Summary of Contents for Dyon SIGMA 24 DVD

Page 2: Table Of Contents
DYON SIGMA 24 DVD V 1.1.0 Content Important Safety Instructions ..............3 Conformity ..................11 Mounting – dismantling ............... 12 Stand mounting ....................12 Wall mounting ..................... 13 Front and Rear Panel Illustration ............14 Buttons on the device ..................14 Connections ......................
Page 3 DYON SIGMA 24 DVD 14.3.4 Picture CD Playback ................65 14.4 DVD System settings ................68 14.4.1 General Setup ..................69 15.1.1 Audio Setup ..................70 16.1.1 System Setup ..................71 18 Specifications ..................73 19 Glossary ..................... 75 20 Warranty condition ................76...
Page 4: Important Safety Instructions
DYON SIGMA 24 DVD Important Safety Instructions 1) Read these instructions. 2) Keep these instructions. 3) Heed all warnings. 4) Follow all instructions. 5) Do not use this apparatus near water. 6) Clean only with dry cloth. 7) Do not block any ventilation openings, install in accordance with the instructions.
Page 5 DYON SIGMA 24 DVD 13) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
Page 6 DYON SIGMA 24 DVD The symbol indicates that dangerous voltages constituting a risk of electric shock are present within this unit. The symbol indicates that there are important operating and maintenance instructions in the literature accompanying this unit. The symbol indicates that this product incorporates double insulation between hazardous mains voltage and user accessible parts.
Page 7 DYON SIGMA 24 DVD Caution Do not trap the power supply cord under the television receiver. Never stand on, lean on, or suddenly push the television or its stand. You should pay special attention to children. Serious injury may result if it should fall.
Page 8 DYON SIGMA 24 DVD Tips regarding environmental protection At the end of its operating life, this product may not be disposed of by way of your normal household waste. Instead it must be delivered to a collection point for recycling electrical and electronic equipment. The icon on the product, in the operating instructions or on the packaging, indicates this.
Page 9 DYON SIGMA 24 DVD Support URL: http://www.dyon.eu See our website for the latest information on this engine, on other products by our company and on our company itself. If you have questions or problems, please read the FAQs on our website or contact our customer support service support@axdia.de...
Page 10 2017, or at the latest by the end of 2018, the digital antenna television DVB-T will be completely removed from the grid. Enjoy more high resolution HD channels with this unit! Visit our homepage (www.dyon.eu) to get more information about DVB-T2 HD in Germany.
Page 11 DYON SIGMA 24 DVD Caution The device turns off after 2 hours without pressing any key. Please note that this is NOT a defect. The device is designed like this. Please use the system settings to turn off this function if necessary.
Page 12: Conformity
DYON SIGMA 24 DVD Conformity We, Axdia International GmbH, hereby declare that this device corresponds to the basic requirements and relevant regulations outlined in guidelines 2014/53/EU and 2009/125/EC. The CE declaration of conformity for this product may be found on the following link: –...
Page 13: Mounting - Dismantling
DYON SIGMA 24 DVD Mounting – dismantling Stand mounting Fix the feet in the device as described in the picture and fix them with the enclosed mounting screws...
Page 14: Wall Mounting
DYON SIGMA 24 DVD Wall mounting Fasten your wall bracket to the threads on the back and observe the hole spacing.
Page 15: Front And Rear Panel Illustration
DYON SIGMA 24 DVD Front and Rear Panel Illustration Buttons on the device Status indicator Blue = Enabled Red = STAND-BY Sensor Remote Sensor Adjust VOL + volume up / Menu to the right Adjust VOL - volume down / Menu to the left...
Page 16: Connections
DYON SIGMA 24 DVD Connections Backsite below: 1. Headset connection 5. Antenna connection Satellite 2. VGA (LNB IN) 3. SCART connection 6. Antenna connection 4. PC Audio IN DVB-T2 / DVB-C 7. COAXIAL...
Page 17 DYON SIGMA 24 DVD Backsite right: 8. HDMI (ARC) 11. Common Interface 9. USB Connection ( CI+ slot) 10. Mini AV IN 12. Mini YPbPr...
