- Page 2 Thank you for purchasing a Pro‐LIFT G5. The Pro‐LIFT product line is designed to enhance your interactive whiteboards and projectors or LCD. Please follow all assembly instructions correctly to provide optimal use. Only a qualified contractor should install the Pro‐LIFT G5. If you do not understand any of the assembly instructions, please contact your local re‐seller or visit www.proliftstand.com. IMPROPER INSTALLATION CAN CAUSE DAMAGE TO YOUR Pro‐LIFT AND LEAD TO SERIOUS PHYSICAL INJURY. JORO Manufacturing cannot take any responsibility for damage or injury resulting from improper installation. Do not operate Pro‐LIFT G5 if there are any obstructions below or above the board. Doing so may cause unit malfunction or lead to serious physical injury. The supplied mounting hardware is for use on the Pro‐LIFT stands only. If you encounter any problems or insufficient hardware during installation, please contact your local re‐seller. ...
- Page 3 G5 Main Frame Kit LCD Mount Fastener Kit (ONLY available with G5L & G5L-PRO Models) 5/32" Allen (Hex) Key 3/16" Allen (Hex) Key WB Fastener Kit (ONLY available with G5W & G5W-PRO Models) Machine Screw Insulator M5 Allen (Hex) Key 5/32"...
- Page 5 Pro-LIFT G5 Foot 1 5/16x1-1/2" Button Head Mount the Pro-LIFT G5 Feet For ease of installation, do this step while Pro-LIFT G5 is lying down Be sure to use the 5/16x1-1/2" Button Head screws provided Be sure to NOT over tighten www.joromfg.com www.proliftstand.com...
- Page 6 M6 x 20mm Socket Cap Screw 2 Turret Head 5/16x1" Button Head 5/16x1" Button Head 5/16x1" Button Head 5/16x1" Button Head Mount the Turret Head Be sure to use the M6 x 20mm Socket Cap Screws (Low Profile) provided Be sure to NOT over tighten If necessary, loosen 5/16x1"...
- Page 7 M6 x 20mm Socket Cap Screw 5/16x1-1/2" Button Head 5/16x1-1/2" Button Head Mount the Pro-LIFT G5 Accessory Shelf Be sure to use the M6 x 20mm Socket Cap Screws supplied Be sure to NOT over tighten If necessary, loosen 5/16x1-1/2" Button Head screws to align holes REMEMBER to tighten screws, but DO NOT over tighten www.joromfg.com...
- Page 8 4 Machine Screw Insulator Machine Screw Insulator 1/4" Nylon Washer 1/4" Nylon Washer M6 x 20mm Socket Cap Screw M6 x 20mm Socket Cap Screw Mount the Pencil Tray Adapters (may not be exactly as shown) Be sure to use the following supplied parts: 1.
- Page 9 M6 Hex Nut 1/4" Washer 5 WB Hanger (SL-607) Part#: G5-ACC-WBH M6 Hex Nut 1/4" Washer M6 x 20mm Socket Cap Screw M6 x 20mm Socket Cap Screw 5/16x3/4" SILVER Button Head screw Be sure to tighten on both angles once WB Hanger has be installed.
- Page 10 6 3/8" x 4" Lg. - 5/16" Hex Socket Head Shoulder 3/8" Washer Laptop Tray Slider Arm Laptop Tray Arm 3/8" Nylon Washer M6x8mm SILVER Button Head 5/16" Washer 5/16" Nylon Locking Nut Mount the Laptop Tray Arm (if the Laptop Tray was ordered with your product) Fasten the Laptop Tray Arm to the Laptop Tray Slider Arm using the M6x8mm SILVER Button Head Screws supplied If the 3/8"...
- Page 11 7 Laptop Tray M6x8mm SILVER Button Head M6x8mm SILVER Button Head Mount the Laptop Tray (if ordered with your product) Be sure to use the fasteners from the LTT Kit Be sure to NOT over tighten www.joromfg.com www.proliftstand.com COPYRIGHT 2014 ProLift G5 - G5W ASSY Instructions : 0.003...
- Page 12 8 Mounting patterns for tested projectors Match holes in the diagram to projection system being used Fasten projector to the corresponding holes using the JORO Button Head Screws supplied Be sure to NOT over tighten www.joromfg.com www.proliftstand.com COPYRIGHT 2014 ProLift G5 - G5W ASSY Instructions : 0.003...
- Page 13 Mount the white board Use the holes which correspond to manufacturers recommended projector to image distance Fasten using the JORO Button Head screws supplied Be sure to NOT over tighten Note, there are drilled/tapped holes on the frame upright, if lowering the board is required 9 ...
- Page 14 10 ...
