Operator's Manual
Power Blower
The engine exhaust from this product contains chemicals known
to the State of California to cause cancer, birth defects, or other
reproductive harm.
Read and understand all provided literature before use.
Failure to do so could result in serious injury.
This product complies with CAN ICES-2/NMB-2.
X7501190602
© 10/2019 ECHO Inc.
PB-2620

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PB-2620 and is the answer not in the manual?

Questions and answers

Related Manuals for Echo PB-2620

Summary of Contents for Echo PB-2620

  • Page 1 State of California to cause cancer, birth defects, or other reproductive harm. Read and understand all provided literature before use. Failure to do so could result in serious injury. This product complies with CAN ICES-2/NMB-2. X7501190602 © 10/2019 ECHO Inc.

  • Page 2: Table Of Contents

    Table of Contents..................2 Introduction ....................3 Servicing Information .................. 4 Parts/Serial Number................4 Service ....................4 ECHO Consumer Product Support ............4 Product Registration ................4 Additional Literature ................4 Safety ......................5 Manual Safety Symbols and Important Information ......5 International Symbols ................

  • Page 3: Introduction

    Scan QR codes for more information. For additional literature, including safety manuals where applicable, or questions regarding terms used in this manual, visit: https://www.echo-usa.com/manuals https://www.shindaiwa-usa.com/manuals X7501190602 © 10/2017 ECHO Inc.

  • Page 4: Servicing Information

    Register your ECHO equipment on-line at www.echo-usa.com or by filling out the product registration sheet included in this manual. Registering your product confirms warranty coverage and provides a direct link to ECHO if we find it necessary to contact you.

  • Page 5: Safety

    Note: This enclosed message provides tips for use, care and maintenance of the unit. CIRCLE AND SLASH SYMBOL This symbol means the specific action shown is prohibited. Ignoring these prohibitions can result in serious or fatal injury. X7501190602 © 10/2017 ECHO Inc.

  • Page 6: International Symbols

    Hot Surface Mixture Idle speed Fast speed Finger severing Primer Bulb DO NOT Allow Ignition Flames or Sparks ON / OFF Near Fuel Choke Control DO NOT Smoke “COLD START” Near Fuel Position (Choke Closed) X7501190602 © 10/2017 ECHO Inc.

  • Page 7: Personal Condition And Safety Equipment

    Personal Condition and Safety Equipment Cancer and Reproductive Harm www.P65Warnings.ca.gov The muffler or catalytic muffler and surrounding cover may become extremely hot. Always keep clear of exhaust and muffler area, otherwise serious personal injury may occur. X7501190602 © 10/2017 ECHO Inc.
  • Page 8 Hearing/Ear Protection ECHO recommends wearing personal protection whenever unit is used. Breathing Protection Operators who are sensitive to dust or other common airborne allergens may need to wear a dust mask to prevent inhaling these materials while operating unit.
  • Page 9 To reduce the risk of serious or fatal injury, persons with pacemakers should consult with their physician and the pacemaker manufacturer before operating this machine. In the absence of such information, ECHO does not recommend the use of this machine by anyone who has a pacemaker.
  • Page 10 • Take periodic breaks to minimize repetition and rest your hands. • Reduce the speed and force with which you do the repetitive movement. • Do exercises to strengthen the hand and arm muscles. X7501190602 © 10/2017 ECHO Inc.
  • Page 11 Keep a Solid Stance • Maintain footing and balance at all times. Do not stand on slippery, uneven or unstable surfaces. Do not work in odd positions or on ladders. Do not over reach. X7501190602 © 10/2017 ECHO Inc.

  • Page 12: Equipment

    Equipment Use only approved attachments. Serious injury may result from the use of a non-approved attachment combination. ECHO, INC. will not be responsible for the failure of cutting devices, attachments or accessories which have not been tested and approved by ECHO. Read and comply with all safety instructions listed in this manual.

