Wireless keypad - KPD-ABC-SQ-0-K (DIGYPAD)
A.
General description
1) Allows keyless entry / exit, by punching a secured combination code of numbers.
2) Up to 3 different codes A, B, C, codes can be from 1 to 8 numbers.
3) Suitable for opening KINGgates equipment, and other brands with a KINGgates receiver.
4) To be installed up to 30 meters range from the equipment (gate, Garage door, etc.).
5) No wiring required. The unit is wireless, and battery powered.
6) For flat vertical surface installation as wall, posts etc.
7) Weatherproof for outdoor, and indoor installations - IP54
8) Battery to last about 24 months with about 10 operations per day.
9) Battery is easy to replace by the user (required some technical skills)
10) Back light - the pads light up with the first press of a button
11) This unit needs to be paired to the gate
B. How to use the unit
1) Key-in your security code followed by the Letters A, or B, or C.
2) 6 seconds allowed between each press of a button.
3) Beep confirmation will be heard - see the table below.
BEEP
SIGNALS
1 short beep
1 long beep
3 long beeps
5 short beeps
MEANING
Confirms a key
press.
More than 6
seconds try again form the
•
For code programing - Code have been successfully changed
•
With regular use - Battery low -replace the battery, you will hear the beeps with the
new battery stalled correctly
• something went wrong, re try again
Series
of beeps
over
2
sec.
and must
be
replaced
KINGGATES
KING GATES
SRL
-
Via A. MALIGNANI,
TEL.
+39
(0)434
737082
-
FAX +39
(0)434
beginning.
indicates
that
the batteries are exhausted
42
-
33077
SACILE
(PN)
ITALY
786031-
P.IVA 016098760939
Advertisement
Table of Contents
Summary of Contents for Allegro KINGGATES KPD-ABC-SQ-0-K
- Page 1 KINGGATES KING GATES Via A. MALIGNANI, 33077 SACILE (PN) ITALY TEL. (0)434 737082 FAX +39 (0)434 786031- P.IVA 016098760939 Wireless keypad - KPD-ABC-SQ-0-K (DIGYPAD) General description 1) Allows keyless entry / exit, by punching a secured combination code of numbers. 2) Up to 3 different codes A, B, C, codes can be from 1 to 8 numbers.
- Page 2 Maintenance This unit does not require any special maintenance. Check it occasionally for spider webs, dust. wipe and clean wet cloth. Replace the battery if not working. Disposing of Battery Discharged battery contains pollutant substances and therefore should be recycle. Dispose battery at waste disposal, Battery world shop, or similar.
- Page 3 INSTALLATION AND PROGRAMING H. Pairing the keypad to the gate system /control unit / receiver Pairing is done at the gate control unit. you may need a technician for it. Paring should be done before installing the unit. Be ready to operate the unit with a code(s). The Keypad operates similar to a remote-control unit.
- Page 4 L. Installation of the unit 1) Before installation check reception form the desired installation location 2) Choose a flat surface for installation, chose the right high to be comfort for adult and or children users 3) Extract out the button plastic part form the metal case – Fig. 2 4) Punch holes in the metal case for the screws to fit it to the wall/ post 5) Fit the metal case of the unit to the wall / post with screws –...
