1. Introduction of Subaru SD Card Navigation System Outline of Subaru SD Card Navigation System Applicable Models Vehicle Country SUBARU No. SD Part No. Map Ver. FB678US 86271AJ67A 13MY Legacy / Outback 86283AJ67A w/ H/K Amp CANADA FB778US 86271AJ77A 2011 Q3...
Page 5
Summary of Features 13-14MY Legacy / Outback Display 7-inch WVGA Deck Single CD Satellite radio iPod/iPhone control USB Audio/Video HD Radio Aha Radio SD Picture SMS/Email read out Voice recognition Yes (English, Spanish, French) Motorway service information Green route search 3D Junction display Navi Traffic information...
1. Introduction of Subaru SD Card Navigation System Hardware TUNE/TRACK knob INFO button Rotate to select a radio Press to display the station, track, or file. information screen. AUDIO button MAP button Press to display the audio Press to display EJECT button the navigation screen.
Screen Layout Control of Audio Source Basic Control of Navigation Function Selector Audio Function <Navigation Mode> Split Screen <Audio Mode> [AUDIO] Full Audio Screen Changing the screens can be done by touching the icon on the screen. Full Map Screen [MAP]...
1. Introduction of Subaru SD Card Navigation System Software The main functions of the system include: (1) Audio (2) Navigation (3) Information (1) Audio function In addition to radio and CDs, the system can also play back sources such as iPods, iPhones, USB and Bluetooth Audio devices.
Audio Function HD radio, XM, Aha Integrated HD Radio, XM and Aha Aha Radio XM Traffic Information HD Radio, XM Tuner Control Smartphone with Data service is required for Aha functions. Aha Radio is not avail- able for 86271AJ67A and 86271AJ77A. HD Radio service available in USA only XM is paid service and subscription is required (as of May 2013)
Page 10
1. Introduction of Subaru SD Card Navigation System Audio Function Movie <USB flash memory> Max data size: 8GB Class: USB mass storage class *Compressed video file is supported for USB only. <Read and play condition> Max picture resolution size: 720*576 pixel Max layers of directory: 8 layers Max number of folders (overall): 3000 Max number of files (overall): 9999...
Navigation Function 3D Junction Display When approaching an ex- pressway exit or a compli- cated intersection, the map switches to a 3D display. Voice Recognition By using the voice control system, the destination can be set by speaking voice commands. This enables you to use functions that are usually inaccessible while driving.
1. Introduction of Subaru SD Card Navigation System Other Function Rear View Camera (Option) Reverse On Appear guidance line R 3.0m (10 ft) 2.0m (7 ft) 1.0m (3 ft) 0.5m (1.6 ft) from the edge of Vehicle Center of vehicle Read out SMS/Email Navigation Mobile phone...
Page 13
Map Update NAVTEQ Map Update Service NAVTEQ, acquired by Nokia provides Map Update Service for SD Card Navi- gation System. Please visit the website and make sure which map version is currently available. https://subaru-aus.naviextras.com/ Map Update Support: If you can't find the answer to your question or for advice on the map inside Navigation System, please contact NAVTEQ via website or call NAVTEQ at 1-888-628-6277 Monday through Friday, 9am - 8pm Eastern Time.
2. Troubleshooting System Diagram Display LVDS: Low voltage differential signaling LVDS XM-ANT GPS-ANT Navigation RADIO-ANT Head Unit Back NTSC RADIO Camera AM/FM ANT-AMP (If applicable) Bluetooth SD slot MINI JACK HD Radio (AUX) Aha Radio USB2.0 STEERING HD Radio service available in USB JACK USA only (as of May 2013) Aha Radio is not available for...
Connections and Pins Connector A Connector B Connector C Not in use Connector D Connector F Connector E Connector G USV1 USB audio power supply (5V) Connector A (USB) US1- IN/OUT USB audio data US1+ IN/OUT USB audio data UGD1 Ground USG1 Ground...
Page 16
2. Troubleshooting Connections and Pins Audio signal (Front Right) Connector D (POWER INPUT/ Audio signal (Front Left) SIGNAL OUTPUT) ACC power supply BU+B Back-up power supply Audio signal (Front Right) Audio signal (Front Left) Ground ANT+ Antenna amplifier power supply (12V) AMP+ Audio amplifier power supply (12V) ILL+...
