DL4B (W)
MINI RC LED LIGHTING
Version HW: 1.1 / SW: 1.1
USER GUIDE
PERFORMANCE AND QUALITY
2020
rev. 01
MODEL ELECTRONICS
Operating Instructions
Information, Support, Service
RC Switches DS1C
RC LED Lighting Controller DL4B
DC ESCs CLEVER
RC Opto-isolator DOP1C
Programmer DPG4
RC LED Lighting Controller DL16B
RC Switches / ESCs - DS4C
1
Advertisement
Table of Contents
Summary of Contents for DSYS DL4B
- Page 1 Operation Technical Specifications Operating Instructions Package content Information, Support, Service ORDER RC Switches DS1C RC LED Lighting Controller DL4B DC ESCs CLEVER RC Opto-isolator DOP1C Programmer DPG4 RC LED Lighting Controller DL16B RC Switches / ESCs - DS4C USER GUIDE...
- Page 2 RC Models Universal RC LED Lighting DL4B DL4BW Car / Boat / Plane / BUS, TIR, Tractor, Tank, Dinghy, Sub, Glider. W - resistant to splashing water, snow, humidity and dust. WIRING Plug the control cable to the receiver (channel ESC, servo or free). Plug the servo cable in to connector K2, which is connected to the control cable.
- Page 3 RAMP 4 and 5 LED: 7,4 - 0,6 - (2 x 3,2) = 0,4 (OK) OPERATION Insert jumper F1 through F6 into connector K3 to set the DL4B function. Connect the control cable to the switched on receiver. When the power is connected, LED L2 indicates the selected function by the number of flashes (The K3 status is read only when it is switched on).
- Page 4 20 minutes. Do not look directly into LED light from small distance. Protect your eyes. Wrong wiring could cause the DL4B damage even its ignition. Check the wiring before every use. Prevent short-circuit of any wires by proper insulation.
- Page 5 PACKAGE CONTENT DL4B (W) with user guide ........1 pc Super LED 5mm, 20mA ........8 pc (4x white 3,2V / 2x red 2,1V / 2x blue 3,2V) Connector K1 ............1 pc Jumper F1-F6 ............6 pc Resistor 120R / 0,25W ......
- Page 6 DS1C (W) 3A (5A / 3s) 25 x 14 x 4 mm DL4B - Universal RC LED Lighting Controller 1 channels control (Stick, Wheel, Switch). Setting with 1 jumpers. Very simple operation and adjustment. Content: 8x super LED 5 mm, Jumper F1-6, connector, cable.
- Page 7 Universal DC ESC Brushed - Reversible / Unidirectional Car, Boat, Plane, BUS, TIR, Tractor, Tank, Dinghy, Sub, Glider. 2 user quick settings by jumper or switch (M1, M2 memories). 2 LEDs status indication (red and green LEDs). Battery: DDE20A, 70A: 5 - 10 Ni-Cd / Ni-MH, 2 - 3S Li-Pol / Li-ion / A123 Li-Fe, Pb 6V / 12V.
- Page 8 DL16B - 3CH Universal RC LED Lighting Controller 2 - 3 channels control (Stick, Wheel, Switch). Setting with 3 jumpers. Very simple operation and adjustment. Content: 13x super LED 5 mm, 6x super LED 3 mm, 3x jumper, Piezo Buzzer, connectors, cables, switch, heat shrink tubes. CAR, track, tank: Right/Left Blinkers, headlights, rear and reversing lights roof lights and beacons, hazard warning lights, lights bar.
