EMX Industries WEL-200 Series Instruction Manual

Instruction Manual
(For red circuit boards)
The WEL-200 is a complete wireless solution for interfacing sensing edges to gate and door operators,
while ensuring compliance
(per page 4, step 6) requires the edge (sold separately) to have a built-in resistor
with a value between 4K – 12K ohms. Non-resistive edges DO NOT work with this system.
Each receiver can connect with up to four transmitters with separate relay and pulse outputs for open and
close edge functionality. Each transmitter can run for up to two years on two AA lithium batteries.
With enhanced diagnostic features, installation and maintenance for the WEL-200 is easy and reliable.
Feedback is provided for all fault modes, including edge open, short conditions, low battery and
failed transmitters.
Specifications
Operating Range
Operating Frequency
Response Time
Operating Temperature
Power
Current Draw
Surge Protection
Outputs
Edge Resistance Range
Dimensions
Connections
Ordering Information
• WEL-200K
• WEL-200R
• WEL-200T
EMX Industries, Inc.
WEL-200_Rev3.0_081820
WEL-200
Wireless Edge Link
with UL325
Receiver (WEL-200R)
12-24 VDC/AC
1 Relay – 42mA, 2 Relay – 70mA
Thermal fuse, MOV
300 Hz pulsed, or relay with
selectable 10K ohm resistor across
normally open contact
5.5" (140 mm) x 1.3" (34 mm)
x 3.5" (90 mm)
12 terminals
Wireless edge link kit, includes WEL-200R, WEL-200T, 2 cable grip inserts and
2 AA lithium batteries
Wireless edge link receiver
Wireless edge link transmitter
Tech support: 216-518-9889
technical@emxinc.com
™
monitoring standards.
200 ft (line of sight)
915 MHz (25 possible channels)
100 ms
-40° to 140°F (-40 to 60°C)
–
The WEL-200 Transmitter
Transmitter (WEL-200T)
2 AA lithium batteries
~ 2 year life
N/A
Thermal fuse
N/A
4K – 12K Ohms
7" (180 mm) x 1.3" (32 mm)
x 2.6" (67 mm)
2 terminals
TM
1/5