Page 17
Connections and Pins SUB-ANT-IN Radio signal (Sub) Connector F (RADIO SUB-ANT-GND Ground ANTENNA) MAIN-ANT-IN Radio signal (Main) MAIN-ANT-GND Ground N.C. No connection Connector G XM SIG XM signal (XM ANTENNA) XM ANT +B XM Antenna +B (5V) Ground Ground...
2. Troubleshooting Specification of Line Diagram 1. Outline Line Diagram can check the connectivity of devises, the vehicle signals, the radio reception and rear view camera setting. 2. How to enter Line Diagnostic mode 2-1. Enter the Diagnostic mode Procedure: 1.
Page 19
3. Display Layout and Explanation 3-1. Top Display Layout ① ⑤ ② ⑥ ③ ⑦ ④ Explanation Explanation Main title Enter Camera Setting ④ [White] after check Vehicle Signal ① ⑤ [Black] under check Vehicle Signal Check Results ⑥ Connected Devices ②...
Page 20
2. Troubleshooting Specification of Line Diagram 3-3. Enter “Audio Check” If the "Audio Check" button is touched, the screen changes to “Audio Check” mode. Explanation Line Diag Line Diag Return Return ⑬ Return to Previous Screen ⑬ Audio Check Audio Check Selection of Radio Band (AM/FM) ⑭...
2. Troubleshooting NO POWER Condition: Absolutely no power in all modes Check all connections at the rear of the unit. Securely connected? Connect Securely Check ACC(12V), BU Check fuses, pin condi- (12V) and GND. tion/fit, continuity to GND. Re-check for original Is ACC BU and GND problem Repair or replace if nec-...
NO SOUND (All modes) Condition: Absolutely no sound on all modes No sound output for all audio sources/modes. Is the VOLUME set to a Turn up VOLUME and re- sufficient level for the check for original problem. audio source to be audi- ble? Replace or repair it and re- Check all speakers im-...
2. Troubleshooting NO SOUND (AM/FM) Condition: No sound on Radio mode (AM/FM) only No sound output for Radio mode. Is the VOLUME set to a sufficient level for the Turn up VOLUME and audio source to be audi- recheck for original ble? problem.
NO SOUND (SAT RADIO) Condition: No sound on SAT radio mode only No sound output for SAT (Satellite) radio Check surroundings: Is the vehicle in an environ- Move the vehicle and ment where reception is diffi- check it again. cult due to something blocking the area above the vehicle? Change to other modes (AM/ FM/CD) and then select a XM...
2. Troubleshooting NO SOUND (CD) Condition: No sound on CD mode only No sound output for CD mode. Does the Navigation Is there any foreign object Replace Navigation Head Unit accept and (ex. label) in the CD slot? Head Unit eject audio CD discs correctly? Re-install Navigation...
NO SOUND (USB) Condition: No sound on only USB mode No sound output for USB mode. The Navigation Head Unit only playback Does USB memory MP3/WMA files in USB have MP3/WMA files? mode. Check the USB con- nectivity in diagnostic Re-connect USB.
2. Troubleshooting NO SOUND (iPod) Condition: No sound only iPod mode Is iPod compatible? See page 91 Q48 for a Non supported iPod list of compatible Apple may not work. Products. Check the USB connectivity in diagnostic mode since iPod Re-connect iPod cable.
CD SKIP CD skips during play- back. Check the location if road Does CD skipping only Does CD skipping hap- condition is good (Ex. dirt occur when vehicle is in pen at the same loca- road, railroad track, road motion? tion? construction may cause CD skipping).
2. Troubleshooting CD WON’T PLAY CORRECTLY Condition: CD Skips, CD jumps tracks CD won't play correctly Is the CD clean and free Please clean the CD of scratches and finger and try again. prints? Do not use CDs with a label. They may cause the disc to get stuck Is a paper label on the inside or damage the Navigation...