Page 18: Ci/Ci+ Slot
DYON SIGMA 24 DVD 4.3 CI/CI+ Slot Note: According the CI Slot: Please take care to insert the CI-Module (CAM) in the correct way. The Top side of the module must face against the wall behind. This device is equipped with a CI+ slot for use with cam modules and smart cards which allow for the viewing of encrypted Pay-TV channels.
Page 19 DYON SIGMA 24 DVD Notice Module and smart card are not including in the packaging. Install the CI+ module after the channel scan has been accomplished and all other settings have been set. The activation of the card may take several minutes for the first time it is used.
Page 20: Remote Key Function
DYON SIGMA 24 DVD Remote Key Function POWER: To switch the set device to on or standby. MUTE: To disable or enable the sound output. PMODE: Change image setting. AUDIO: To change the audio track. SMODE: To change the sound setting.
Page 21 DYON SIGMA 24 DVD 22. EXIT: In menu: Used to return to the previous screen or menu. In DVD mode: Open DVD settings 23. FAV: Used to access your favorite channels. DVD mode: To open the DVD main menu if existing 24.
Page 22 DYON SIGMA 24 DVD Notes on batteries If the remote control is not used for a long period of time, please remove the battery from the compartment. Do not heat batteries or dispose of them in fires. Do not dismantle, deform or modify batteries.
Page 23: Connecting To Tv-Signal Input
DYON SIGMA 24 DVD Connecting to TV-Signal Input 4.5.1 Connection for DVB-T2 reception or cable TV Connect the TV signal cable (the antenna cable, for example) to the Antenna Input Jack (RF) on the back of the unit. After connection, switch on the device. Perform the initial installation or press SOURCE, select DVB-T/C and perform the station search.
Page 24: Connection For Satellite Reception
DYON SIGMA 24 DVD 4.5.2 Connection for Satellite reception Connect the signal cable to the LNB IN input on the rear panel. After connection, switch on the device. Perform the initial installation or press SOURCE, select SATELLITE and perform the station search. Please note the reception path...
Page 25: First Time Setup
DYON SIGMA 24 DVD First Time Setup Note Before you proceed, please make sure that the receiver/antenna cable is connected. Basic Settings 1. This screen is only displayed when the TV is turned on for the first time or reset to the factory default setting.
Page 26: Channel Search
DYON SIGMA 24 DVD Channel search Note If you receive television for private use, DTV is usually the right choice for the type of reception. Then select the reception mode available to you. Other settings are usually not necessary. Tune Type Now select the desired reception mode with the /...
Page 27 DYON SIGMA 24 DVD Digital Type Then select the reception path depending on how TV channels are received by you. DVB-C  Cable Television If you want to watch cable television, please select the DVB-C option for RECEPTION WAY using the arrow keys.
Page 28 DYON SIGMA 24 DVD Satellit For TV reception via a satellite dish on the roof, please select the option Satellite using the arrow keys for RECEIPTION PATH. Further settings are usually not necessary. Confirm with OK to start the channel search.
Page 29 DYON SIGMA 24 DVD Important! Use the EXIT or MENU button to cancel the channel scan. Please note that if you cancel the scan, no stations will be stored and therefore no station picture will be displayed. First aid! No transmitter is displayed after the first installation.
Page 30: Osd Settings (Main Operations)
DYON SIGMA 24 DVD 6 OSD Settings (Main Operations) Press the MENU button and / to select the page. Press / to select the setting. CHANNEL MENU NOTE: After the initial installation, only stations of the currently selected receiver source can be edited here.
Page 31 DYON SIGMA 24 DVD 1) Auto Tuning: Press the MENU button and 2 x the OK button. Tuning Setup UK Country  DTV +ATV  Tune Type  DVB-C  Digital Type Scan Type Full Network ID Auto Frequency Auto...
Page 32 DYON SIGMA 24 DVD 2) DTV Manual Tuning: You can select a DTV channel and then search the channels in / this channel. To select a channel. please press Then press OK to search the channel. NOTE: Bad (bad) - Normal (normal) - Good (good) is the signal strength.
Page 33 DYON SIGMA 24 DVD 3) Programme Edit: You can delete, move, skip, or add channels to your favorites. First, change to the reception mode DVB-T/C or Satellite, in which you want to edit the channel list and sort channels. Press the MENU button on the remote control.
