MESH & SOLID SAFETY COVER
INSTALLATION GUIDE
Questions?
Phone us at 1-877-527-4881
FAX 1-781-297-2083
or email us at customercare@splashsupercenter.com
Congratulations on your purchase of a
Safety Cover from Splash Super Center.
Before you Start
Please fully read these instructions before and during the installation,
to ensure a smooth, quick & proper installation.
The Pool Site
Carefully examine the immediate pool area. The deck width around
the pool needs to be a minimum of 3 feet. The cover itself will over-
lap the pool from waters edge approximately 9"- 18" onto the deck
surface. The spring and strapping will extend another 17" from covers
edge.
Examine the deck surface. Are there any extrusions (obstacles) on the
deck surface that would prevent the cover from laying fl at? Rough cop-
ing ladder sockets, waterspouts, and other items that are not fl ush with
the deck. These surfaces should be padded with carpet, foam or other
similar material which will help to protect the cover from chafi ng.
Tools
You will need the following tools to complete installation.
• Rotary Hammer Drill
• 3/4" Concrete drill bit w/long shaft (diamond tip)
• Lubricant (silicone spray)
• Hammer
• Tape measure
• Chalk and chalk line
PLEASE READ ALL DIRECTIONS CAREFULLY BEFORE DRILLING ANY HOLES
ACURATE MEASURING WILL ENSURE A PROPERLY INSTALLED COVER
60 Campanelli Dr., Braintree, MA 02184 www.splashsupercenter.com
(toll free Monday-Friday 9am-5pm EST)
Included Safety Cover Hardware
Please examine the following list, and
make sure your safety cover includes
all the needed hardware.
Standard Hardware
Brass anchors
Stainless steel springs
Stainless steel buckles
Steel installation rods
Allen wrench
Spring covers
Tamper
Optional Hardware
Wood deck anchors
Anchor tubes
Short springs
Anchor fl anges
Lawn stakes
Automatic cover pump
Raised Wall Hardware
Eyebolts
Cable
Lag shields
1
Page
of 5
Advertisement
Summary of Contents for Splash MESH & SOLID SAFETY COVER
- Page 1 (toll free Monday-Friday 9am-5pm EST) FAX 1-781-297-2083 or email us at customercare@splashsupercenter.com Congratulations on your purchase of a Safety Cover from Splash Super Center. Included Safety Cover Hardware Before you Start Please fully read these instructions before and during the installation, Please examine the following list, and to ensure a smooth, quick &...
- Page 2 MESH AND SOLID SAFETY COVER INSTALLATION GUIDE Installing a Safety Cover STEP 1 Remove the safety cover from the box and carefully unfold. Be sure cover is right side up, and protective strips are on bottom. Center Drape cover over the pool, it is easier to leave the Strap water at normal height, as cover will fl...
- Page 3 MESH AND SOLID SAFETY COVER INSTALLATION GUIDE Installing a Safety Cover STEP 3 Deck Drill Tamp in Screw in Surface Hole Casing Anchor Using a hammer drill and a 3/4” drill bit, set the drill over the marked anchor holes. Keeping the drill perpendicular to the deck surface, drill down 1 7/8”...
- Page 4 MESH AND SOLID SAFETY COVER INSTALLATION GUIDE Installing a Safety Cover FREEFORM COVERS CUSTOM DECK SURFACES Freeform safety covers are installed the same as Brick, stone, pavers or lawn surfaces require standard rectangular covers, freeform covers have additional support for the anchors to maintain an 18”...
- Page 5 MESH AND SOLID SAFETY COVER INSTALLATION GUIDE Care and Maintenance Cover must always stretch taut across the pool. After the initial installation, some stretching may occur. Each spring should be compressed 50%, if needed readjust straps. Water level in pool can not go below 18” from top, as cover is designed to set down on water with the weight of snow and ice.