SOUND IS DISCOMFORTING Condition: Sound poor, sound too low, sound Sound output is noisy. too loud, and sound distorted Move to an area with Is the sound noisy for Is sound noisy for Is sound noisy for Radio Radio Is the noise heard even in good reception and mode only or ALL modes? Radio mode or All...
Page 32
2. Troubleshooting NO ILLUMINATION Condition: No front panel button illumination Front panel illumination doesn't turn ON. Check the ILL+ signal in Check if the ILL+ wire harnesses diagnostic mode. is connected correctly. Does the diagnostic dis- Does the illumination turn ON? play shows “ON”? The problem was solved.
Page 33
NO DISPLAY Condition: No display, no screen backlight Display does not show images on screen. Press the MAP button on the Navigation Head Unit. Problem solved. Does the LCD light up? Replace Navigation Head Unit Caution: Do not remove the display from the main unit portion. Unit is one piece. GOOD...
2. Troubleshooting CURRENT GPS POSITION DOES NOT MOVE Condition: Vehicle position icon inaccurate, Vehicle position icon doesn’t move Current GPS position on map doesn't move even though vehicle is in motion. Drive vehicle in an open area with no obstructions (buildings, hills, structures).
BLUETOOTH DOES NOT WORK Condition: Bluetooth device will not pair to the system Gather following Infor- mation from customer; Service provider, phone manufacturer and model Bluetooth devices that are not listed on Subaru web may not pair to the system. Note: Bluetooth devices that are not listed as in- Is Bluetooth device compatible? compatible or compatible have not been tested.
2. Troubleshooting REAR VIEW CAMERA WON’T DISPLAY Condition: Rear View video not shown Check the rear view Rear view camera camera and re-connect. won't display or gets a And check the connec- noise in the display. tivity in diagnostic mode. If it will not restored, rear view camera needs to be examined and/or re-...
AHA RADIO - Caution Message (1) Caution Message: Please make sure the Aha app is Note: Aha Radio is not available for running on your mobile device. 86271AJ67A and 86271AJ77A Symptoms: Aha application shuts down by itself • Unable to enter Aha Mode •...
Page 38
2. Troubleshooting AHA RADIO - Caution Message (2) Caution Message: Please update your Aha Note: Aha Radio is not available for application. 86271AJ67A and 86271AJ77A Symptom: Unable to enter Aha Mode Reinstall the latest Aha Is the latest Aha application No / Unknown application on Smart- properly installed on Smart-...
Page 39
AHA RADIO - Caution Message (3) Caution Message: Please reconnect mobile Note: Aha Radio is not available for device. 86271AJ67A and 86271AJ77A Symptom: Unable to enter Aha Mode on vehicle Navigation Head Unit Disconnect Unit-Smartphone communication and reconnect Smartphone. Is the problem fixed? Turn OFF and ON Smartphone and open Aha application on The problem was...
Page 40
2. Troubleshooting AHA RADIO - Caution Message (4) Caution Message: Note: Poor wireless reception. Aha Radio is not available for 86271AJ67A and 86271AJ77A Symptoms: Programs are not played on vehicle Navigation Head Unit • Images are not shown on vehicle Navigation Head Unit •...
Page 41
AHA RADIO - Caution Message (5) Caution Message: Note: Entry not recognized. Aha Radio is not available for 86271AJ67A and 86271AJ77A Symptom: All Aha Mode functions on vehicle Navigation Head Unit do not work Turn OFF and ON Smartphone and open Aha application on The problem was Smartphone.
Page 42
2. Troubleshooting AHA RADIO - Caution Message (6) Caution Message: Please login to the Aha app on the Note: Aha Radio is not available for mobile device. 86271AJ67A and 86271AJ77A Symptom: Unable to enter Aha Mode on vehicle Navigation Head Unit Login into the Aha application on Smartphone.
Page 43
AHA RADIO - Caution Message (7) Caution Message: Note: The station list cannot be acquired. Aha Radio is not available for 86271AJ67A and 86271AJ77A Symptom: Aha Radio Station List is not shown on vehicle Navigation Head Unit Turn OFF and ON Smartphone and open Aha application on The problem was Smartphone.