  • Page 13: Emission Control (Exhaust & Evaporative)

    The 50 or 300 hour emission compliance period is the time span selected by the manufacturer certifying the engine emissions output meets applicable emissions regulations, provided that approved maintenance procedures are followed as listed in the Maintenance Section of this manual. X7501190602 © 10/2017 ECHO Inc.

  • Page 14: Description

    Locate the safety decal(s) on your unit. Make sure the decal(s) is legible and that you understand and follow the instructions on it. If a decal cannot be read, a new one can be ordered from your ECHO dealer. Safety label is for example only. Your label my appear slightly different.

  • Page 15: Contents

    Due to packaging restrictions, some assembly may be necessary. After opening the carton, check for damage. Immediately notify your retailer or ECHO Dealer of damaged or missing parts. Use the contents list to check for missing parts. ____1 Power Head...

  • Page 16: Assembly

    (E) over upper pipe (F) until there is light resistance. Do not force the connection. Hold upper pipe, and turn lower pipe clockwise, engaging positive locking channels until connection is firm. X7501190602 © 10/2017 ECHO Inc.

  • Page 17: Remove Blower Pipes

    Wear gloves to protect hands from sharp edges and hot surfaces. X7501190602 © 10/2017 ECHO Inc.

  • Page 18: Fuel

    Fuel Diesel fuels and alternative fuels, such as E-15 (15% ethanol), E -85 (85% ethanol) or any fuels not meeting ECHO requirements are NOT approved for use in ECHO 2-stroke gasoline engines. Use of diesel or alternative fuels may cause...
  • Page 19 2-stroke and 2/4-stroke hybrid engines. Two Stroke Oil - A two-stroke engine oil, such as ECHO branded 2-stroke oils, meeting ISO-L-EGD (ISO/CD 13738) and J.A.S.O. FD Standards must be used. ECHO branded 2-stroke oils meet these standards. Engine problems due to inadequate lubrication caused by failure to use an ISO-L- EGD (ISO/CD 13738) and J.A.S.O.
  • Page 20 Add remaining gasoline, close fuel container, and remix. Spilled fuel is a leading cause of hydrocarbon emissions. Some locations may require the use of automatic fuel shut-off containers to reduce fuel spillage. X7501190602 © 10/2017 ECHO Inc.
  • Page 21 90 days when a fuel stabilizer is added. Stored two-stroke fuel may separate. ALWAYS shake fuel container thoroughly before each use. Used oil and gasoline, and soiled towels are hazardous waste materials. Disposal laws vary by locality. X7501190602 © 10/2017 ECHO Inc.

  • Page 22: Starting Cold Engine

    Recoil starter: Use short pulls - only 1/2 to 2/3 of rope for starting. Do not allow the rope to snap back in. Always hold the unit firmly. X7501190602 © 10/2017 ECHO Inc.

  • Page 23: Starting Warm Engine

    The starting procedure is the same as Cold Start except DO NOT close the choke. Stop Switch Move stop switch (A) away from the STOP position. Throttle Position Lever Move throttle position lever (B) midway between idle and full throttle positions. X7501190602 © 10/2017 ECHO Inc.
  • Page 24 Recoil starter: Use short pulls - only 1/2 to 2/3 of rope for starting. Do not allow the rope to snap back in. Always hold the unit firmly. Note: If engine does not start after 5 pulls, use Cold Start Procedure. X7501190602 © 10/2017 ECHO Inc.

  • Page 25: Stopping Engine

    Have your dealer repair stop switch before using unit again. Operating Blower Always wear safety glasses, hearing protection and a face filter mask or serious personal injury may result. Do not point the blower pipe in the direction of people or pets. X7501190602 © 10/2017 ECHO Inc.
  • Page 26 Use only during appropriate hours. To reduce sound levels, limit the number of pieces of equipment used at any one time. Allow the engine to warm up at a fast idle for a few minutes. X7501190602 © 10/2017 ECHO Inc.

