Summary of Contents for S&P THGT-HATCH

  • Page 1 THGT-HATCH...

  • Page 3: Table Of Contents

    INDEX 1. GENERAL ..................................4 1.1. Warnings ................................... 4 1.2. Safety instructions ..............................4 1.3. Transport, lifting ............................... 5 1.4. Storage ..................................6 2. PRODUCT DESCRIPTION ..............................6 2.1. Technical specifi cations ............................6 2.2. Dimensions ................................7 3. INSTALLATION................................. 7 3.1.

  • Page 4: General

    1. GENERAL 1.1. WARNINGS This manual provides information and instructions for the correct lifting, installation, operation and maintenance of this fan series. The manufacturer; Soler & Palau Sistemas de Ventilación S.L.U. accepts no responsibility for costs, breakages, acci- dents or any inconvenience caused by failure to comply with the instructions contained in this manual, general codes of practice or due to improper use.

  • Page 5: Transport, Lifting

    HATCH will not open in order to prevent rain ingress or damage to the opening mechanism due to strong wind. However, these sensors shall not have any priority whatsover in case of fi re emergency. Under such event, the THGT-HATCH shall operate regardless of the weather conditions. Safe installation •...

  • Page 6: Storage

    2.1. TECHNICAL SPECIFICATIONS Combining a motorized hatched enclosure and a mechanical extract fan, the THGT-HATCH is a roof-mounted unit de- signed for vertical smoke extract in fi re conditions. F400-120 certifi cation for dual purpose as per EN 12101-3 (0370- CPR-3963).

  • Page 7: Dimensions

    THGT-HATCH is a roof unit. It may be installed onto a specifi c base or frame for this unit, or directly on the roof on (re- quires JBS-HATCH mounting accessory).

  • Page 8: Electrical Connection

    3.3. ELECTRICAL CONNECTION The electrical connection of this unit is divided in two parts: actuators for the HATCH, and the motor of the FAN. For both parts the diagrams provided inside their respective terminal boxes shall be followed. Consider a recommended time to fan start of 30s after the cover has started to open. HATCH The HATCH cover is operated by two 220-240V IP65 actuators, which may indicate the fully open / fully closed position.

  • Page 9: Commissioning

    • After two hours of operation, check that all fi xings and supports/bases are tight and adjust if necessary. • Set up the activation sequence of the THGT-HATCH unit so that the fan starts 30 seconds after the cover starts to open.

  • Page 10: Putting Out Of Service And Recycling

    The basic principle of condition monitoring is to monitor a suitable measurement, so that any upward trend can be de- tected and taken as an indication that a problem exists. Thus it is important to: A. Identify initial installed vibration level. B.
  • Page 12 S&P SISTEMAS DE VENTILACIÓN, S.L.U. C. Llevant, 4 Polígono Industrial Llevant 08150 Parets del Vallès Barcelona - España Tel. +34 93 571 93 00 Fax +34 93 571 93 01 www.solerpalau.com Ref. 9023087100...