Page 44
2. Troubleshooting AHA RADIO - Caution Message (8) Caution Message: Note: The content cannot be acquired. Aha Radio is not available for 86271AJ67A and 86271AJ77A Symptom: Aha Radio Content is not shown on vehicle Navi- gation Head Unit Press (Refresh button) on Unit.
Page 45
AHA RADIO - Caution Message (9) Caution Message: Note: Information acquisition error. Aha Radio is not available for 86271AJ67A and 86271AJ77A Symptom: Aha Radio Icons or Logos are not shown on vehicle Navigation Head Unit Return to Station List and se- lect the same station again.
Page 46
2. Troubleshooting AHA RADIO - Caution Message (10) Caution Message: Note: Action not available. Aha Radio is not available for 86271AJ67A and 86271AJ77A Symptom: All Aha Mode functions do not work on vehicle Navigation Head Unit • Forward/Reverse functions do not work on vehicle Navigation Head Unit •...
Page 47
AHA RADIO - Caution Message (11) Caution Message: Aha Server Error - Please check Note: Aha Radio is not available for connection or reception. 86271AJ67A and 86271AJ77A Symptom: Aha Radio content cannot be played on vehicle Navigation Head Unit Move vehicle to an area where Smartphone has better recep- The problem was tion.
Page 48
2. Troubleshooting AHA RADIO - Caution Message (12) Caution Message: Note: Aha Server Down - Please try again later. Aha Radio is not available for 86271AJ67A and 86271AJ77A Symptom: Aha Radio content cannot be played on vehicle Navigation Head Unit Wait for about 10 minutes and try again.
Page 49
AHA RADIO - Caution Message (13) Caution Message: Aha Station Contents Not Available - Note: Aha Radio is not available for Please Try Again Later. 86271AJ67A and 86271AJ77A Symptom: Aha Radio content cannot be played on vehicle Navigation Head Unit Move vehicle to an area where Smartphone has better recep- The problem was...
Page 50
2. Troubleshooting AHA RADIO - Caution Message (14) Caution Message: Aha Communication Error - Please Note: Aha Radio is not available for Check Owner's Manual. 86271AJ67A and 86271AJ77A Symptom: Aha Radio content cannot be played on vehicle Navigation Head Unit Move vehicle to an area where Smartphone has better recep- The problem was...
Page 51
AHA RADIO - Caution Message (15) Caution Message: Note: Aha Radio is not available for 86271AJ67A and 86271AJ77A Failed. Symptom: Map is not updated when pressing “Map Update” button of Aha Radio on vehicle Navigation Head Unit Map Update Button Move vehicle to an area where Smartphone has better recep- The problem was...
Page 52
2. Troubleshooting AHA RADIO - Caution Message (16) Caution Message: Please select the type of connection Note: Aha Radio is not available for in 'Aha Radio Setting'. 86271AJ67A and 86271AJ77A Condition: Android device is connected via Bluetooth and iPhone (iOS) is connected via USB Select the appropriate setting from the two connections avail- The problem was...
Page 53
AHA RADIO - Caution Message (17) Caution Message: To use this function, you must agree to the Note: Aha Radio is not available for terms and condition on the 'caution' screen. 86271AJ67A and 86271AJ77A Symptom: Map is not shown when pressing button Press “MAP”...
Page 54
2. Troubleshooting AHA RADIO - Caution Message (18) Caution Message: 'Aha Radio Setting' change failed. Note: Aha Radio is not available for Please try again later. 86271AJ67A and 86271AJ77A Symptom: Aha Radio Setting on vehicle Navigation Head Unit cannot be changed Wait for about 10 minutes and The problem was try again.
Page 55
AHA RADIO - Caution Message (19) Caution Message: External device has been connected. Note: Aha Radio is not available for Voice recognition mode off. 86271AJ67A and 86271AJ77A Symptom: Voice Recognition Mode has turned OFF by itself Wait for about 10 minutes and The problem was try again.
Page 56
2. Troubleshooting AHA RADIO - Caution Message (20) Caution Message: Connection with Aha app is not completed. Note: Aha Radio is not available for Please try again later. 86271AJ67A and 86271AJ77A Symptom: Voice Recognition Mode does not work for Aha Radio Wait for about 10 minutes and The problem was try again.
