SCORPION G2 MANUAL - WATER JETTER/DRAIN CLEANER
WATER JETTING/DRAIN CLEANING MACHINE
Cold Water
Record Serial Number below and retain product serial number which is
located on nameplate.
UNIT SERIAL NO.
ENGINE SERIAL NO.
PURCHASE DATE
®
Petrol Driven
V1.0 - 2020
Advertisement
Table of Contents
Related Manuals for Jetwave Scorpion G2
Summary of Contents for Jetwave Scorpion G2
- Page 1 SCORPION G2 MANUAL - WATER JETTER/DRAIN CLEANER ® WARNING! Read this Operator’s Manual carefully before using this machine. Failure understand and follow the contents of this manual may result in electrical shock, fire and/or serious personal injury. READ CAREFULLY WATER JETTING/DRAIN CLEANING MACHINE...
-
Page 2: Table Of Contents
SCORPION G2 MANUAL - WATER JETTER/DRAIN CLEANER Table of Contents Safety Symbols General Power Tool Safety Warnings Work Area Safety Electrical Safety Personal Safety Tool Use And Care Service Water Jetter Safety Description, Specifications And Standard Equipment Description Specifications Standard Equipment... -
Page 3: Safety Symbols
SCORPION G2 MANUAL - WATER JETTER/DRAIN CLEANER Safety Symbols In this operator’s manual and on the product, safety symbols and signal words are used to communicate important safety information. This section is provided to improve understanding of these signal words and symbols. -
Page 4: Water Jetter Safety
SCORPION G2 MANUAL - WATER JETTER/DRAIN CLEANER clean. Properly maintained tools with sharp cutting burns or other issues. Appropriate personal protective edges are less likely to bind and are easier to control. equipment (PPE) includes safety glasses and gloves, and may also include equipment such as latex or •... -
Page 5: Description, Specifications And Standard Equipment
® Figure.1 - Scorpion G2 Water Jetting Machine with each catalog number. Figure.3 - Machine Serial Number Figure.1a - Scorpion G2 Water Jetting Machine with optional front double stack kit UNIT MACHINE PRESSURE FLOW RATE... -
Page 6: Machine Assembly
SCORPION G2 MANUAL - WATER JETTER/DRAIN CLEANER The machine serial number is located on the frame. 2. Clean any oil, grease or dirt from the equipment, The last 4 digits indicate the month and year of the including the handles and controls. This aids inspection manufacture. -
Page 7: Machine And Work Area Set-Up
SCORPION G2 MANUAL - WATER JETTER/DRAIN CLEANER Engines produce carbon monoxide, a colorless, odorless poison gas. Breathing carbon monoxide can cause nausea, fainting or death. Do not start and run engine in an enclosed area, even if doors and windows are open. Only operate outside. -
Page 8: Water Supply
Keeping the jetter hose on the reel(s) will help to minimize hose damage. The Scorpion G2 is equipped with two hose reels, a primary reel mounted to the jetter frame and the remote reel which has a separate base. Typically the primary reel is equipped with larger hose suitable for jetting larger diameter drains or supplying water to the remote reel. - Page 9 SCORPION G2 MANUAL - WATER JETTER/DRAIN CLEANER 1. Water Control Valve. Choose the valve to be used to control water flow. If using a foot valve to control water flow, route a hose from the jetter pump to the IN fitting on the foot valve.
-
Page 10: Jetter Hose Selection Chart
SCORPION G2 MANUAL - WATER JETTER/DRAIN CLEANER Jetter Hose Selection Chart Applications Pipe Size Suggested Hose (ID) Kitchen sinks, laundry tubs and stacks, clean-outs, and vents. 2” – 3” 1/8” Whip hose (optional equipment) 1/8” or 3/16” Whip hose (optional Shower and floor drains, lateral lines, and grease traps. -
Page 11: Operating Instructions
SCORPION G2 MANUAL - WATER JETTER/DRAIN CLEANER Operating Instructions 3. Turn the battery isolator switch ON and confirm the Emergency stop button is in the out position (rotate button clockwise) (Figure 11). CAUTION 4. Confirm that the water supply is turned on and the water tank is full. - Page 12 SCORPION G2 MANUAL - WATER JETTER/DRAIN CLEANER 6. If needed, turn the unloader valve while monitoring the When jetting a drain, typically the hose is fed into the drain pressure gauge on the unloader valve to adjust the the full distance to be cleaned and slowly pulled back. This...
-
Page 13: Draining Water From System
OFF. When the trigger is OFF, water recirculates and it causes the water to heat up. This Jetwave water jetting machine can also be used as a pressure washer. Use as a pressure washer is similar to 4. -
Page 14: Hose Reel Brake Adjustment
SCORPION G2 MANUAL - WATER JETTER/DRAIN CLEANER Hose Reel Brake Adjustment Engine The reels are equipped with an adjustable brake to Maintain the engine as directed in the engine operator’s prevent the hose from playing off the reel under its own manual supplied with the unit. -
Page 15: Gearbox Lubrication
At 1000 hours of use (less in severe use conditions) the authorized Jetwave service technician. Scorpion G2 should be taken to a Jetwave Independent Service Center for pump seal and valve service. Tool should be taken to a Jetwave Independent Service Center or returned to the factory. -
Page 16: Troubleshooting
SCORPION G2 MANUAL - WATER JETTER/DRAIN CLEANER Trouble Shooting PROBLEM CAUSE SOLUTION Jetter shuts off in use. Not enough water in the tank (low water Confirm water supply is ON. float switch turning jetter off). Confirm water supply hose is clear and not kinked or collapsed. -
Page 17: Maintenance Log
SCORPION G2 MANUAL - WATER JETTER/DRAIN CLEANER Maintenance Log Hour Meter Date Maintenance Performed Service Agent Reading... - Page 18 SCORPION G2 MANUAL - WATER JETTER/DRAIN CLEANER NOTES...
- Page 19 SCORPION G2 MANUAL - WATER JETTER/DRAIN CLEANER NOTES...
- Page 20 72–74 Richmond Road, Keswick, 5035 Adelaide, South Australia, AU +61 8 8371 3599 sales@jetwave.com.au jetwave.com.au jetwavegroup jetwave.group jetwavegroup jetwavegroup jetwave-group...
