mode. • Press the GUARD MODE button again to enter Tray 2 mode. • Press the GUARD MODE button again to return to Normal mode. - Page 38 Defender Press Brake Guarding System Operation Manual LS-CS-M-069 Warning: NO OPTICAL PROTECTION IN FIELD MUTED MODE In Field Muted mode, all optical guarding is deactivated. Although the Defender Press Brake Guarding System ensures that the machine does not exceed safe speed in this mode, particular caution must still be exercised.
-
Page 39: Exiting Field Muted Mode
Defender Press Brake Guarding System Operation Manual LS-CS-M-069 6.6.1 Exiting Field Muted Mode To exit Field Muted mode and return to Normal mode press the GUARD MODE button when the tools are open. If the tools are not open, the Status window will display the message Open tools to enable button function. -
Page 40: Exiting Stop At Mute Mode
Defender Press Brake Guarding System Operation Manual LS-CS-M-069 There are two Stop at mute symbols that can be displayed in the Sensor window. Stop at mute – optical protection is active. Stop at mute – optical protection is muted. 6.7.1 Exiting Stop at Mute Mode To turn off Stop at Mute mode, press the MUTE STOP button when the tools are open. -
Page 41: Exiting Back Gauge Mode
Defender Press Brake Guarding System Operation Manual LS-CS-M-069 6.9.1 Exiting Back Gauge Mode To turn off Back Gauge mode, press the BACK GAUGE button when the tools are open. If the tools are not open, the Status window will display the message Open tools to enable button function. -
Page 42: Exiting Tool Setup Mode
Defender Press Brake Guarding System Operation Manual LS-CS-M-069 Press any button to ex it Figure 6-18: Tool Setup Mode Screen 6.10.1 Exiting Tool Setup Mode Tool Setup mode can be exited by pressing any of the Defender panel buttons when the tools are open. - Page 43 Defender Press Brake Guarding System Operation Manual LS-CS-M-069 If a monitored device fails, the Defender will trigger an E-Stop and display the message External device monitor A turn B error – CHECK EDM A where • A is the number of the monitor; 1,2,3 or 4.
-
Page 44: User And Supervisor Menus
Defender Press Brake Guarding System Operation Manual LS-CS-M-069 User and Supervisor Menus The Menu screen gives access to the menus that are used to configure the way that the Defender system operates. There are three levels of access to the menu system; User, Supervisor and System. -
Page 45: Selecting Menu Parameters
Defender Press Brake Guarding System Operation Manual LS-CS-M-069 Once a menu has been selected the parameters can be navigated, selected and edited. The parameters are stored in non-volatile memory that is maintained even when the Defender system is powered down. -
Page 46: Setting Option Parameters
Defender Press Brake Guarding System Operation Manual LS-CS-M-069 7.1.2 Setting Option Parameters Option parameters are navigated in the same way as menus, using the buttons described in Figure 7-2 Table 7-2. The arrow buttons step through the list of options; the desired option is then selected by pressing the ENTER button. -
Page 47: User Menu
Defender Press Brake Guarding System Operation Manual LS-CS-M-069 Note: The Defender system will not allow a value to be entered which is outside of the allowable range for that parameter. The valid range of values is displayed next to the parameter’s name in the Parameter screen (ignore the units). If an attempt is made to exceed the valid range, an Entry out of range message is displayed, and the value will not be saved. -
Page 48: Parameter 1 - Field Muted Button Functionality
Defender Press Brake Guarding System Operation Manual LS-CS-M-069 Use the ► button to navigate the digits, and the ▲▼ buttons to change the digit value. Changes can be abandoned at any time by pressing the button. When the desired digit has been set press the ENTER button, the value will be written into the Defender’s non-volatile... -
Page 49: Parameter 4 - Language
Defender Press Brake Guarding System Operation Manual LS-CS-M-069 Use the ► button to navigate the digits, and the ▲▼ buttons to change each digit value. Changes can be abandoned at any time by pressing the button. When the desired digit has been set press the ENTER button, the value will be written into the Defender’s non-volatile... -
Page 50: Operator Instruction And Demonstration
Defender Press Brake Guarding System Operation Manual LS-CS-M-069 Operator Instruction and Demonstration Installer Reference #: _______________ Instructor's Name: _________________ Company: _______________________ Signature: ________________________ Date: ___________________________ Ensure that the responsible person - Operator, Foreman or Manager (whoever the company designates as responsible) reads and understands the manual (translate if necessary). -
Page 51: Operation In Normal Mode
Defender Press Brake Guarding System Operation Manual LS-CS-M-069 Operation in Normal Mode Refer to Section 3.4 for a detailed description. Refer to Section 6.5 for selecting guard modes. • Ensure that it is understood what happens when the system runs in normal mode. -
Page 52: Setting The Laser Position
Defender Press Brake Guarding System Operation Manual LS-CS-M-069 Setting the Laser Position Refer to Section 3 and the Lazer Safe Alignment Guide (LS-CS-M-017 Rev 2.0) for a detailed description on laser alignment. • Explain and demonstrate how to adjust the Transmitter and Receiver height. •... -
Page 53: Customer Sign Off - Training Completed
Defender Press Brake Guarding System Operation Manual LS-CS-M-069 8.14 Customer Sign Off – Training Completed Company Name: __________________ Date: ___________________________ Names of Company Representatives: Signatures of Company Representatives: ________________________________ ________________________________ ________________________________ ________________________________ ________________________________ ________________________________ ________________________________ ________________________________ ________________________________ ________________________________ ________________________________ ________________________________ Page 46 Original Language Version: 1.04... -
Page 54: Maintenance
Defender Press Brake Guarding System Operation Manual LS-CS-M-069 Maintenance Transmitter & Receiver To maintain the transmitter and receiver, the filter window on both units should be regularly inspected to ensure they are free from finger prints, grease, dirt and scratches. The filter window should be replaced if it is damaged in any way. -
Page 55: Glossary Of Terms
The distance between the lower and upper tools Open tools Increase the opening, retract the pressing beam Optical protection Lazer Safe laser guards, or OEM light curtains Punch Top tool of the press brake Retract The opening movement of the tools...