3. FAQ Navigation How can I eject the SD card ? What if I eject the MAP SD card while using the Navigation system? You can corrupt the MAP data file and navigation system may stop working. Please do not eject the MAP SD card while navigating. How do I know if my Navigation unit is receiving GPS signals? 1.
Page 59
How can I adjust the contrast and brightness of the screen? 1. Press 2. After completing the adjustment, touch How can I change the language for Display and Voice Recognition? 1. Press 4. Select a language 2. Touch “Info” 3. Touch “Language” My navigation voice guidance volume is too low.
Page 60
3. FAQ Navigation Can I review my entire driving route in simulation? Yes. 1. Set your destination 5. Scroll down the list and touch “Simulate 2. Touch “Menu” on MAP screen Navigation” 3. Touch “My Route” 4. Touch “More” I live in the high elevation area, does the unit provide altitude information? Yes.
Page 61
What types of MAP views are available? Three types of MAP views are available (2D North Up, 2D Heading Up, and 3D) How to change the MAP view. 1. Touch “Menu” on MAP screen 2. Touch “More…” 3. Touch “Settings” 4.
Page 62
3. FAQ Navigation I want to use the Navigation system to go back to home. How can I do? Please make sure your home has been added to the “Favorites.” If not, refer to Question 11. If your home is set to the “Favorites”, follow the procedure below. 1.
Page 63
What is the “Route Planning Methods”? “Route Planning Methods” provide you options to search the route to the destina- tions. What “Route Planning Methods” are available? 4 Route Planning Methods are available (Fast, Green, Short and Easy).
Page 64
3. FAQ Navigation How can I choose a “Route Planning Method” (Fast, Green, Short and Easy)? 1. Touch “Menu” on MAP screen 2. Touch “More” 3. Touch “Settings” 4. Touch “Route Settings” 5. Touch “Route Planning Method” 6. Select one from “Fast” “Green” “Short” and “Easy” How can I find my current location/position? 1.
Page 65
How can I locate emergency services (Hospital, Police etc) near me? 1. Touch on MAP screen 3. Touch “Help Nearby” 2. Touch “Where Am I?” 4. Select one of categories What kind of navigation methods are available to the destination? Address, Places (POI), Map, Favorites and History...
Page 66
3. FAQ Navigation How can I change “Route Planning Method” while entering the destination? 1. Touch “More” before touching “Go!” 3. Select one from “Route Alternatives” 2. Touch “Route Alternatives” “Route Alternatives” How can I change my destination while driving? While driving, the destination can be changed by using the Voice control function 1.
Page 67
How can I find a “POI” by category? Destination Select one of Categories.
Page 68
3. FAQ Navigation How many “POI” categories are available? 18 categories are available (Accommodation, Airport, Automotive, Business, Café or Bar, Community, Favorites, Finance, Gas Station, Leisure, Marine, Medical, Parking, Restaurant, Shopping, Sports, Transport and Truck) How can I cancel my destination? 1.
Page 69
How can I rename a “Favorite”? 1. Touch on MAP screen 3. Select one you want to change the name 4. Touch 2. Touch “Favorites” 5. Touch “More” 6. Touch “Rename Favorite” Can I set a destination by using Voice Command while driving? How can I access previously used destinations? 1.
Page 70
3. FAQ Navigation What maps are stored in the MAP SD Card? US (50 states, District of Columbia & Puerto Rico), Canada (13 Provinces) Does the route guidance consider traffic conditions? Yes. Real time traffic information is provided by XM Traffic with XM subscription. How do I change the language for Voice Guidance? 1.
Page 71
How can we get detailed GPS information? GPS Info can be set on Quick Menu. Frequently used buttons and functions used during navigation can be selected and displayed on Quick Menu. Set GPS Info on Quick Menu: 1. Touch “Menu” 3.
3. FAQ Bluetooth Hands-free Which Bluetooth phones are compatible with the Navigation unit? A phone compatibility list is available at Subaru Website http://www.subaru.com/engineering/multimedia-electronics.html What should I do first to use the Bluetooth hands-free function with the Navigation unit? How can I register my phone to the Navigation unit? 1.