Page 34 DYON SIGMA 24 DVD from the favorites, the icon disappear. 5) Signalinformation Use the "▲ ▼" buttons to select the menu item Signal Information. To get signal information, press OK to confirm. Press the Menu button to return to the previous menu.
Page 35: Picture Menu
DYON SIGMA 24 DVD 6.2 PICTURE MENU The second item of the MENU is PICTURE MENU. You can adjust picture effect here, such as contrast, brightness, etc. (just if in picture mode personal has been selected) Press ▲▼ to select the setting, press ◄► to change the setting.Press TV MENU to step back to the previous menu.
Page 36 DYON SIGMA 24 DVD Description of the individual menu items: Picture Mode Dynamic, Standard, Mild and Personal Contrast Setting 0 - 100 Brightness Setting 0 - 100 Colour Setting 0 - 100 Tint Setting 0 - 100 Sharpness Setting 0 - 100...
Page 37: Sound Menu
DYON SIGMA 24 DVD SOUND MENU The third item of the MENU is the SOUND MENU. You can adjust the sound effect here such as treble, bass, balance etc. Press ▲▼ to select the setting, press ◄► to change the setting.
Page 38: Time Menu
DYON SIGMA 24 DVD 6.4 TIME MENU The fourth menu item is the TIME menu. You can set the sleep timer, the auto standby, and the display time . Press ▲ ▼ to select a setting, press ▲ ▼ to change the value and OK to confirm.
Page 39: Lock Menu
DYON SIGMA 24 DVD LOCK MENU The fifth item of the menu is the LOCK MENU You can lock system, set password, lock channel and set parental guidance. Once you set the lock system on you can not search the channels or change any channels.
Page 40 DYON SIGMA 24 DVD Note: The default password is 0000. If the menu is completely locked, the hotel mode can be opened directly with the key combination MENU - 4 - 5 - 8 - 8 (without hyphens). Lock station: Press ▲ ▼ to select a program (station), press the green teletext key to lock the program.
Page 41: Setup Menu
DYON SIGMA 24 DVD SETUP MENU The sixth item of the MENU is the SETUP MENU. You can adjust the Menu language, Audio language, Subtitle language etc. Press ▲▼ to select the setting, press ▲▼ to select the value to change, press ◄► to change the setting.
Page 42 DYON SIGMA 24 DVD Description of the individual menu items Language Select the menu language TT Language Select the videotext language Audio Languages Select Audio Language Subtitle Language Select Subtitle Language Hearing Impaired On / Off Aspect Ratio Select aspect ratio between:...
Page 43: Hotel Mode
DYON SIGMA 24 DVD 7 Hotel Mode Note on operation in hotel mode: To enter the hotel mode, select "System Lock " under the menu item "LOCK". Confirm with OK and enter the password (0000). Now this menu item is activated, press ◄► to change the setting (On / Off) and you can select "Hotel mode", confirm with...
Page 44 DYON SIGMA 24 DVD Hotel Menu Enable or disable hotel mode Hotel Mode Lock source Lock individual sources (satellite, HDMI, etc.) “Off” or signal source such as Start source (satellite, HDMI, etc.) Start channel Set channel at system start Standard volume...
Page 45: Epg Menu (Electronic Program Guide)
DYON SIGMA 24 DVD EPG Menu (Electronic Program Guide). The EPG menu is used to look at what is being broadcasted on DTV or Radio channel in the day. To access the EPG menu, press the EPG button, the following menu will be displayed: Program guide 10.April 2014 14:45 –...
Page 46: Troubleshooting
DYON SIGMA 24 DVD Troubleshooting No sound /No Picture Trouble phenomenon Symptom Inspection Check Picture Audio antenna position, direction Snow Noise or connection antenna position, direction or connection Ghost Normal audio electronic equipment,car/ Interfere Noise motorcycle,fluorescent light Volume(check if mute is...
Page 47: Error Notes
DYON SIGMA 24 DVD Problem Potential What to do Reasons Remote control The battery is Change new unit is not exhausted battery workable Remote control Adjust the way unit is not of holding in the right remote control opposite of the...