  • Page 27: Maintenance

    Wear gloves to protect hands from sharp edges and hot surfaces. Operating a poorly maintained unit can result in serious injuries to operator or bystanders. Always follow all maintenance instructions as written, otherwise serious personal injury may result. X7501190602 © 10/2017 ECHO Inc.

  • Page 28: Skill Levels

    Level 1 = Easy to do. Common tools may be required. Level 2 = Moderate difficulty. Some specialized tools may be required. Level 3 = See your dealer. Click HERE or go to http://www.echo-usa.com/products/maintenance-kit HERE https://www.shindaiwa-usa.com/you-can.aspx For information about maintenance kits.

  • Page 29: Air Filter

    Clean the filter with a neutral detergent. Do not use solvents for cleaning. If filter can be reused, be certain: • The entire frame of the filter is securely seated in the housing. X7501190602 © 10/2017 ECHO Inc.

  • Page 30: Fuel Filter

    Fines up to $37,500 may be enforced for using an un-certified replacement part. Spark Plug Level 2. Parts Required: Tune-Up Kit Use only NGK BPMR8Y spark plug otherwise severe engine damage may occur. X7501190602 © 10/2017 ECHO Inc.

  • Page 31: Cooling System

    This build up insulates the engine and prevents the heat from leaving. Removal of cooling passage blockages or cleaning of cooling fins is considered “Normal Maintenance.” Any failure attributed to lack of maintenance is not warranted. X7501190602 © 10/2017 ECHO Inc.

  • Page 32: Exhaust System

    335 m (1100 ft.) above sea level (ASL) (96.0 kPa). To maintain proper engine operation above 335 m (1100 ft.) ASL the carburetor may need to be adjusted by an authorized ECHO service dealer. X7501190602 © 10/2017 ECHO Inc.
  • Page 33 If a tachometer is available, idle speed screw (A) should be set to the specifications found on “Specifications” Page of this manual. Turn idle screw (A) clockwise to increase idle speed; counter clockwise to decrease idle speed. X7501190602 © 10/2017 ECHO Inc.

  • Page 34: Troubleshooting

    See your dealer does not wire start Interlock switch No spark Incorrect gap - Adjust to Covered with 0.65mm (0.026 Spark at carbon - in.) plug Fouled with Clean or replace fuel - Plug plug defective X7501190602 © 10/2017 ECHO Inc.

  • Page 35: Storage

    Do not store your unit for a prolonged period of time (30 days or longer) without performing protective storage maintenance which includes the following: Store unit in a dry, dust free place, out of the reach of children. X7501190602 © 10/2017 ECHO Inc.
  • Page 36 10. Install the spark plug. Connect the spark plug lead to the spark plug. 11. Remove blower pipe assembly from unit. X7501190602 © 10/2017 ECHO Inc.

  • Page 37: Specifications

    (MPH) Air Volume with round pipe 12.9 m /min. (456 ft. /min.) Maximum Air Speed with flat 80.5 m/sec (180 mph) pipe (MPH) Air Volume with flat pipe 12.1 m /min. (428 ft. /min.) X7501190602 © 10/2017 ECHO Inc.