Page 73
How many cell phones can be registered to the Navigation unit? Up to 5 phones When multiple phones are registered to the Navigation unit, which phone will be connected first when the Navigation unit turns ON ? The order of connection precedence is 1 to 5. The system tries to connect to the first registered phone.
Page 74
3. FAQ Bluetooth Hands-free How can I find out the signal strength level of my Bluetooth phone with the unit? How can I open the hands-free call screen?
Page 75
When multiple phones are registered to the Navigation unit, how do I know which phone has been connected when the Navigation unit turns ON? How can I select my phone if another phone has been connected when the Naviga- tion unit turns ON?
Page 76
3. FAQ Bluetooth Hands-free What methods are available to make a call? You can make a call By entering a phone number • From call history (Outgoing Calls & Incoming Calls) • From Phonebook • From Speed Dial • How many “Outgoing and Incoming Call Histories” are stored to Navigation unit? How can I transfer my phone book to the Navigation unit? After the registration is completed, “Do you want to transfer the phone book from your mobile?”...
Page 77
How many phone contacts can be transferred to the Navigation unit? Up to 1000 persons can be transferred for each registered phone. During phonebook transfer what happens if more than 5 numbers are registered to one person in the phone book of the cell phone? The top 4 numbers will be transferred to the unit in the order of “Mobile”, “Home”, “Work”, and “Other.”...
Page 78
3. FAQ Bluetooth Hands-free How can I delete all phone contacts from the Navigation unit? Touch “Delete All” How can I delete a single phone contact from the Navigation unit? Select a person name to delete Touch “Delete”...
Page 79
What methods are available to place a call while driving? You can make a call From call history (Outgoing calls, Incoming calls) • From Speed Dial • Voice control • How can I receive a call? How can I adjust the volume level of the outgoing calls? During a call, Talking screen is displayed...
Page 80
3. FAQ Bluetooth Hands-free How can I transfer a call from Hands-free to my cell phone? Can I switch a call between private and hands-free mode while driving ? Is a “call waiting” function available? Yes.
Page 81
Will the Hands-free call be automatically transferred to the cell phone when the vehi- cle is turned off? Can a phone call be transferred to the hands-free call when the vehicle is turned on? How can I set my Navigation unit to answer a hands-free call automatically?
Page 82
3. FAQ Bluetooth Hands-free How can I adjust the Ring Tone volume ? Touch “Volume Settings” How can I adjust the Ring Tone volume while receiving a call? The Ring Tone volume can be adjusted with Steering Wheel Switches (+) / (-). What Bluetooth profiles are required in my phone for Phone book transfer? PBAP (Phone Book Access Profile) or OPP (Object Push Profile).
Page 83
How can I register “Speed Dial” numbers? How many “Speed Dial” numbers can be registered? Up to 10 How can I change the passcode (passkey)?
Page 84
3. FAQ Bluetooth Hands-free What Bluetooth profiles are required to use the Message function? HFP (Hands-free Profile) Ver.1.0 or later (Conformed Ver.1.5) • MAP (Message Access Profile) • What types of messages can be received on the Navigation unit? SMS (Short Message Service) •...
Page 85
How can I check my messages? Can I open attached file on the message? No. When a file is attached with the message, the icon is displayed, but the contents of the attached files cannot be opened. Attachment may be viewed on your cell phone.
Page 86
3. FAQ Bluetooth Hands-free How can I reply to a message? How many default “Reply Messages” are available? 18 default “Reply Messages” are available Can I reply to the message using one of default “Reply Messages” while driving? Yes, but you need to reply before closing the message. Once it’s closed, all messages cannot be accessed while driving...
Page 87
How can I edit or change the “Reply Messages”? You can enter up to 160 single-byte characters in a replay message How can I create my own reply message (free message)? You can enter up to 160 single-byte characters in a replay message How can I have my Navigation unit read the body of the message? 1.
Page 88
3. FAQ Bluetooth Hands-free How can I adjust the volume level of message read by the Navigation unit? Adjust “Message Readout Volume” Touch “Volume Settings” Can I set or configure the “Phone Settings” for each registered phone? Yes.
