Vehicles manufactured in 2017 and onwards without TPMS
sensors in the tires
10R-058209
speedsignal GmbH
Carl-von-Ossietzky-Straße 3
D- 83043 Bad Aibling
Installation Guide
RunLock
Volvo XC 60
Volvo XC 90
Volvo V 90
Volvo S 90
Art. No. B-339VO03
Phone:
+49 8061 49518 – 0
Fax:
+49 8061 49518 – 10
E-Mail:
info@speedsignal.de
Homepage: www.speedsignal.de
facebook:
facebook.com/speedsignal
Advertisement
Table of Contents
Related Manuals for Speedsignal RunLock B-339VO03
Summary of Contents for Speedsignal RunLock B-339VO03
- Page 1 Volvo XC 90 Volvo V 90 Volvo S 90 Vehicles manufactured in 2017 and onwards without TPMS sensors in the tires Art. No. B-339VO03 10R-058209 speedsignal GmbH Phone: +49 8061 49518 – 0 E-Mail: info@speedsignal.de Carl-von-Ossietzky-Straße 3 Fax: +49 8061 49518 – 10 Homepage: www.speedsignal.de...
-
Page 2: Table Of Contents
The installation of this product should only be carried out by trained specialist personnel and in accordance with this manual. speedsignal GmbH cannot accept any liability for injury to persons or damage to property from errors or mistakes in this operating manual. -
Page 3: Installation Guide
Installation Guide: TX 25 Flap to the left of the steering wheel Control unit CEM Open the indicated screws and remove Attached to the A-pillar Open the indicated screws CAN tap on the OBD connector OBD socket rear panel Connector FL - CEM Connector IP - CEM Installation Button 6003131 The button can be installed on a free button, as recommended on page 4. -
Page 4: Tap Points
Tap Points There are 2 CAN taps on the vehicle, described here with CAN1 high / low and CAN2 high / low. A tap is made on the FL connector of the CEM and a tap on the OBD connector. Front view OBD Plug Cable Colour... -
Page 5: Connection Diagram
Connection Diagram Plug FL at the CEM OBD socket Plug IP at the CEM RunLock button battery B-339VO03 Revision 3... - Page 6 Pin Assignment 6-pole minifit-plug Input/Output Designation Cable Colour Remark Input CAN1-Low white-brown not assigned not assigned Input CAN1-High white-yellow Input green-grey not assigned Pin Assignment 10-pole minifit-plug Input/Output Designation Cable Colour Remark Input ground brown not assigned not assigned Output illumination orange buttons...
-
Page 7: Functionality Test
Warranty Conditions: speedsignal GmbH guarantees within the legal deadline of 2 years from the original date of purchase that this pro- duct is free from defects in material and workmanship as long as this product was installed similar to our installa- tion-on guide. -
Page 8: Service