Page 48 DYON SIGMA 24 DVD - Check the input source using the SOURCE The reception is button. disturbed, the antenna - Check the antenna cable is not cable. connected, an unused - In TV mode, press the No Signal reception path has...
Page 49: Ci+ Information
DYON SIGMA 24 DVD 10 CI+ information The TV set contains a Common Interface CI+ Slot. Different CAM cards with smart card reader can be found at local dealers for different Pay-TV provider. • Set in: Turn off the TV. Now insert the module.
Page 50 DYON SIGMA 24 DVD The device can be operated with CI + capable modules. Which channels and contents are enabled depends on the CI+ module and smart card used. Note that not all service providers will provide the necessary CI+ module, or use different modules that may not be compatible.
Page 51: Teletext Function Keys
DYON SIGMA 24 DVD 11 TELETEXT Function Keys Teletext is an information system broadcast by certain channels which can be consulted like a newspaper. It also offers access to subtitles for viewers with hearing problems or who are not familiar with the transmission language(cable networks, satellite channels, etc.)
Page 52 DYON SIGMA 24 DVD INDEX This returns to the contents page (usually page 100). SUB PAGE Certain pages contain sub-pages which are automatically displayed successively. This key is used to stop or resume sub- page acquisition. The indication appears top left.
Page 53: Selecting The Input Source
DYON SIGMA 24 DVD Selecting the input source This unit includes a variety of input sources, which can be selected and selected using the SOURCE button on the TV or on the remote control. Press SOURCE to enter the input source menu, the following...
Page 54: Using Usb Devices
DYON SIGMA 24 DVD 13 Using USB Devices The Dyon Core has an USB Port to upgrade the software and playing media files. If possible, please connect USB devices directly to the Devices USB interface. If this is not possible, use only USB extension cables not exceeding 25 cm.
Page 55: Photo Playback
DYON SIGMA 24 DVD 13.1 Photo Playback Use ◄► or ▲ ▼ to select a photo. A preview image is displayed. Press the OK button or Play button ► (at the bottom of the remote control) to display the photo in full screen mode.
Page 56: Music Playback
DYON SIGMA 24 DVD 13.2 Music Playback Use ◄► or ▲ ▼ to select a music file. An infofile is displayed. Press the OK button or Play button ► (at the bottom of the remote control) to play the music file...
Page 57: Video Playback
DYON SIGMA 24 DVD 13.3 Video Playback Use ◄► or ▲ ▼ to select a photo. A preview image is displayed. Press the OK button or Play button ► (at the bottom of the remote control) to display the movie in full screen mode.
Page 58: Dvd Operation
DYON SIGMA 24 DVD 14 DVD Operation IMPORTANT Note: If you want to play a DVD, you must first open the input source menu with the SOURCE button and then go to DVD. Press the OK button to enter the selected DVD mode.
Page 59: Using Discs
DYON SIGMA 24 DVD 14.2 Using discs Handling When inserting or removing a disc, do not touch the surface (see illustration). Do not affix paper or labels on the disc. Cleaning Fingerprints and other contaminations can reduce the quality of the sound and the video. Use a soft,...
Page 60: Playback Operation
DYON SIGMA 24 DVD 14.3 Playback operation 14.3.1 Getting started Connect the device to a mains socket using the power supply unit that is delivered with the device. Push the POWER key on the right side of the TV SET.
Page 61 DYON SIGMA 24 DVD Operating the device and general buttons Depending on the situation, you can use the buttons on the device or remote control to operate the device. However, the remote control enables greater usage of the device functions.
Page 62: Dvd Playback
DYON SIGMA 24 DVD 14.3.2 DVD playback Start playback Insert a disc. The DVD player automatically starts with the playback. In the initial menu, select the desired option using the  buttons. Then press OK on the remote control or ENT on the DVD player.
Page 63 DYON SIGMA 24 DVD Continue playback at normal speed using INFO button Press this button once to display detailed information about the disc in the player. (Pressing this button repeatedly). AUDIO button During playback the available audio streams are enabled successively (DVDs can contain up to eight audio streams;...
