CARBON MONOXIDE DETECTOR, i4H-CO-M330
Air Vents
INTRODUCTION
The i4H-CO-M330 electrochemical Carbon Monoxide Detector is effective for
detecting any buildup of carbon monoxide, also known as CO gas, in your home or office.
The features of i4H-CO-M330 detector includes:
1 Easy to install.
2 Monitoring for carbon monoxide in a continuous manner.
3
Giving a loud alarm (85 dB) when it detects a buildup of carbon monoxide. Inform
users and CMS through i4H-LS-20 alarm panel.
4 Available Test Button for you to test the detector anytime.
5 Self-testing its operative function continuously.
6 Complying the requirements of UL Standard 2034, EN50291.
LOCATIONS TO INSTALL YOUR DETECTOR
Since CO gas moves freely in the air, the suggested location is in or as near as possible to
sleeping areas of the home. The human body is most vulnerable to the effects of CO gas
during sleeping hours. For maximum protection, a CO detector should be located outside
primary sleeping areas or on each level of your home. In the figure below, are suggested
locations in the home. The electronic sensor detects carbon monoxide, measures the
concentration and sounds a loud alarm before a potentially harmful level is reached.
Alarm LED
Press the latch and push
the cover downward to
open the battery
compartment
Power LED
Fault LED
Test/Mute
Button
Advertisement
Table of Contents
Related Manuals for i4Home i4H-CO-M330
Summary of Contents for i4Home i4H-CO-M330
- Page 1 INTRODUCTION The i4H-CO-M330 electrochemical Carbon Monoxide Detector is effective for detecting any buildup of carbon monoxide, also known as CO gas, in your home or office. The features of i4H-CO-M330 detector includes: 1 Easy to install.
- Page 2 If applicable, the unit will chirp for approximately one second and all the LED will flash for one second. Gently close the front cover. Note that the front cover of the i4H-CO-M330 unit can’t be closed if all three AA batteries are not properly installed.
- Page 3 2) There is back tamper switch inside the main body of the i4H-CO-M330, if the detector is removed from the mounting bracket, the buzzer would beep for warning.
- Page 4 ACTIONS TO TAKE WHEN ALARM SOUNDING In case of harmful levels of CO gas being detected, The i4H-CO-M330 detector will go into a continuous full alarm. Try to take the following necessary actions immediately:...
- Page 5 Although many products of combustion can cause discomfort and adverse health effects, it is CO gas which presents the greatest threat to life. Carbon monoxide is produced by the incomplete combustion of fuels such as natural gas, propane, heating oil, kerosene, coal, charcoal, gasoline, or wood. The incomplete combustion of fuel can occur in any device which depends on burning for energy or heat such as furnaces, boilers, room heaters, hot water heaters, stoves, grills, and in any gasoline powered vehicle or engine (e.g.
- Page 6 Test your detector at least every week (see the section "TESTING YOUR DETECTOR"). Important notice: The i4H-CO-M330 uses an electrochemical sensor whose life is about 5 years, the user should replace a new i4H-CO-M330 before its life time expires. WARRANTY INFORMATION Limited Warranty: i4Home Co., Ltd. warrants its i4H-CO-M330 Carbon Monoxide Detector to be free from defects in material and workmanship under normal use and service for a period of one (1) year from date of purchase.