Page 89
How many “Ring Tones” types are available? 3 different Ring Tones are available Touch “Volume Settings” Can I reply to the received TEXT message by Speech (speech-to-text)? No. The unit does not have speech-to-text capability.
3. FAQ Audio / Visual How can I scroll through audio sources? How can I adjust the Sound Quality? Touch the sound band you want to adjust. Touch “Adjust” in EQ Settings.
Page 91
How can I save the Sound Quality Settings? How many “EQ Settings” presets are available? 6 (EQ1, EQ2, EQ3, EQ4, EQ5 and Flat) How can I reset or initialize all EQ Settings (EQ1, EQ2, EQ3, EQ4 and EQ5)? Touch “Flat” for more than 2 seconds.
Page 92
3. FAQ Audio / Visual How can I adjust the audio balance? Touch the balance point you want to use Touch “Adjust” on Sound Position...
Page 93
How can I set the volume level for each audio source? Touch...
Page 94
3. FAQ Audio / Visual What is HD Radio? HD Radio, which original stood for “Hybrid Digital”, is the trademark for iBiquity’s in- band on-channel (IBOC) digital radio technology used by AM and FM radio stations to transmit audio and data via digital signal in conjunction with their analog signals. Note: HD Radio service available in USA only (as of May 2013) Which radio station transmits radio program in HD mode? Check the information from the HD Radio website at http://www.hdradio.com/...
Page 95
How can I tell if the HD radio is broadcasting in “digital” mode? Once the digital signal is received, “Digital” is displayed How can I manually store radio stations as presets? How can I store radio stations automatically into the preset buttons?
Page 96
3. FAQ Audio / Visual How many AM/FM radio stations can be stored as presets? 6 stations each for FM1, 2 and 3 and 6 stations for AM (Total: 24 stations) How does “Tag” work ?
Page 98
3. FAQ Audio / Visual Can I receive SAT (XM) for free? No. SAT (XM) radio is a paid subscription. I cannot get some of the XM channels. Why? It may be an invalid channel or a non-subscribed channel. How can I select a SAT channel? There are 4 ways to select a SAT channel (Preset, Channel, Direct and Category) Preset Channel...
Page 99
How can I store SAT radio channels? How many SAT channels can be stored into the preset memory buttons? Save up 6 stations each for XM1, XM2 and XM3. (Total of 18 stations)
Page 100
3. FAQ Audio / Visual How can I find the XM radio ID number? What types of CDs are supported? I cannot see TEXT information while playing my CD. Why? The CD-TEXT function can be used only for commercially available CDs that support CD TEXT.
Page 101
Does the system play MP3/WMA files on CD-R/CD-RW? Yes. What is the recommended bit rate and sampling frequency of MP3/WMA files on CD- R/CD-RW? Bit rate: 128kbps • Sampling frequency: 44.1KHz • How do I know if my USB memory is connected to the USB port correctly? Once the USB memory is connected to the USB port and recognized by the system, the USB icon will be highlighted.
Page 102
3. FAQ Audio / Visual How can I listen to the music stored in the USB flash memory? Select a Folder Touch a music file to play Can I watch video stored in the USB memory while driving? No. In order to watch video contents, the vehicle must be stopped and the park- ing brake applied.
Page 103
How can I watch a USB video contents ? Note: You can watch a USB video only if you have stopped your vehicle and applied the park- ing brake to ensure safety and turned the ignition switch to ON or ACC ON. How to view video in full screen size? Touch the area where the video is shown to view in full screen mode.
Page 104
3. FAQ Audio / Visual How can I change the subtitle language of the USB video playback? How can I change the audio language of the USB video playback?
Page 105
How can I change the aspect ratio of the USB video playback? How can I display the DIVX VOD (Video On Demand) registration code?
Page 106
3. FAQ Audio / Visual What video formats are supported for USB video playback? DivX, Div, AVI, WMV, MP4, M4V What is the maximum resolution and frame rate of the video files for USB video play- back? 720x480 (30 frame/second), 720x576 (25 frame rate / second) If the video resolution and frame rate do not meet the specification, “Video resolu- tion not supported”...
