Storage shelf
Mounting Instructions
NOTICE:
The storage shelf should be mounted by at least 2 persons.
Bachmann GmbH
Ernsthaldenstraße 33
70565 Stuttgart
Germany
Telefon: +49 711 86602-0
Telefax: +49 711 86602-34
E-Mail: info@bachmann.com
Internet: www.bachmann.com
700.9000_Mounting_Instruction_REV01_ENG
1
Advertisement
Related Manuals for Bachmann 700.9000
Summary of Contents for Bachmann 700.9000
- Page 1 Storage shelf Mounting Instructions NOTICE: The storage shelf should be mounted by at least 2 persons. Bachmann GmbH Ernsthaldenstraße 33 70565 Stuttgart Germany Telefon: +49 711 86602-0 Telefax: +49 711 86602-34 E-Mail: info@bachmann.com Internet: www.bachmann.com 700.9000_Mounting_Instruction_REV01_ENG...
- Page 2 Mounting Instructions Step 1: Four screws and corresponding accessories (not included in the scope of delivery) are required for fastening. Step 2: Switch on the battery and adjust the monitor box to reachable height. 700.9000_Mounting_Instruction_REV01_ENG...
- Page 3 Step 3: On the top of the storage shelf is the screw attachment kit located. Step 4: Attach the storage shelf to the bottom end of the back of the monitor box. 700.9000_Mounting_Instruction_REV01_ENG...
- Page 4 Step 5: Place the top of the storage shelf in the location shown. Step 6: Mount the storage shelf by tightening the screws in the places provided. 700.9000_Mounting_Instruction_REV01_ENG...
- Page 5 700.9000_Mounting_Instruction_REV01_ENG...
- Page 6 Step 7: The storage shelf is now mounted on the monitor box. 700.9000_Mounting_Instruction_REV01_ENG...
- Page 7 Step 8: For example, place your Barco Clickshare USB dongle in the corresponding storage tray. 700.9000_Mounting_Instruction_REV01_ENG...