- Page 16 Pro-LIFT G5 Foot Pro-LIFT G5 Foot 1 5/16x1-1/2" Button Head Mount the Pro-LIFT G5 Feet For ease of installation, do this step while Pro-LIFT G5 is lying down Use the 5/16x1-1/2" Button Head screws provided Do NOT over tighten www.joromfg.com www.proliftstand.com COPYRIGHT 2014 ProLift G5 - G5L ASSY Instructions : 0.004...
- Page 17 Pro-LIFT G5 Accessory Shelf Part#: WF122412PROL M6 x 20mm Socket Cap Screw 5/16x1-1/2" Button Head Mount the Pro-LIFT G5 Accessory Shelf 5/16x1-1/2" Button Head Use the M6 x 20mm Socket Cap Screws supplied Do NOT over tighten If necessary, loosen 5/16x1-1/2" Button Head screws to align holes REMEMBER to tighten screws, but DO NOT over tighten www.joromfg.com...
- Page 18 5/16x1" SILVER Button Head Pro-LIFT LCD ARM 5/16x1" SILVER Button Head Pro-LIFT LCD ARM Remove Pro-LIFT LCD Arms Remove 5/16x1" SILVER Button Head screws and store in safe place to re-use once LCD is installed. Remove Pro-LIFT LCD Arms www.joromfg.com www.proliftstand.com...
- Page 19 5/16 Hex Nut 5/16 Hex Nut 5/16x1" SILVER Button Head 5/16x1" SILVER Button Head 4 5/16 Hex Nut G5-ACC-PT5 5/16 Hex Nut 5/16x1" SILVER Button Head 5/16x1" SILVER Button Head Fasten the 5/16x1" SILVER Button Head screws to the G5-ACC-PT5 Be sure to NOT over tighten 5/16 Hex Nut 5/16x1"...
- Page 20 5 Please use the appropriate mounting holes for your LCD (not included) as shown above G5-ACC-PT5 G5-ACC-PT5 LCD fastener from LCD TV kit provided Fasten the G5-ACC-PT5 to your LCD (not included) using the fasteners from the LCD TV Kit. Use the appropriate fasteners as specified in the LCD owners manual Do NOT over tighten www.joromfg.com...
- Page 21 5/16" Washer Narrow 5/16 Hex Nut Pro-LIFT LCD ARM 5/16" Washer Narrow Mount the Pro-LIFT LCD Arms to G5-ACC-PT5 tubes Mount the Pro-LIFT LCD Arms prior to hanging on the Pro-LIFT G5L Use the fasteners supplied Do NOT over tighten www.joromfg.com www.proliftstand.com COPYRIGHT 2014 ProLift G5 - G5L ASSY Instructions : 0.004...
- Page 22 7 5/16x1" Button Head 5/16x1" Button Head 5/16x1" Button Head Hang the LCD Assembly Hang on all four (4) pins on uprights If necessary, loosen the 5/16x1" Button Head screws to align holes REMEMBER to tighten screws, but do NOT over tighten www.joromfg.com www.proliftstand.com COPYRIGHT 2014...
- Page 23 8 5/16x1" SILVER Button Head 5/16x1" SILVER Button Head Secure Pro-LIFT LCD Arms to Pro-LIFT G5L Frame Use the 5/16x1" SILVER Button Head screws that were removed earlier Do NOT over tighten www.joromfg.com www.proliftstand.com COPYRIGHT 2014 ProLift G5 - G5L ASSY Instructions : 0.004...
- Page 24 9 3/8" x 4" Lg. - 5/16" Hex Socket Head Shoulder Bolt 3/8" Washer Laptop Tray Slider Arm Laptop Tray Arm 3/8" Nylon Washer M6x6mm Button Head 5/16" Washer 5/16" Nylon Locking Nut Mount the Laptop Tray Arm (if the Laptop Tray was ordered with your product) Fasten the Laptop Tray Arm to the Laptop Tray Slider Arm using the M6x6mm Button Head Screws supplied If the 3/8"...
- Page 25 10 Laptop Tray M6x6mm Button Head M6x6mm Button Head Mount the Laptop Tray (if ordered with your product) Use the fasteners from the LTT Kit Do NOT over tighten www.joromfg.com www.proliftstand.com COPYRIGHT 2014 ProLift G5 - G5L ASSY Instructions : 0.004...
- Page 26 11 Cable Tray #12 x 5/8" Pan Head Wood Screw Mount the Cable Tray (if ordered with your product) Use the #12 x 5/8" Pan Head Wood Screws supplied Do NOT over tighten www.joromfg.com www.proliftstand.com COPYRIGHT 2014 ProLift G5 - G5L ASSY Instructions : 0.004...
- Page 27 12 Wire Mgmt Molding Laptop Tray (if ordered with your product) Mount the Wire Mgmt Molding JORO recommends attaching the Wire Mgmt Moldings supplied Remove the backing from the double sided tape and attach to side of frame upright www.joromfg.com www.proliftstand.com COPYRIGHT 2014 ProLift G5 - G5L ASSY Instructions : 0.004...
- Page 28 12 ...