  • Page 38: Product Registration

    Please go to http://www.echo-usa.com/Warranty/Register-Your-ECHO to register your new product on-line. It's FAST and EASY! NOTE: your information will never be sold or misused by ECHO, Inc. Registering your purchase enables us to contact you in the unlikely event of a service update or product recall, and verifies your ownership for warranty consideration.
  • Page 39 PB-2620 PRODUCT REGISTRATION X7501190602 © 10/2017 ECHO Inc.
  • Page 40 P48915001001 - P48915999999 ECHO INCORPORATED 400 Oakwood Road Lake Zurich, IL 60047 www.echo-usa.com...
  • Page 41 INTRODUCTION: Ce Guide de démarrage rapide ECHO est conçu pour vous fournir les détails sur les signaux de sécurité et d’avertissement, les étapes de montage nécessaires et les instructions opérationnelles qui vous permettront d’utiliser votre produit dans les plus brefs délais.
  • Page 42 Additional operating instructions are available from • Conserve water by using blowers instead of hoses for many lawn your Authorized ECHO Dealer. and garden applications, including areas such as gutters, screens, patios, grills, porches, and gardens.
  • Page 43 Mantenga todas las partes del cuerpo alejadas de las superficies pueden producirse lesiones graves. Su concesionario de mantenimiento auto- calientes. rizado de ECHO le proporcionará instrucciones de funcionamiento adicio- • No opere desde las escaleras, ya que será difícil mantener el equi- nales.
  • Page 44 • N’utiliser que des attaches approuvées. L’utilisation de combinai- • Utiliser des râteaux et des balais pour dégager les débris avant de sons d’accessoires non-approuvés peut causer de graves bless- souffler. ures. X7151190000 © 09/2019 ECHO Incorporated...
  • Page 45 Les curieux doivent porter des lunettes protectrices. • Éviter de souffler des débris vers les personnes, les animaux domes- tiques, les fenêtres ouvertes ou les véhicules pendant l’utilisation de l'appareil. À l’approche d’une personne, couper le moteur. X7151190000 © 09/2019 ECHO Incorporated...
  • Page 46 Nota: Alinee las pestañas del tubo con la ranura de la unidad. Insertar hasta escuchar un "CLIC". Remarque: Alignez les languettes du tube avec la fente de l’unité. Insérez jusqu'à ce qu'un "CLIC" soit entendu. X7151190000 © 09/2019 ECHO Incorporated...
  • Page 47 Démarreur à rappel Remarque: Si, après 5 tractions, le moteur ne démarre pas, placez le Levier de Starter (F) en position de MARCHE , pousser la Purge (G) à nouveau et répétez et répétez l'étape X7151190000 © 09/2019 ECHO Incorporated...
  • Page 48 Remarque: Si, après 4-5, le moteur ne démarre pas, effectuez la procédure de démarrage à froid Étape 3. STOP ENGINE / DETENER MOTOR / ARRÊT MOTEUR MAINTENANCE PROCEDURE: IDLE SPEED ADJUSTMENT PROCEDIMIENTO DE MANTENIMIENTO: AJUSTE DE LA VELOCIDAD DE RALENTÍ PROCESSUS D'ENTRETIEN RÉGLAGE DE LA VITESSE DE RALENT 3000 X7151190000 © 09/2019 ECHO Incorporated...
  • Page 49 Carburetor adjustments, other than idle around fuel cap and empty fuel tank. Pull the fuel filter from the fuel tank. speed, must be performed by an authorized ECHO dealer. Remove the filter from the line and install the new filter (do not damage •...
  • Page 50 Service of this product during the warranty period must be performed by personales o daños a la propiedad. an Authorized ECHO Service Dealer. For the name and address of the • Durante el transporte, proteja siempre la unidad para prevenir el vuelco, Authorized ECHO Service Dealer nearest you, ask your retailer or call 1- el derrame de combustible y el daño de la unidad.
  • Page 51 • Toujours sécuriser l'appareil pendant le transport afin d'éviter tout retour- miento de ECHO autorizado más cercano, pregúnteselo a su revende- nement, tout déversement de carburant et tout dommage à l'appareil. dor o llame al 1-800-432-ECHO (3246). La información sobre el Rangement à...
  • Page 52 • L'entretien de ce produit pendant la période de garantie doit être effectué par un distributeur agréé ECHO. Pour obtenir le nom et l'adresse du dis- tributeur agréé ECHO le plus près de chez vous, demandez à votre revendeur ou appelez le 1 800 432-ECHO (3246). Des renseignements sur les concessionnaires sont également disponibles sur notre site Web...
