  • Page 1 Addlogix Wireless PC2TV InternetVue 2100 User’s Guide Version 3.01.10 or later...

  • Page 2: Table Of Contents

    Addlogix Wireless PC2TV InternetVue 2100 Table of Contents 1 INTRODUCTION RODUCT ESCRIPTION RODUCT PECIFICATION INIMUM YSTEM EQUIREMENTS 2 HARDWARE SETUP TTACHING NTERNET 3 SOFTWARE SETUP NSTALLING OFTWARE NINSTALLING THE OFTWARE 4 INTERNETVUE 2100 SOFTWARE APPLICATION SING THE ONFIGURATION SING THE...

  • Page 3: List Of Figures

    Addlogix Wireless PC2TV InternetVue 2100 List of Figures 1: H IGURE ARDWARE ESCRIPTION 2100 S IGURE NTERNET PLASH 3: C IGURE ONFIGURATION IZARD 4: C IGURE ONFIGURATION IZARD 5: C IGURE ONFIGURATION IZARD 6: C IGURE ONFIGURATION IZARD 7: C...

  • Page 4: Introduction

    The device has its own software (Wireless PC2TV InternetVue 2100 application) that allows you to control viewing options and configure predefined settings so that future connections are simple and easy.

  • Page 5: Minimum System Requirements

    Addlogix Wireless PC2TV InternetVue 2100 1.3 Minimum System Requirements Operating System • Microsoft Windows 2000 Professional (SP4) • Windows XP Home / Professional Edition SP2 • Windows Vista Computer System • Pentium 4 or M >1.5 GHz • 512 MB of RAM •...

  • Page 6: Hardware Setup

    2.1 Attaching InternetVue 2100 to a Television or Monitor Connect a DVI or VGA cable to the appropriate DVI or VGA port on the InternetVue 2100. Connect the other end of the cable to the appropriate DVI or VGA port on the television, projector or monitor.

  • Page 7: Software Setup

    Before you install the InternetVue 2100 software, remove any earlier version of the InternetVue 2100 software installed on the computer. See “Uninstalling Software” for removal instruction. Load the CD that came with the InternetVue 2100 into the computer CD/DVD drive. The Setup program should Auto-Start (or click on PC2TVSetup.exe to start the program) Select the License Agreement checkbox and click Next.

  • Page 8: Uninstalling The Software

    Addlogix Wireless PC2TV InternetVue 2100 3.2 Uninstalling the Software Click Start and navigate to All Programs > PC2TV Click Uninstall and the software removal process will begin. When the un-installation process is finished, reboot your PC. Version 0.2...

  • Page 9: Internetvue 2100 Software Application

    InternetVue 2100 Software Application 4.1 Using the Configuration Wizard After installing InternetVue 2100 software, on the first application start, the Configuration Wizard will appear to guide you through the initial setup. The Wizard can also be selected by clicking the Wizard button in the Advance View screen.
  • Page 10 Addlogix Wireless PC2TV InternetVue 2100 Version 0.2 Figure 4: Configuration Wizard Password Setup Screen The Password (optional) restricts access to Advance and Internet Settings. Password can be up to 32 characters in length. Figure 5: Configuration Wizard Device Settings Screen...
  • Page 11 Addlogix Wireless PC2TV InternetVue 2100 The Device Name (optional) allows you to use a name in place of the PC2TV’s default display ID. The Device Name can be up to 4 characters in length. Figure 6: Configuration Wizard Wireless Settings Screen...
  • Page 12 Addlogix Wireless PC2TV InternetVue 2100 Version 0.2 Figure 7: Configuration Wizard Configuration Summary Screen The Configuration Summary displays your current configuration settings...

  • Page 13: Using The Software

    Figure 8: InternetVue 2100 Application At start-up, the application automatically scans for Wireless PC2TV InternetVue 2100 devices. If one InternetVue 2100 is located, the SSID of that device will appear in the Wireless Display List. If multiple InternetVue 2100s are located, the Wireless Display List appears with the SSID of each device.

  • Page 14: Advanced

    To change your display mode, click the desired video mode button on the application. Stopping the Display To stop your computer from displaying on the connected television or computer monitor without disconnecting from the InternetVue 2100, click the Stop Display button on the on the application Disconnecting from InternetVue 2100 To disconnect your computer from the InternetVue 2100 and close the application: Click the Close button on the Wireless PC2TV application.