Page 107
How can I play music (audio) from iPod? How do I know if the connected iPod is recognized by the Navigation unit? Once your iPod is connected to the USB port and recognized by the Navigation unit, iPod icon will be highlighted.
Page 108
3. FAQ Audio / Visual How can I find a music files by Albums, Songs and Artists for iPod player? How can I repeat a song in the iPod?
Page 110
3. FAQ Audio / Visual How can I play songs in “Shuffle Songs” mode with iPod? How can I change the audiobook playback speed?
Page 111
Which iPods are supported by the Navigation unit? Can pictures or photography from the iPod be displayed on the Navigation unit? No. Pictures stored on the iPod cannot be shown on the display Are Podcasts supported in iPod mode? Yes, but it may operate differently Can I charge my iPod with the Navigation unit?
Page 112
3. FAQ Audio / Visual What profiles are required to listen to Bluetooth Audio? A2DP (Advanced Audio Distribution Profile) Ver. 1.0 or higher • AVRCP (Audio/Visual Remote Control Profile) Ver.1.0 or higher (Ver. 1.4 or higher • is recommended) How many Bluetooth Audio devices can be registered to the Navigation unit? Up to 5 devices How can I register my Bluetooth portable device to the Navigation unit?
Page 113
How can I connect my Bluetooth Audio device to the Navigation unit?
Page 114
3. FAQ Audio / Visual How can I play Bluetooth Audio? Before playing Bluetooth Audio, please make sure your Bluetooth device has been registered and connected. Why iTunes downloaded music won’t play in USB audio player? USB audio player only supports MP3 and WMA music files and won’t support AAC file from iTunes store.
3. FAQ Others How can I play a picture Slide Show? Caution: Do not add photo data on Map SD Card. It may damage the software file. Always use a different SD card to store photo data. Remove/Attach SD Card Cover: How can I replace the Subaru Opening Screen with my own picture?
Page 117
Do I lose the Subaru Opening screen once it is replaced with my own picture? You can select either the Subaru logo (default) or your picture as the Opening Screen. 1. Press “Audio” 2. Touch “Info” 3. Touch “Settings” In start up Screen, you can select “Customized (your picture)” or “Initialize (Subaru logo)”...
Page 118
3. FAQ Others How can I set or adjust the clock? Current time can be adjusted automatically using GPS signals or manually. How can I turn off the “Guide Tone (Beep)”?
Page 119
What “Personal Data” will be deleted by touching “Delete Personal Data” button? You can delete the data items that you How to delete personal data registered and return them to the factory default value.
Page 120
3. FAQ Others What items will be initialized by touching the “Initialize” button? Settings of Skin Pattern, Start Up Screen, Clock, Time Display, Time Zone, Link to Day/ Night View, Voice Recognition and Guide Tone will be reset to the factory default How can I adjust the volume level of Voice Guidance?
Page 121
How can I check the Software (Navigation & Audio) version? 1. Press “Audio” 2. Touch “Info” 3. Touch “Software version” How can I check the system conditions (GPS, Parking Brake, Reverse signals)? 1. Press “Audio” 2. Touch “Info” 3. Touch “System Check” Can I make a back-up copy of the MAP SD card and restore the content to another SD card? No.
4. Glossary [A] - [M] [ Alphabetical Order ] Term Definition Aha is a comprehensive “automotive grade” cloud platform, providing automotive manufacturers a single integration point to bring the widest range of current and future Web infotainment content safely into their vehicles.
4. Glossary [N] - [S] Term Definition Navigation System Navigation system is capable of containing map data, determining a vehicle's location and providing suggested direction. Navteq is a Chicago, Illinois-based provider of Geographic Information NAVTEQ Systems data and is a dominant company in providing the base elec- tronic navigable maps.
Page 124
4. Glossary [U] - [number] Term Definition USB is a specification to establish communication between devices and a host controller. USB flash drive consists of a flash memory stor- (Universal age device integrated with a USB 1.1 or 2.0 interface. Serial Bus) WMA (Windows WMA is an audio data compression technology developed by Micro-...
