Summary of Contents for Trivinci Systems Road-Keeper
- Page 1 Road-Keeper HD Video Data Logger User Guide Version：1.4 June 2019...
- Page 2 Overview Congratulations on your purchase of the Road-Keeper Dual HD video data logger from Trivinci Systems LLC. This is a digital full HD video camera recorder for your vehicle with advanced GPS and accelerometer technology that captures two streams of 1080p video, positional and inertial data.
- Page 3 Road-Keeper User Guide Check with Trivinci Systems LLC for updated features and functions. A copy of this user Guide and the Race-Keeper Comparo Installation file can be found on the microSD card that came with you Road-Keeper video data logger.
-
Page 4: Power Button
Road-Keeper User Guide Key functions and controls Power button • Press Power button once to turn Road-Keeper on and press for 3 Seconds to power off. Short press to turn screen off/on. Menu/Mode button ◣In the standby mode, long-press the Menu button to switch between video / photo / playback mode. - Page 5 Screen View button Press Screen view button to switch the display between • both, front only and rear only camera view. Use this when aiming the two cameras For WIFI version on Road-Keeper, long press the Screen • info@race-keeper.com www.Race-Keeper.com...
- Page 6 ◣When the Road-Keeper is recording video，press the OK/Lock button to lock the video, a key icon will appear on the screen. This will Save this video and prevent the Road-Keeper overwriting this video when space is needed. Use the Lock button if there is an incident around your vehicle that you want to Save.
- Page 7 / off the Microphone. Use this function to prevent recording of private conversations or phone calls ◣In the menu interface, press Down to move down. Reset If the Road-Keeper logger stops responding, press the Reset • button to restart the unit. MicroSD Card Slot The Road-Keeper logger supports high speed microSD •...
- Page 8 USB Port • Use the car charger power cable to supply 5v DC power for your Road-Keeper logger. The Cig plug on the cable contains the power regulator to convert and regulate your vehicle power from 12v to 5v. Front Camera The front camera records the view in front of your vehicle.
-
Page 9: Installation
• after cleaning the glass with an alcohol wipe, use the 3M adhesive pad to fix the Road-Keeper on the front windshield. Choose a position on the windshield where the front facing camera is looking through clean glass (cleaned by the windshield wiper), and where the interior facing camera is not obscured by the rear view mirror. - Page 10 Turn on the vehicle ignition (so power on the cigarette • lighter socket comes on) and check that the Road-Keeper powers up. You will see the Road-Keeper logo on-screen for short time during power up and power down. Adjust the front and rear camera lenses to ensure a good viewing angle.
-
Page 11: Operation
When the vehicle engine is stopped and the ignition turned off, the Road-Keeper with stop the recording and power down. Manually On/Off: Press the power button once to power the Road-Keeper on, and press it again for 3 seconds to power off. info@race-keeper.com... - Page 12 The red record icon (red circle, top left on the screen) blinks. Manual Recording With the Road-Keeper powered up and in standby ready to record, press the REC key to start a recording. The red record icon (red circle, top left on the screen) will blink showing a recording is in progress.
- Page 13 Road-Keeper User Guide Press Menu/Mode key to enter photo setup option. ZOOM in/out (Photos and Videos) In Photo mode, press the Record/ Up button to made the current camera Zoom in. Press the Mic/Down button to Zoom out. To change the Zoom level on the second camera, use the right button (Screen View Switch) to change the camera shown in the Main view.
- Page 14 2. Protect: Select to either lock or unlock the file. 3. Slide Show: Select 2, 5, or 8 seconds to browse the files. Remarks: If the Road-Keeper stops responding while in use, press the RESET button on the unit's side to restart it.
- Page 15 Functions and Use of Road-Keeper Loop Recording • ·What is loop recording? The recorded video duration can be selected in the Road-Keeper menu: Off,1Minute,3Minutes,5Minutes,10Minutes,20Minutes Loop recording is the process of recording video continuously to an endless memory card. At the end of the memory card, the latest video clip will replace the earliest video clip.
- Page 16 Road-Keeper User Guide time:‘1Minute,3Minutes,5Minutes,10Minutes,20Minutes’ by using the UP/DOWN buttons. If you select ‘Off’ then the loop recording function will be off and the Road-Keeper will record continuously. info@race-keeper.com www.Race-Keeper.com...
- Page 17 Road-Keeper User Guide G-Sensor automatic Function • ·What is G-Sensor function? During loop recording, once the G-sensor detects a high G moment caused by a collision or other impact, the device will lock current video to avoid it being deleted automatically in the loop recording function ·How to use it?
- Page 18 Motion detection is the process of detecting movement in the front camera view. When the Road-Keeper is in Standby, when it detects movement in the front camera, it will start to record until the front image is still for ten seconds.
- Page 19 Road-Keeper User Guide • ·What is GPS? GPS is the global positioning system the Road-Keeper logger uses to sense its location and speed. ·How to use it? In standby mode, enter the Menu, find the GPS option and select KM/H or MPH. If you select ‘Off’, GPS will not work.
- Page 20 Therefore, you can wirelessly control the Road-Keeper using an app on your smart phone, and you can also preview or download video or pictures from the Road-Keeper.
-
Page 21: Specification
Road-Keeper User Guide Specification LCD Display 2.0” TFT LCD Camera FOV 170° High Resolution Wide Angle Language English, French, Spanish, Portuguese, Italian Video Resolution FHD 1080P@30fps+ FHD 1080P@30fps; HD 720P@30fps+ HD 720P@30fps Video Format H.264 compress format Mic/Speaker Built-in Off, 1,3,5,10,20 minutes Loop Recording Yes. - Page 22 Road-Keeper User Guide Back-up Power Super capacitor Accessories In-car charging cable. Mount (Bracket). User Manual. info@race-keeper.com www.Race-Keeper.com...
- Page 23 A: Please try to reset with the reset button, and format your SD card. Q: The screen flickers when filming in fluorescent lighting. A: Set the Road-Keeper to 50 or 60Hz in the System menu Q: Camera image is blurry. A: Please check if the protective film has been removed from each camera lens.
- Page 24 Road-Keeper User Guide formatted FAT32 by the Road-Keeper logger. For Questions about and Support for your Road-Keeper logger please email us at info@Race-Keeper.com and include details of your issue, along with your contact information. www.Race-Keeper.com Document Revisions Version Date Change...
- Page 25 Road-Keeper User Guide info@race-keeper.com www.Race-Keeper.com...