  • Page 15: Advanced Settings

    Accessing Application Help To access Application Help, click on the “?” (Application Help) button. Figure 10: Application Help Screen 4.3 Advanced Settings To access the Advanced settings, click the Advanced View button on PC2TV InternetVue 2100 Application. Figure 11: InternetVue 2100 Application...
  • Page 16 Addlogix Wireless PC2TV InternetVue 2100 Version 0.2 The PC2TV InternetVue 2100 application expands to its full view, as shown below: Figure 12: InternetVue 2100 Application General Resolution, Desktop Display, Device Settings, and Configuration Summary. Display Connection Wireless Channel Number. Internet Connection TCP/IP, and Wireless Settings (External Network Connection Wired or Wireless).
  • Page 17 Addlogix Wireless PC2TV InternetVue 2100 Video Settings Figure 13: General – Video Settings Screen Resolution sets the quality of the image sent from your PC to your TV or Monitor. Increasing the Resolution, increases the amount of data sent over your wireless connection, and may exceed the capability of your wireless network.
  • Page 18 Addlogix Wireless PC2TV InternetVue 2100 location of the Extended Mode virtual display area (for example, to the right or left of the normal viewing area of your PC display). To send DVD video to your TV or Monitor, start playing the DVD in your media player, and drag the media player into the Extended Mode virtual display area.
  • Page 19 Addlogix Wireless PC2TV InternetVue 2100 Wireless Channel Number Figure 15: Display Connection – Wireless Channel Number Screen Channel selects one of the wireless channels to use for the connection from your PC to the PC2TV device. You may need to change the wireless channel number to improve video quality, if too many wireless access points in your area are using the same channel number.
  • Page 20 Addlogix Wireless PC2TV InternetVue 2100 Wireless Settings Figure 17: Internet Connection – Wireless Settings Screen The Wireless Network settings allow you to select one of the three possible connection configurations for your PC2TV device. The “Do not allow external network connections” setting means there is no connection from the PC2TV device (either wireless or Ethernet cable) to the Internet.
  • Page 21 Upgrade Figure 19: Advanced – Upgrade Firmware Screen The “Upgrade Now!” button causes the PC2TV InternetVue 2100 application software to search for firmware updates from the Internet (if “Upgrade from the Internet” is selected) or from your PC (if “Upgrade from this computer” is selected).

  • Page 22: Troubleshooting

    802.11g or 802.11b specification. Installation Questions and Issues Do I have to reboot after installing the Wireless PC2TV InternetVue 2100 application? After the application is installed, the application checks if the driver installation requires a reboot or not.
  • Page 23 Wireless PC2TV InternetVue 2100 does not appear in the available AP list). If the Wireless PC2TV InternetVue 2100 still does not appear in the available list, a fresh start is recommended by using the following steps: Exit the Wireless PC2TV InternetVue 2100 application (if launched).
  • Page 24 Addlogix Wireless PC2TV InternetVue 2100 An Ethernet network cable is connected either to the Wireless PC2TV InternetVue 2100 or your computer. The Wireless PC2TV InternetVue 2100 application is launched. If you are projecting: Check the bullet items listed above. Stop projecting from within the application, and then project again.

  • Page 25: Faq

    If more than one user wants to project to the same display, a window on their computer screen informs them that the Wireless PC2TV InternetVue 2100 is in use (wait mode). Click the Display button after the first user has stopped displaying.
  • Page 26 2100, or a wireless access point (if one already exists while being projected onto the display). If the Internet is accessed via the Wireless PC2TV InternetVue 2100, it is advised that the Ethernet cable be connected to the Wireless PC2TV InternetVue 2100 before it is powered Note the following special cases: The Ethernet port on the board can have DHCP enabled or STATIC addresses.
  • Page 27 This only applies if the feature is enabled at the time of Wireless PC2TV InternetVue 2100 launch After the Wireless PC2TV InternetVue 2100 application closed, my laptop wireless utility...
  • Page 28 Addlogix Wireless PC2TV InternetVue 2100 If I have set but forgot my password setting how do I reset it? Factory default can be restored by press and hold the “Factory Reset Switch” for the VGA/DVI units or the “Component/Composite Video Switch” for the component/composite units, for five seconds.
