- Page 1 Air hydraulic K 21270 trolley jack...
-
Page 2: Safety Instructions
INSTRUCTIONS FOR USE IMPORTANT Read these instructions carefully and store this manual in a place where you can easily find it as you may need to use it again. This jack has been designed to elevate heavier cars and trucks. Any other use beyond the conditions established for use of this jack, are considered to be inappropri- ate. - Page 3 8 The jack should be positioned so as to avoid the need for the user to place any part of his/ her body underneath the vehicle. Never work under a raised vehicle without supporting it with jack stands or other appropriate methods.
-
Page 4: Use And Operation
USE AND OPERATION Prior to operate the jack, a small assembly operation is required: 1 Start by removing the upper cover, placing the jack handle in posi- tion (4, fig.5) and secure the bolt (26) and it’s washer (27) which are included in a kit (fig.6). - Page 5 Fig. 2 Fig. 4 Fig. 5 Fig. 6 Fig. 8 not OK Fig. 7 Fig. 9 not OK...
- Page 6 LIFTING 1 Position the jack under the lifting point of the vehicle and following the safety instructions described, the lifting operation is performed by moving the lever control (2, fig.7) to the UP position and holding it there until the vehicle has been lifted to the desired height. Immedi- ately place the jack stands or another appropriate support method to support the vehicle.
-
Page 7: Maintenance
MAINTENANCE Important: Both the maintenance and the repair of the jack should only be performed by qualified and authorized personnel. 1 Before performing any maintenance operation, disconnect the air supply hose from the connection on the handle (3, fig.7). 2 Clean and lubricate the moving parts of the jack at regular intervals and insert a small amount of lubricant in the air inlet connection. - Page 8 SPARE PARTS LIST K 21270 Pos. Part No. Description K 21279 Wheel K 21275 Cylinder K 21276 Release valve K 21277 Valve housing K 21278 Pneumatic motor...
- Page 12 Kamasa Tools is a registered trademark of KG Knutsson AB, 191 81 Sollentuna, Sweden CE declaration for this product is available as a file on www.kamasatools.com K 21270 www.kamasatools.com...