Page 64: Cd Playback (Audio, Mp3, Vcd, Svcd)
DYON SIGMA 24 DVD recordings of multiple camera perspectives. TITLE button The content of a DVD is often divided into several titles that contain multiple menus. If you press the TITLE button during playback, the title menu is displayed. Using the  buttons or the numerical buttons (0-9) and +10 on the remote control, you can select the desired title or the desired option.
Page 65 DYON SIGMA 24 DVD  button To jump to the beginning of the next track or chapter. GOTO button Enables you to select a position (time or track) at which to start playback. During CD playback the following options are...
Page 66: Picture Cd Playback
DYON SIGMA 24 DVD 14.3.4 Picture CD Playback Insert a picture CD. The DVD player automatically starts with the playback The root folder and various subfolders are displayed. Select a folder using the  buttons on the remote control. Confirm your selection using one of the following buttons: , OK, PLAY/...
Page 67 DYON SIGMA 24 DVD Press this button a second time to close the display window.. This function is only available in folder mode. Press this button once to play back the content of a file/folder button in loop mode. Press this button repeatedly to cycle through the following...
Page 68 DYON SIGMA 24 DVD Press the  button to rotate the current picture anti-clockwise as shown below. Press the  button to flip the current picture horizontally as shown below. Press the  button to flip the current picture vertically as shown below.
Page 69: Dvd System Settings
DYON SIGMA 24 DVD 14.4 DVD System settings In this section, you will learn how to customize the default settings of the system according to your needs. Note Only change the system settings if there is no disc in the DVD player or if the DVD player is not in operation.
Page 70: General Setup
DYON SIGMA 24 DVD 14.4.1 General Setup – General Setup -- TV-Display Wide OSD Language Screen Saver Last Memory Make settings: Highlight the option using the  and  buttons. Switch to the option's setting by pressing OK or . Use the  and  buttons to highlight the desired setting and confirm with OK.
Page 71: Audio Setup
DYON SIGMA 24 DVD 15.1.1 Audio Setup – Audio setup -- Downmix Make settings: Highlight the option using the  and  buttons. Switch to the option's setting by pressing OK or . Use the  and  buttons to highlight the desired setting and confirm with OK.
Page 72: System Setup
DYON SIGMA 24 DVD 16.1.1 System Setup -- Bevorzugte Einstellungen -- TV Typ Audio Untertitel CD/DVD Menü Kindersicherung Passwort Standard Make settings: Highlight the option using the  and  buttons. Switch to the option's setting by pressing OK or . Use the  and  buttons to highlight the desired setting and confirm with OK.
Page 73 DYON SIGMA 24 DVD Menu option Possible Settings TV Typ system To set the TV type (NTSC, PAL, Auto). Audio To set the playback language Possible settings are English (default), French, Spanish, German etc.. Subtitle To set the subtitle language Possible settings are English, French, Spanish, German etc.
Page 74: Specifications
DYON SIGMA 24 DVD 18 Specifications Item Specification ATV/DTV Tune Frequency Range VHF: 174MHz to 230 MHz UHF: 470MHz to 862 MHz Connections RF IN IEC 169-2 female connector TV SCART Composite Video, Audio L/R Power Input 100-240V ~ 50/60Hz Consumption 60 W.
Page 75 DYON SIGMA 24 DVD Disposal of electrical and electronic equipment This product must be disposed of properly at the end of its useful life, disposal with household waste is not permitted. This product must be returned to the appropriate recycling collection point or to the retailer from whom the same product is purchased.
Page 76: Glossary
DYON SIGMA 24 DVD 19 Glossary DiSEqC Digital Satellite Equipment Control Digital system, with which the receiver can control different components of the external unit. It is especially used for selecting from multiple satellite positions (for example Astra and Eutelsat).
Page 77: Warranty Condition
We offer a warranty on our products in accordance with the following conditions: 1. DYON products are covered by a 12 month warranty. We will resolve damages or defects on DYON products free of charge within 12 months of the purchase date under the following warranty conditions.
Page 78 DYON SIGMA 24 DVD IMPORTANT: AXDIA will only accept parcels that have an RMA number. Please observe the following when sending the product: 1. Send the product suitably packaged with carriage and insurance paid. Do not enclose any accessories with the products (no cables, CD's, memory cards, manuals, etc.), unless the AXDIA Service Centre specifies otherwise.
